check engine Citroen DS4 2014 1.G Owner's Guide

253
Starting preventedYou have exceeded the authorised
driving limit: the starting prevention
system inhibits engine starting.
Every time the ignition is switched on, the
SERVICE and engine diagnostic warning
lamps come on and the UREA warning lamp
flashes, accompanied by the temporary display
of "NO START IN" and 0 miles or kilometres
-
("NO START IN 0 miles" means "Starting
prevented").
To be able to start the engine, you must call on
a CITROËN dealer or a qualified workshop.Type 2 instrument panel
A system that prevents engine
starting is activated automatically
from 650
miles (1 100 km) after
confirmation of a fault with the SCR
emissions control system. Have the
system checked by a CITROËN dealer
or a qualified workshop as soon as
possible.
In the event of a fault with the the SCR emissions control system
The UREA, SERVICE and diagnostic warning
lamps comes on, accompanied by an audible
signal and the display of the message
"Emissions fault".
The alert is triggered when driving when the
fault is detected for the first time, then when
switching on the ignition for subsequent
journeys, while the fault persists. In the event of the detection of a fault
If it is a temporary fault, the alert
disappears during the next journey,
after self-diagnosis of the SCR system.
Checks

257
Never dispose of AdBlue® additive
bottles in the household waste. Place
them in a special container provided
this purpose or take them to your
dealer.
Important: if your vehicle's
AdBlue
® tank is completely empty -
w
hich is confirmed by the alert displays
and the impossibility of starting the
engine - you must add at least 3.8 litres
(so two 1.89 litre bottles). If any additive is split or splashed, wash
immediately with cold water or wipe
with a damp cloth.
If the additive has crystallised, clean it
off using a sponge and hot water.
Important:
in the event of a top-
up after a breakdown because of
a lack of additive , you must wait
around 5 minutes before switching
on the ignition, without opening the
driver's door, locking the vehicle,
introducing the key into the ignition
switch, or introducing the key of the
"Keyless Entr y and Star ting" system
into the passenger compartment .
Switch on the ignition, then, after
10 seconds, start the engine.
F

O

btain a bottle of AdBlue
®. After first
checking the use-by date, read carefully
the instructions on use on the label before
pouring the contents of the bottle into your
vehicle's AdBlue
® tank. F
A
fter emptying the bottle, wipe away any
spillage around the tank filler using a damp
cloth.
F
R
efit the blue cap to the tank and turn it a
6
th of a turn clockwise, to its stop.
F
R
efit the black plastic blanking plug,
clipping it in on the flap.
F

D

etach the cord from the parcel shelf
support and lower the boot floor.
Checks

Removing the cartridge
F Stow the black pipe.
F D etach the angled base from the white pipe.
F

S
upport the compressor vertically.
F

U
nscrew the cartridge from the bottom.
Checking tyre pressures /
inflating accessories
Beware of discharges of fluid.
The expiry date of the fluid is indicated
on the cartridge.
The sealant cartridge is designed for
single use; even if only partly used, it
must be replaced.
After use, do not discard the cartridge
into the environment, take it to an
authorised waste disposal site or a
CITROËN dealer.
Do not forget to obtain a new sealant
cartridge, available from CITROËN
dealers or from a qualified workshop. You can also use the compressor, without
injecting any product, to:
-
c heck or adjust the pressure of your tyres,
-

i
nflate other accessories (balls, bicycle
tyres...). F

C
onnect the compressor's electrical
connector to the vehicle's 12 V socket.
F S tart the vehicle and let the engine run.
F

A
djust the pressure using the compressor
(to inflate: switch B in position "I" ; to
deflate: switch B in position "O" and press
button C ), according to the vehicle's tyre
pressure label or the accessory's pressure
label.
F

R
emove the kit then stow it.
F

T
urn the selector A to the "Air"
position.
F

U
ncoil the black pipe H fully.
F

C
onnect the black pipe to the
valve of the wheel or accessory.
I

f necessary, fit one of the adaptors
supplied with the kit first.

