keyless entry Citroen DS4 2014 1.G User Guide

81
Doors
Opening
From outside
F After unlocking the vehicle or with the electronic key of the Keyless Entry and
Starting system in the recognition zone,
pull the door handle.
From inside
F Pull the interior control lever of a front door; this unlocks the vehicle completely.
Closing
When a door is not closed correctly:
-
w
hen the engine is running ,
this warning lamp comes
on, accompanied by an alert
message for a few seconds,
-

w
hen the vehicle is moving (speed
higher than 6 mph (10 km/h)), this warning
lamp comes on, accompanied by an alert
message for a few seconds.
When the selective unlocking is
activated, the first press of the remote
control unlocking button permits
unlocking of the driver's door only. With the selective unlocking activated:
-

o

pening the driver's door unlocks
the driver's door only (if the vehicle
has not already been completely
unlocked).
-

o

pening the passenger's door
unlocks the rest of the vehicle.
The interior door controls do
not operate when the vehicle is
deadlocked.
Access

Boot
The vehicle or just the boot is unlocked,
depending on the setting.Selective unlocking
By default, complete unlocking is activated.
This setting is done in the "driving" menu,
then "Vehicle settings" and "Vehicle
access" .
When unlocking of the boot only is activated:
F

W
ith the electronic key on your person and
in the recognition zone A , press the boot
unlocking control to unlock just the boot,
then raise the tailgate.
Unlocking is signalled by rapid flashing of the
direction indicators for a few seconds.
Use this button for access to
additional information. F

L
ower the tailgate using one of the interior
grab handles.
If the boot is not closed correctly, with the
engine running or when moving (speed
above 6 mph (10 km/h)), a message appears
for a few seconds.
Closing
Opening
Complete unlocking
F After unlocking the vehicle or the boot with
the Keyless Entry and Starting system
electronic key on your person in the
recognition zone A , press the boot opening
control then raise the tailgate.

11 5
Front armrest
Comfort and storage system for the driver and front passenger.
The height and length of the armrest cover can be adjusted.
Height adjustment
F Raise the cover to the required position (low, intermediate or high).
F

I
f you raise the cover slightly beyond the
high position, guide it when lowering it to
the low position.
Longitudinal adjustment
F Slide the cover fully for wards or rear wards.
Storage
A storage space is arranged below the armrest
cover. It houses the back-up reader for the
electronic key of the "Keyless Entry and
starting" system, if the vehicle is so equipped.
F

Ra
ise the lever.
F

R
aise the cover fully.
Fittings

Front armrest
Comfort and storage device for the driver and front passenger.
The length of the armrest cover can be adjusted.
Storage
There is a storage space below the cover of
the armrest. Depending on equipment, this can
contain the back-up reader for the electronic
key of the Keyless Entry and Starting system.
F
R
aise the cover fully.
Longitudinal adjustment
F To move for wards, raise the lever. The armrest slides for wards to its stop.
F

T
o stow it, slide it fully back and press
down to lock it.

133
Welcome lighting
The remote switching on of the lighting makes your access to the vehicle easier in poor light. It is
activated depending on the ambient light level detected by the sunshine sensor.
Switching onSwitching off
F Press the open padlock on the
remote control or one of the front
door handles with the "Keyless
Entry and Starting" system.
The sidelamps and dipped beam headlamps,
as well as the side spotlamps, located under
the door mirrors, come on; your vehicle is also
unlocked. Activation or deactivation, as well as
the duration of the lighting duration
for the welcome lighting can be set
via the vehicle configuration menu.
Programming
The welcome lighting switches off automatically
after a programmed time, when the ignition is
switched on or on locking the vehicle.
Visibility

Starting-switching off the engine Keyless Entry and Starting
Starting the engine
F Place the gear selector lever at N for vehicles with an electronic gearbox, P or N
with an automatic gearbox, or neutral with
a manual gearbox.
F

W
ith the electronic key inside the vehicle,
press the brake pedal for vehicles with
an electronic or automatic gearbox, or
fully declutch for vehicles with a manual
gearbox. F

B
riefly press the "
S TA R T/
STOP " button while maintaining
pressure on the pedal until the
engine starts. If the electronic key is not detected
in the zone, a message is displayed.
Move the electronic key into the zone
so that the engine can be started.
If one of the starting conditions is not
met, a reminder message appears in
the instrument panel screen. In some
circumstances, it is necessary to
turn the steering wheel slightly while
pressing the " START/STOP " button
to assist unlocking of the steering;
a message warns you when this is
needed.
The presence of the "Keyless Entry
and Starting" electronic key in the
recognition zone is essential.
As a safety measure, do not leave this
zone with the vehicle running.
diesel vehicles
In temperatures below zero
the engine will not start until
the preheater warning lamp
has gone off.
If this warning lamp comes on after
pressing " START/STOP ", you should
hold the brake or clutch pedal down
until the warning lamp goes off and do
not press the " START/STOP" button
again.
The steering column unlocks and the engine
starts more or less instantly.
See the advice below for Diesel versions.
It is not necessary to place the electronic key in
the reader.

