warning light Citroen DS4 2017 1.G User Guide

135
DS4_en_Chap04_eclairage-et-visibilite_ed01-2016
Directional lighting
When the dipped or main beam headlamps
are on, this function, allows the light beams to
better follow the road.
The use of this function, coupled with the
xenon headlamps and the cornering lighting,
considerably improves the quality of your
lighting round bends.This function is inactive:
-

w
hen stationary or at low speeds,
-
w
hen reverse is engaged.
The system is activated by default.
with directional lighting without directional lighting
Programming
The system is activated or
deactivated in the vehicle
configuration menu.
The state of the system stays in memory on
switching off the ignition.
Contact a CITROËN dealer or a qualified
workshop.
Operating fault
If a fault occurs, this warning lamp
flashes in the instrument panel,
accompanied by a message in the
screen.
04
Lighting and visibility

138
DS4_en_Chap04_eclairage-et-visibilite_ed01-2016
Automatic rain sensitive windscreen wipers
Briefly push stalk downwards.The instruction is confirmed by
a wiping cycle, accompanied by
illumination of this warning lamp
in the instrument panel and an
activation message.
Switching off
Briefly push stalk downwards again.The instruction is confirmed by
this warning lamp going off in the
instrument panel and/or the display of
a deactivation message.
The automatic rain sensitive
windscreen wipers must be reactivated
if the ignition has been off for more
than one minute.
Operating fault
If an automatic rain sensitive wiper malfunction
occurs, the wipers will operate in intermittent
mode.
Contact a CITROËN dealer or a qualified
workshop.
Do not cover the rain sensor, linked with
the sunshine sensor and located in the
centre of the windscreen behind the rear
view mirror.
Switch off the automatic rain sensitive
wipers when using an automatic car wash.
In winter, it is advisable to wait until the
windscreen is completely clear of ice
before activating the automatic rain
sensitive wipers.
Switching on
The windscreen wipers operate automatically, without any action on the part of the driver, if rain is
detected (sensor behind the rear view mirror), adapting their speed to the intensity of the rainfall.
04
Lighting and visibility

154
Braking assistance systems
Group of supplementary systems which help
you to obtain optimum braking in complete
safety in emergency situations:
-
a
nti-lock braking system (ABS),
-

e
lectronic brake force distribution (EBFD),
-

e
mergency braking assistance (EBA).Anti-lock braking system and electronic brake force distribution
Linked systems which improve the stability and manoeuvrability of your vehicle when braking, in
particular on poor or slippery sur faces.
Activation
The anti-lock braking system comes into
operation automatically when there is a risk of
wheel lock.
Normal operation of the ABS may make itself
felt by slight vibration of the brake pedal. When braking in an emergency, press
very firmly without releasing the
pressure.
Operating fault
If this warning lamp comes on,
together with the STOP and ABS
warning lamps, accompanied by an
When replacing wheels (tyres and
rims), ensure that they conform to the
manufacturer's recommendations. If this warning lamp comes on,
accompanied by an audible signal
and a message in the screen, it
In either case, contact a CITROËN dealer or a
qualified workshop. indicates a malfunction of the anti-lock braking
system which could result in loss of control of
the vehicle when braking.
audible signal and a message in the screen, it
indicates a malfunction of the electronic brake
force distribution which could result in loss of
control of the vehicle when braking.
You must stop as soon as it is safe to do so.
05
Safety

160
The driver must ensure that passengers use
the seat belts correctly and that they are all
fastened before setting off.
Wherever you are seated in the vehicle,
always fasten your seat belt, even for short
journeys.
Do not interchange the seat belt buckles as
they will not fulfill their role fully.
The seat belts are fitted with an inertia reel
permitting automatic adjustment of the length
of the strap to your size. The seat belt is
stowed automatically when not in use.
Before and after use, ensure that the seat
belt is reeled in correctly.
The lower part of the strap must be
positioned as low as possible on the pelvis.
The upper part must be positioned in the
hollow of the shoulder.
The inertia reels are fitted with an automatic
locking device which comes into operation in
the event of a collision, emergency braking
or if the vehicle rolls over. You can release
the device by pulling the strap firmly and then
releasing it so that it reels in slightly.Recommendations for children
Use a suitable child seat if the passenger is
less than 12 years old or shorter than one
and a half metres.
Never use the same seat belt to secure
more than one person.
Never allow a child to travel on your lap.
For more information on Child seats, refer
to the corresponding section.
Advice
In order to be effective, a seat belt must:
- b e tightened as close to the body as
possible,
-

b
e pulled in front of you with a smooth
movement, checking that it does not
twist,
-

b
e used to restrain only one person,
-

n
ot bear any trace of cuts or fraying,
-

n
ot be converted or modified to avoid
affecting its performance.
In accordance with current safety regulations,
for all repairs on your vehicle's seat belts, go
to a qualified workshop with the skills and
equipment needed, which a CITROËN dealer
is able to provide.
Have your seat belts checked regularly by
a CITROËN dealer or a qualified workshop,
particularly if the straps show signs of
damage.
Clean the seat belt straps with soapy water or
a textile cleaning product, sold by CITROËN
dealers.
After folding or moving a seat or rear bench
seat, ensure that the seat belt is positioned
and reeled in correctly.
In the event of an impact
Depending on the nature and
seriousness of the impact , the
pretensioning device may be deployed
before and independently of the airbags.
Deployment of the pretensioners is
accompanied by a slight discharge of
harmless smoke and a noise, due to the
activation of the pyrotechnic cartridge
incorporated in the system.
In all cases, the airbag warning lamp
comes on.
Following an impact, have the seat belts
system checked, and if necessary replaced,
by a CITROËN dealer or a qualified
workshop.
05
Safety