289
F Remove the plastic cover from the (+) terminal, if your vehicle has one.
F

C
onnect the red cable to the positive
terminal (+) of the flat battery A , then to the
positive terminal (+) of the slave battery B.
F

C
onnect one end of the green or black
cable to the negative terminal (-) of the
slave battery B (or earth point on the other
vehicle).
F

C
onnect the other end of the green or black
cable to the earth point C on the broken
down vehicle (or on the engine mounting). F

S
tart the engine of the vehicle with the
good battery and leave it running for a
few
m
inutes.
F
O
perate the starter on the broken down
vehicle and let the engine run.
I
f the engine does not start straight away,
switch off the ignition and wait a few
moments before trying again.
Starting using another
battery
First check that the slave battery has a
nominal voltage of 12 V and a capacity
at least equal to that of the discharged
battery.
Do not try to start the engine by
connecting a battery charger.
Do not disconnect the (+) terminal when
the engine is running.
Before disconnecting the battery
Wait 2 minutes after switching off the ignition
before disconnecting the battery.
Close the windows and the doors before
disconnecting the battery.
When your vehicle's battery is discharged, the
engine can be started using a slave battery
(external or on another vehicle) and jump lead
cables.
F
W
ait until the engine returns to idle then
disconnect the jump lead cables in the
reverse order.
F
R
efit the plastic cover to the (+) terminal,
if your vehicle has one.
Practical information

291
Some functions are not available if the
battery is not sufficiently charged.Protect your eyes and face before
handling the battery.
All operations on the battery must be
carried out in a well ventilated area and
away from naked flames and sources
of sparks, so as to avoid the risk of
explosion or fire.
Do not try to charge a frozen battery;
the battery must first be thawed out to
avoid the risk of explosion. If the battery
has been frozen, before charging have
it checked by a CITROËN dealer or
a qualified workshop who will check
that the internal components have not
been damaged and the casing is not
cracked, which could cause a leak of
toxic and corrosive acid.
Do not reverse the polarity and use
only a 12 V charger.
Do not disconnect the terminals while
the engine is running.
Do not charge the batteries without
disconnecting the terminals first.
Wash your hands after wards.
It is advisable to disconnect the battery
if the vehicle is to be left unused for
more than one month.
The batteries contain harmful substances
such as sulphuric acid and lead. They
must be disposed of in accordance
with regulations and must not, in any
circumstances, be discarded with household
waste.
Take used remote control batteries and
vehicle batteries to a special collection point.
Do not push the vehicle to start the
engine if you have an electronic or
automatic gearbox.
Practical information

driving advice
distribution of loads
F Distribute the load in the trailer so that the heaviest items are as close as possible to
the axle and the nose weight approaches
the maximum permitted without
exceeding
it.
Air density decreases with altitude, thus
reducing engine per formance. Above
1
000 metres, the maximum towed load must
be reduced by 10
% for every 1 000 metres of
altitude.
Side wind
F Take into account the increased sensitivity to side wind.
Cooling
Towing a trailer on a slope increases the
temperature of the coolant.
As the fan is electrically controlled, its cooling
capacity is not dependent on the engine speed.
F

T
o lower the engine speed, reduce your
speed.
The maximum towed load on a long incline
depends on the gradient and the ambient
temperature.
In all cases, keep a check on the coolant
temperature.
F

I
f the warning lamp and the STOP
warning lamp come on, stop the
vehicle and switch off the engine
as soon as possible.
Braking
Towing a trailer increases the braking distance.
To avoid overheating of the brakes on a long
mountain type of descent, the use of engine
braking is recommended.
Ty r e s
F Check the tyre pressures of the towing vehicle and of the trailer, observing the
recommended pressures.
Lighting
F Check the electrical lighting and signalling on the trailer.
Refer to the "Technical data" section for
details of the weights and towed loads
which apply to your vehicle.
The rear parking sensors will be
deactivated automatically if a genuine
CITROËN towbar is used.

