69Multifunction screens

"SETUP" menu
)Press the "SETUP"button for access to itsmenu. You can choose from the following functions:
- "Display configuration",
- "Voice synthesis".
Display confi guration
This menu is used to set the brightness of the
screen, the screen colour scheme and the date
and time.
Voice synthesis
This menu is used to adjust the volume for
guidance messages and to select the type of
voice (male or female).
For safety reasons, configuration of themultifunction screen by the driver must only be done when stationary.

Tr i p c o m p u t e r
Monochrome screen C


Information displays

You can choose between two types of display by pressing button A:


- the trip computer information appears
temporarily above the audio information,
displayed permanently in full screen,
or

- the trip computer and audio information
both appear permanentl
y in a shared screen.
)Press the button, located at the end of
the wiper stalk , to display the various trip computer tabs in succession. S
ystem that gives you current information on your journey (range, fuel consumption…).

71Multifunction screens


- the current information tab with:
●
the range,
●
the current fuel consumption,
●
the Stop & Star t time counter.



- t
he trip "1"
tab with:
●
the distance travelled,
●
the avera
ge fuel consumption,
●
the average speed,
for the first trip.



- the trip
"2"tab with:
●
the distance travelled,
●
the avera
ge fuel consumption,
●
the average speed,
for the second trip.



Trip zero reset
)
When the trip required is displayed, press
the button on the end of the wiper stalk for
m
ore than two seconds.
Tr i p s "1"and "2"
are independent but their use is identical. For example, trip "1"
can be used for dailyfigures, and trip "2"
for monthly figures.

Type 2 central instrument panel screen
Information displays


- Display of instantaneous information with:
●
the ran
ge,
●
the current fuel consumption,
●

Stop & Start time counter,


- Display of trip "1"
with:
●
the distance travelled,
●
the average fuel consumption,
●
the average speed,
for the first trip.



- Displa
y of trip "2"
with:
●
the distance travelled,
●
the average fuel consumption,
●
the average speed, for the second trip.



●
information on the current audio source,

●
black screen,

●
navi
gation-guidance messages.
)Press the button, located at the end of the
wiper stalkor )turn the thumb wheel, located on the left of
the steering wheel
,
to display the following information in turn:
●
reminder of the speed,
●
instantaneous information
,●
trip "1" ,
●
trip "2",

73Multifunction screens

Tr ip zero reset
)When the required trip is displayed, press
th
e thumb wheel located on the left of the
steering wheel
or the button on the end of
the wiper stalk
for more than two seconds.
Trips "1"
and "2"are independent but their use
is identical.
For example, trip "1"
can be used for daily figures and trip "2"
for monthly figures.

A few definitions…
This value may vary following a changein the style of driving or the relief,resulting in a significant change in thecurrent fuel consumption.

If dashes are displayed continuously while driving in place of the digits, contact a CITROËN dealer or a qualified workshop.
This function is only displayed from 20 mph (30 km/h).
The fuel consumption of your vehicle will be higher than the official figures obtainedby CITROËN during the first 3 000 miles(5 000 km) of the vehicle's life.
Range
(miles or km)This indicates the distancewhich can still be travelled with the fuelremaining in the tank in relation to the average
fuel consumption over the last few miles(kilometres) travelled.
When the ran
ge falls below 20 miles (30 km),
dashes are displayed. After filling with at least 5 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (10 0 km).

Current fuelconsumption
(mpg or l/100 km or km/l)
This is the average fuel consumption during the last few seconds.


Average fuel consumption
(mpg or l/100 km or km/l)
This is the average fuel consumption since the last trip computer zero reset.
Average speed
(mph or km/h)This is the average speed calculatedsince the last trip computer zero reset (ignition on).
Distance travelled
(miles or km)This indicates the distancetravelled since the last trip computer zero reset.
Stop & Start time counter
(minutes/seconds or hours/minutes)
If your vehicle is fitted with Stop & Star t, a timecounter calculates the time spent in STOP mode during a journey.
It resets to zero every time the ignition isswitched on with the key.

75
Multifunction screens

003
Comfort

Vent ilat ion
Air intake
The air circulating in the passenger compar tment
is filtered and originates either from the outside
via the grille located at the base of the windscreen or from the inside in air recirculation mode.
Air treatment
The incoming air follows various routesdepending on the controls selected by thedriver:
- direct arrival in the passenger compartment (air intake),
- passage through a heating circuit (heating),
- passage through a cooling circuit (air conditioning).
Control panel
The controls of this system are grouped
together on control panel A on the centreconsole.


Air distribution
1.Windscreen demisting-defrosting vents.
2. Front side window demisting-defrosting
vents. 3. Side adjustable air vents.
4.
Central adjustable air vents.
5. Air outlets to the front footwells.
6.Air nozzles to the front footwells. 7. Air outlets to the rear footwells.