Emergency switch-off
In the event of an emergency only,
the engine can be switched of without
conditions. To do this, press and hold
the "START/STOP" button for about
3 seconds.
In this case the steering column locks as soon
as the vehicle stops.
Electronic key not
recognised
If the electronic key is no longer in the
recognition zone when driving or when you
(later) request switching off the engine,
a
message is displayed. F

P
ress and hold the " S TA R T/
STOP" button for about
3
seconds if you want to force
switching off the engine (note
that restar ting will not be
possible without the key) .
Ignition on position
(without starting)
With the Keyless Entry and Starting key inside
the vehicle, pressing the "START/STOP"
button, with no action on the pedals , allows
the ignition to be switched on.
F
P

ress the "START/STOP " button,
the instrument panel comes on
but the engine does not start.
F

P
ress the button again to switch off the
ignition and so allow the vehicle to be
locked.
With the ignition on, the system
automatically goes into energy
economy mode when required to
maintain the state of charge of the
battery.

233
Fuel tankCapacity of the tank: approximately 60 litres.
Low fuel level
When the low fuel level in the
tank is reached, this warning lamp
comes on in the instrument panel,
accompanied by an audible warning
Refuelling
F Press control A until the automatic opening of the fuel flap is heard.
T

his control remains active for a few
minutes after switching off the ignition. If
necessary, switch the ignition on again to
reactivate it.
F

T
ake care to select the pump that delivers
the correct fuel for your vehicle.
With Stop & Start, never refuel with the
system in STOP mode; you must switch
off the ignition with the key, or the
START/STOP button if your vehicle has
Keyless Entry and Starting.
Additions of fuel must be of at least 5 litres to
be registered by the fuel gauge.
Opening the filler cap may result in an inrush of
air. This vacuum is entirely normal and results
from the sealing of the fuel system.
and the display of an alert message. When it
first comes on, around 6 litres of fuel remain
in the tank.
Until sufficient fuel has been added, every
time the ignition is switched on, this warning
lamp appears, accompanied by an audible
signal and an alert message. When driving,
this audible signal and the display of this
alert message are repeated with increasing
frequency, as the level drops towards 0
.
You must refuel as soon as possible to avoid
running out.
If you run out of fuel (Diesel), refer to the
corresponding section.
Checks

Instrument panels ................................18 -20, 39
Intelligent Traction
Control
........................................................ 16

9
Internet
...............

...................................366, 367
Internet browser
....................................3

66, 367
ISOFIX
...............

........................................... 159
Isofix mountings
...............................

.............157Labels, identification ..................................... 31 9
Lamp, boot ............................... ............. 123, 144
Lamps, parking
............................................. 13

1
Level, AdBlue
® additive ................................. 24 8
Level, brake fluid ........................................... 2
42
Level, Diesel additive

.................................... 24

4
Level, engine coolant

.................................... 24

3
Level, engine oil

...............................
....... 35, 241
Level, power steering fluid
...............

.............................................. 242
Levels and checks

..............................
..239 -244
Lighting, dashboard
........................................ 41
L

ighting dimmer
..............................
.... 18, 19, 41
Lighting, directional
............................... 13

5, 13 6
Lighting, guide-me home
...............................

.................... 131, 132
Lighting, interior
.................................... 14

2, 143
Lighting, mood
..............................

................143
Lighting, welcome

......................................... 13

3
Loading
..............................

..................... 14, 294
Load reduction mode

.................................... 2

92
Localised Assistance Call

............................. 32

2
Locating your vehicle

................................ 6
4, 70
Locking from the inside

..............................
........................75
Long objects, transporting

............................ 12

0
Low fuel level

..............................
..................233
Luggage retaining strap
............................................................ 12

1
Jack
........

...............................................265, 354
Jukebox (copy)

...............................

............... 357
Jukebox (playing)

.......................................... 3

57
Jump starting

..............................

.................. 289
Ignition ................ ................................... 187, 190
Ignition on...................................................... 19 0
Immobiliser, electronic
............................ 7

4, 191
Indicator, engine oil level
...............

............................. 35, 39, 241
Indicator lamps, operation
...............................

............ 30, 31, 34
Indicator lamps, status
...............

............................................. 31
Indicators, direction
.............................. 1

66, 276
Inflating tyres

..............................
....................14
Inflating tyres and accessories (using the kit)

..............................
................260
Input, auxiliary
...............................

................400
Headlamps, automatic
illumination ............................... ........... 129, 132
Headlamps, dipped beam
...............

............................ 128, 275, 276
Headlamps, directional
................. 1

34, 135, 275
Headlamps, halogen
..................................... 2

75
Headlamps, main beam
...............

............................ 128, 275, 276
Headlamps, Xenon

....................................... 2

75
Headlamp wash
............................................ 13

9
Head restraints, front
........

..................................................... 101
Head restraints, rear
...............................

...............................103
Heating
................

................................ 14, 90, 91
Hill start assist

............................................... 20

8
Hooks
...............................

.............................12 2
Maintenance, routine ...................................... 14
M ap reading lamps ....................................... 14
2
Key
.......

.......................................... 67- 69, 73, 74
Key, electronic
.............................. 6

7- 69, 71, 189
Keyless Entry and Starting
..............................................6

7, 70, 74
Key not recognised

.......................................
18

9
Key with remote control
............................................. 6

0, 62, 191
Kit, hands-free
.............................. 3

76, 377, 402
Kit, puncture repair ...............................
............................
260
Kit, temporary puncture repair ...............................
............................ 260