QUESTIONANSWER SOLUTION
There is a difference in
sound quality between the
different audio sources. For optimum sound quality, the audio settings for Volume, Bass,
Treble, Equalizer and Loudness can be adapted to the different
sound sources, which may result in audible differences when
changing source. Check that the audio settings for (Volume, Bass,
Treble, Equalizer, Loudness) are adapted to the
sources listened to. It is advisable to set the
Audio functions (Bass, Treble, Fr-Re balance,
Le-Ri balance) to the middle position, select the
"Linear", musical ambience and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.
With the engine off, the
system switches off after a
few minutes of use. When the engine is switched off, the system's operating time
depends on the state of charge of the battery.
The switch-off is normal: the system switches to economy mode
and switches off to prevent discharging of the vehicle's battery. Start the vehicle's engine to increase the battery
charge.

ABS and EBFD systems ...............................16 8
Accessories .............................. ............ 190, 304
Accessory position
....................................... 19

0
AdBlue
® ............................... ..........................248
Additif AdBlue ................................................. 28
Ad
ditive, AdBlue
.................................... 2
48, 254
Adjusting headlamps
.................................... 13

4
Adjusting head restraints

.............................. 10

1
Adjusting seat
......................................... 9

9, 100
Adjusting the date

..................................... 4
3, 51
Adjusting the height and reach of the steering wheel

.................................. 10

4
Adjusting the seat belt height
...............

.................................... 171, 172
Adjusting the time

..................................... 4
3, 51
Advice on driving

..............................
............18 4
Airbags
...............

......................................27, 175
Airbags, curtain
..................................... 1

79, 180
Airbags, front......................................... 176, 180
Airbags, lateral
...................................... 1

78, 180
Air conditioning
...............................

................14
Air conditioning, automatic

................. 8
9, 90, 93
Air conditioning, manual
........................... 8

9 -91
Air vents
..............................

............................88
Alarm
............................................................... 77
A

nti-lock braking
system (ABS)

.............................................. 16

8
Anti-pinch
........................................................ 84
A

nti-theft
..............................
.........................191
Armrest, front

......................................... 11

5 , 11 6
Armrest, rear

................................................. 12

0
Ashtray, portable
............................................ 111
A

ssistance call
...............................
....... 167, 322
Audible warning
............................................ 16

7
Audio streaming (Bluetooth)
......................... 3

54, 356, 400, 403
Audio system

...............................
............ 43, 389
Auxiliary
........................................................ 35

4Battery
...............................

............ 245, 288 -291
Battery, charging
...............................
.... 290, 291
Battery, remote control ........................ 6 6, 72-74
Black panel ...................................................... 42
Blanking screen (snow shield)
...............................

................293
Blind
.............................................................. 11

9
Blind spot sensors

........................................2

16
Blue HDi

...............
...........................39, 209, 248
Bluetooth (hands-free)

.................. 3
76, 377, 402
Bluetooth (telephone)
............................ 376

, 377
Bonnet
...............

............................................238
Boot
........

.........................................................82
Brake discs

....................................................2

47
Brake lamps

...............................
...................279
Brakes
........................................................... 2

47
Braking assistance system

...........................16

8
Braking, dynamic emergency
.................................................. 19

2
Bulbs (changing)
...............................

.... 274, 279
Cable, audio

..................................................35

4
Cable, jack

..............................
......................354
Capacity, fuel tank

..............................
..........233
CD
..............................

........................... 354, 397
CD, MP3

........................................ 3
54, 397, 398
Central locking

.............................. 6
2, 68, 69, 75
Centre console
.............................................. 11

3
Changing a bulb
.................................... 2

74, 279
Changing a fuse
............................................ 28

2
Changing a wheel

...............................
..........265
Changing a wiper blade
...............

.................................... 140, 293
Changing the remote control battery ................................... 66, 72, 73
CHECK
................

...................................... 19, 39
Checking the engine oil level
...............

........................................... 35
Checking the levels

................................ 24

1-244
Checking tyre pressures (using the kit)

..............................
................260
Checks
...............

................... 239, 240, 245, 247
Checks, routine

..................................... 2
45, 247
Child lock

...............................
........................162
Children
......................... 1

55, 157, 158, 159, 160
Children (safety)
...............................

