413
QUESTIONANSWER SOLUTION
The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5

MHz is displayed...). The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.
Activate the RDS function to enable the system
to check whether there is a more power ful
transmitter in the geographical area.
The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode. This phenomenon is normal and does not
indicate a failure of the audio equipment.
The aerial is absent or has been damaged (for example when going
through an automatic car wash or in an underground car park). Have the aerial checked by a CITROËN dealer.
Sound cut-outs of 1 to
2

seconds in radio mode. During this brief sound cut-out, the RDS searches for another
frequency giving better reception of the station. Deactivate the RDS function if the phenomenon
is too frequent and always on the same route.
The traffic announcement
(TA) is displayed. I do
not receive any traffic
information. The radio station does not broadcast traffic information.
Tune to a radio station which broadcasts traffic
information.
The stored stations are not
found (no sound, 87.5 MHz
is displayed...). An incorrect waveband is selected.
Press the BAND button to return to the waveband
on which the stations are stored.
Audio and Telematics

415
QUESTIONANSWER SOLUTION
The message "USB
peripheral error"
or "Peripheral not
recognised" is displayed in
the screen. The USB memory stick is not recognised.
The memory stick may be corrupt.
Reformat the memory stick (FAT32).
A telephone connects
automatically,
disconnecting another
telephone. Automatic connection overrides manual connection.
Modify the telephone settings to remove
automatic connection.
The Apple
® player is
not recognised when
connecting to the USB
port. The Apple® player is of a generation that is not compatible with a
USB connection. Connect the Apple® player to the AUX Jack
socket using a suitable cable (not supplied).
The hard disk or device
is not recognised when
connecting to the USB
port. Some hard disks and devices need a power supply greater than is
provided by the audio system.
Connect the device to the 230 V socket, the
12

V

socket or an external power supply.
Caution : ensure that the device does not
transmit a voltage greater than 5 V (risk of
destruction of the system).
When streaming, the
sound cuts momentarily. Some models of telephone prioritise connection with the "hands-
free" profile. Delete the "hands-free" connection profile to
improve streaming.
In "Random all" play, not
all of the tracks are played. In "Random all" play, the system can only take into account up to
999 tracks.
Audio and Telematics

QUESTIONANSWER SOLUTION
With the engine off, the
audio system switches off
after a few minutes of use. When the engine is switched off, the audio system operating time
depends on the state of charge of the battery.
The switch-off is normal: energy economy mode is activated
automatically to preserve the state of charge of the vehicle's
battery. (See the "Energy Economy Mode" section). Start the vehicle's engine to increase the battery
charge.
The message "the audio
system is overheated"
appears on the display. In order to protect the installation if the surrounding temperature
is too high, the audio system switches to an automatic thermal
protection mode leading to a reduction of the volume or stopping of
the playing of the CD. Switch the audio system off for a few minutes to
allow the system to cool.

421
DAB (Digital Audio Broadcasting) - Digital radio ........................ 3 52, 353, 395, 396
Date (setting)

...............................
.............. 43, 51
Daytime running lamps

................. 1
29, 275, 277
Deactivating the passenger
airbag
.......................................................... 17

6
Deadlocking
...............................

............... 63, 69
Defrosting
...............................

................. 98, 105
Diesel
...............................

....................... 32, 235
Dimensions
..............................

.....................318
Dipstick
................

.................................... 35, 241
Direction indicators
....... 1

31, 166, 275, 276, 279
Display screen, instrument panel
............................................... 1

8, 19, 209
Display screen, multifunction (with audio system)

....................................... 43
D

oor pockets
................................................. 11

0
Doors
..............................................................

.81
Doors, rear

...............................
.....................162
Drawer, storage
...............................

..............118
Driving economically ....................................... 14
Dynamic stability
control (DSC)

.............................................. 16

9Filling the fuel tank

........................2
33, 235, 236
Filter, air
...............

.........................................245
Filter, oil
......................................................... 24

5
Filter, particle
........................................ 2

44, 246
Filter, passenger
compartment
.............................................. 24

5
Fitting a wheel

...............................
................269
Fitting roof bars

.............................................29

4
Fittings, boot

.................................................12

1
Fittings, interior
...................................... 11

0 , 111
Fittings, rear
...............................

...................120
Flap, fuel filler

...............................
.........233, 236
Flashing indicators
................ 1

31, 166, 276, 277
Foglamps, front
..................... 1

30, 136, 275, 278
Foglamps, rear
.............................. 1

30, 279, 281
Frequency (radio)

.................................. 3
50, 351
Fuel .......................................................... 14, 235
Fuel consumption
............................................ 14
F

uel tank........................................................236Emergency call ..................................... 167, 322
Emergency warning
lamps
..............................