.............162
Child seats

.................... 1
48, 149, 153 -155, 161
Child seats, conventional

..............................15

4
Child seats, ISOFIX

.............. 1
57, 158, 159, 160
Cigar lighter

...............................
....................112
C
ITROËN
L
ocalised
Emergency Call
.......................................... 32

2
Closing the boot

...............................
......... 62, 82
Closing the doors

.......................... 6
2, 68, 69, 81
Configuration, vehicle
......................... 2

0, 43, 49
Connection, Bluetooth
..................3

68, 376, 377
Connection, MirrorLink
................................. 3

71
Connection, Wi-Fi network
....................................................... 36

8
Control, electric windows

................................84
C

ontrol, emergency
boot release
...............................

...................83
Control, emergency door
.......................... 6

5, 71
Control, heated seats

.................................... 10

1
Controls, steering mounted
.............................................. 3

28, 391
Control stalk, lighting

............................ 1
28, 131
Control stalk, wipers

...................... 1
37, 138, 141
Courtesy lamps

..................................... 1
33, 142
Cruise control
........................................ 2

19, 224
Cup holder

...............................
......................113

Instrument panels ................................18 -20, 39
Intelligent Traction
Control
........................................................ 16

9
Internet
...............

...................................366, 367
Internet browser
....................................3

66, 367
ISOFIX
...............

........................................... 159
Isofix mountings
...............................

.............157Labels, identification ..................................... 31 9
Lamp, boot ............................... ............. 123, 144
Lamps, parking
............................................. 13

1
Level, AdBlue
® additive ................................. 24 8
Level, brake fluid ........................................... 2
42
Level, Diesel additive

.................................... 24

4
Level, engine coolant

.................................... 24

3
Level, engine oil

...............................
....... 35, 241
Level, power steering fluid
...............

.............................................. 242
Levels and checks

..............................
..239 -244
Lighting, dashboard
........................................ 41
L

ighting dimmer
..............................
.... 18, 19, 41
Lighting, directional
............................... 13

5, 13 6
Lighting, guide-me home
...............................

.................... 131, 132
Lighting, interior
.................................... 14

2, 143
Lighting, mood
..............................

................143
Lighting, welcome

......................................... 13

3
Loading
..............................

..................... 14, 294
Load reduction mode

.................................... 2

92
Localised Assistance Call

............................. 32

2
Locating your vehicle

................................ 6
4, 70
Locking from the inside

..............................
........................75
Long objects, transporting

............................ 12

0
Low fuel level

..............................
..................233
Luggage retaining strap
............................................................ 12

1
Jack
........

...............................................265, 354
Jukebox (copy)

...............................

............... 357
Jukebox (playing)

.......................................... 3

57
Jump starting

..............................

.................. 289
Ignition ................ ................................... 187, 190
Ignition on...................................................... 19 0
Immobiliser, electronic
............................ 7

4, 191
Indicator, engine oil level
...............

............................. 35, 39, 241
Indicator lamps, operation
...............................

............ 30, 31, 34
Indicator lamps, status
...............

............................................. 31
Indicators, direction
.............................. 1

66, 276
Inflating tyres

..............................
....................14
Inflating tyres and accessories (using the kit)

..............................
................260
Input, auxiliary
...............................

................400
Headlamps, automatic
illumination ............................... ........... 129, 132
Headlamps, dipped beam
...............

............................ 128, 275, 276
Headlamps, directional
................. 1

34, 135, 275
Headlamps, halogen
..................................... 2

75
Headlamps, main beam
...............

............................ 128, 275, 276
Headlamps, Xenon

....................................... 2

75
Headlamp wash
............................................ 13

9
Head restraints, front
........

..................................................... 101
Head restraints, rear
...............................

...............................103
Heating
................

................................ 14, 90, 91
Hill start assist

............................................... 20

8
Hooks
...............................

.............................12 2
Maintenance, routine ...................................... 14
M ap reading lamps ....................................... 14
2
Key
.......

.......................................... 67- 69, 73, 74
Key, electronic
.............................. 6

7- 69, 71, 189
Keyless Entry and Starting
..............................................6

7, 70, 74
Key not recognised

.......................................
18

9
Key with remote control
............................................. 6

0, 62, 191
Kit, hands-free
.............................. 3

76, 377, 402
Kit, puncture repair ...............................
............................
260
Kit, temporary puncture repair ...............................
............................ 260