....................166, 167
Emissions control system, SCR
..............................

................................29
Energy economy
mode
........................................................... 2

92
Engine compartment
............................ 2

39, 240
Engine, Diesel

....................... 2
35, 237, 240, 312
Engine, petrol

................................2
35, 239, 308
Engines
..............................

................... 308, 312
Environment
...............................

............... 14, 74Fusebox, dashboard .....................................
28 2
Fusebox, engine
compartment
.............................................. 28

2
Fuses
................

.............................................282
Gauge, fuel.................................................... 233
Gearbox, automatic ........ 1 4, 204, 212, 246, 291
Gearbox, electronic
........ 1

4, 200, 212, 246, 291
Gearbox, manual
.................... 1

4, 199, 212, 246
Gear efficiency indicator
...............................

.......................209
Gear lever
..............................

.........................14
Gear lever, automatic gearbox
................

....................................... 204
Gear lever, electronic gearbox
................

............................... 200, 246
Gear lever, manual gearbox
................

....................................... 19 9
Glove box

....................................................... 111
G

uide-me-home
...............................
.............132
Eco-driving ............................... ......................14
Eco-driving (advice) ........................................ 14
E
conomy mode
...............................
..............292
Electronic brake force distribution (EBFD)
..................................... 16

8
Emergency braking assistance (EBA)
..............................

....................168, 169
Emergency braking
system

................
......................................... 169
Hazard warning lamps ..........................16 6, 167
Hazard warning lamps, automatic operation
.................................... 16

7
Headlamp adjustment
................................... 13

4
Alphabetical index

Audio and Telematics 3

Internet browser


Authentication for Internet browsing via
a smartphone is done using the Dial-Up
Networking (DUN) standard.
Press on " Internet browser
" to
displays the browser's home page;
first connect your smartphone by
Bluetooth, option "Internet", see the
" Te l e p h o n e
" section.

Some smartphones of the latest
generation do not support this
standard.






Press on Connected services
to
display the primary page.

1
1
1
2
3
4
5
6
7
8
9
10
11
Audio and Telematics 5


Level 1

Level 2

Comments


Connected
services



Secondary page



Bluetooth
connection

Search
Start the search for a device to connect.

Connect / Disconnect
Start or end the Bluetooth connection to the
selected device.

Update
Import contacts from the selected telephone to
save them in the audio system.

Delete
Delete the selected telephone.

Confirm
Save the settings.

Connected
services



Secondary page



Tr a n s f e r r a t e

Reset

Reset the usage monitor, them confirm.

Confirm


Connected
services



Secondary page



WiFi connection

All
Display all Wi-Fi networks.

Secure
Display secure Wi-Fi networks.

Stored
Memorise the selected Wi-Fi network(s).

Add
Add a new Wi-Fi network.

Off/
On

Activate or deactivate a Wi-Fi network.

Connect
Select a Wi-Fi network found by the system and
connect to it.

Audio and Telematics 7


As a safety measure and because it
requires sustained attention by the
driver, using a smartphone when
driving is prohibited.
All operations must be done with the
vehicle stationary
.

The synchronisation of a
smartphone allows applications on a
smartphone that are adapted to the
MirrorLink
TM technology to be displayed
in the vehicle's screen.
As the principles and standards are
constantly evolving, it is recommended
that you update the operating system of
your smartphone.
For the list of eligible smar tphones,
connect to the brand's internet website
in your country.
Please note:


- if your smartphone is supported, to
make it "MirrorLink
TM " compatible,
some phone manufacturers
nevertheless invite you to first
download a dedicated application.

- iPhone
®
is not supported yet; an
Apple ® application, "CarPlay ®
", is
being developed.



When connecting a smartphone to
the system, it is recommended that
Bluetooth
® be started on the smartphone


Start the application on the
smartphone (optional, depending
on the smartphone and operating
system).
Access to the different audio sources remains
accessible in the margin of the MirrorLink
TM
display, using touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons

If the smartphone is locked,
communication with the system is only
by USB cable.
During the procedure, several screen
pages relating to certain functions
are displayed.
Accept to start and end the
connection.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

Press " MirrorLink

TM
" to start
the application in the system.
Once connection is established, an
" Applications
" page is displayed with the
list of applications already downloaded to
your smartphone and adapted to MirrorLink
TM
technology.
If only one application has been downloaded to
the smartphone, it starts automatically.



MirrorLink TM
smartphone
connection

Press the end of the lighting control stalk to
start voice recognition of your smartphone via
the system.
Voice recognition requires a compatible
smartphone connected to the vehicle by
Bluetooth.







Voice recognition


As a safety measure, applications
can only be viewed with the vehicle
stationary; display is interrupted once
the vehicle is moving.
From the system, press " Connected
services
" to display the primary
page.