185
DS4_en_Chap06_conduite_ed01-2016
When towing
Distribution of loads
F Distribute the load in the trailer so that the heaviest items are as close as possible to
the axle and the nose weight approaches
the maximum permitted without exceeding
it.
Air density decreases with altitude, thus
reducing engine per formance. Above
1
000 metres, the maximum towed load must
be reduced by 10
% for every 1 000 metres of
altitude.
Side wind
F Take into account the increased sensitivity to side wind.
Cooling
Towing a trailer on a slope increases the
temperature of the coolant.
As the fan is electrically controlled, its cooling
capacity is not dependent on the engine speed.
F

T
o lower the engine speed, reduce your
speed.
The maximum towed load on a long incline
depends on the gradient and the exterior
temperature.
In all cases, keep a check on the coolant
temperature.
F

I
f the warning lamp and the STOP
warning lamp come on, stop the
vehicle and switch off the engine
as soon as possible.
Braking
Towing a trailer increases the braking distance.
To avoid overheating of the brakes, the use of
engine braking is recommended.
Ty r e s
F Check the tyre pressures of the towing vehicle and of the trailer, observing the
recommended pressures.
Lighting
F Check the electrical lighting and signalling on the trailer and the headlamp beam
height of your vehicle.
For more information on Adjusting the
headlamp beam height , refer to the
corresponding section.
For more information on Weights
, refer
to the corresponding section.
The rear parking sensors will be
deactivated automatically to avoid the
audible signal if a genuine CITROËN
towbar is used.
If the exterior temperature is high, it
is recommended that the engine be
allowed to idle for 1 to 2 minutes after
the vehicle comes to a stop, to facilitate
its cooling.
06
Driving

189
DS4_en_Chap06_conduite_ed01-2016
Starting / Switching off the engine with Keyless Entry and
S tarting
Starting the engine
F With a manual gearbox, place the gear
lever in neutral and declutch fully.
F

W
ith an automatic gearbox, place the gear
selector at P or N and press the brake
pedal. F

B
riefly press the "
S TA R T/
STOP " button while maintaining
pressure on the pedal until the
engine starts. If the electronic key is not detected
in the zone, a message is displayed.
Move the electronic key into the zone
so that the engine can be started.
If one of the starting conditions is not
met, a reminder message appears in
the instrument panel screen. In some
circumstances, it is necessary to
turn the steering wheel slightly while
pressing the " START/STOP " button
to assist unlocking of the steering;
a message warns you when this is
needed.
The presence of the "Keyless Entry
and Starting" electronic key in the
recognition zone is essential.
As a safety measure, do not leave this
zone with the vehicle running.
Diesel vehicles
In temperatures below zero
the engine will not start until
the preheater warning lamp
has gone off.
If this warning lamp comes on after
pressing " START/STOP ", you should
hold the brake or clutch pedal down
until the warning lamp goes off and do
not press the " START/STOP" button
again.
The steering column unlocks and the engine
starts.
See the advice for Diesel versions.
F

P

lace the electronic key inside the vehicle:
there is no need to place it in the reader.
06
Driving

206
DS4_en_Chap06_conduite_ed01-2016
Stop & Start
Operation
Going into engine STOP mode
STOP mode does not affect the
functionality of the vehicle, such as
braking, power steering, for example.
Never refuel with the engine in STOP
mode; you must switch off the ignition
with the key or the "START/STOP"
button.
With a manual gearbox, at a
speed below 12 mph (20 km/h),
If your vehicle is fitted with the
system, a time counter calculates
the sum of the periods in STOP STOP mode is not invoked when:
-
t
he vehicle is on a steep slope (up or
d ow n),
-
t
he driver's door is open,
-
t
he driver's seat belt is not fastened,
-
t
he vehicle has not exceeded 6 mph
(10 km/h) since the last engine start (using
the key or the "START/STOP" button),
-
t
he electric parking brake is applied or
being applied,
-
t
he engine is needed to maintain a
comfortable temperature in the passenger
compartment,
-
d
emisting is active,
-
s
ome special conditions (battery charge,
engine temperature, braking assistance,
ambient temperature...) where the engine is
needed to assure control of a system.
Special cases: STOP mode
unavailable
In this case, the "ECO" warning lamp
flashes for a few seconds, then goes
of f.
This operation is perfectly normal.
With an automatic gearbox,
when
the vehicle is stationary, this warning mode during a journey. It resets itself to zero
every time the ignition is switched on with the
key or the "START/STOP" button.
The Stop & Start

system puts the engine temporarily into standby - STOP mode - during stops in
the traffic (red lights, traffic jams, or other...). The engine restarts automatically - START mode - as
soon as you want to move off. The restart takes place instantly, quickly and silently.
Per fect for urban use, the Stop & Start system reduces fuel consumption and exhaust emissions as
well as the noise level when stationary.
or when the vehicle is stationary with the
PureTech

130 petrol and BlueHDi Diesel 115
and 120

versions, this warning lamp comes on
in the instrument panel and the engine switches
to standby automatically when you place the
gear lever in neutral and release the clutch
pedal.
lamp comes on in the instrument panel and the
engine switches to standby automatically when
you press the brake pedal or place the gear
selector at position N .
06
Driving

2 11
DS4_en_Chap06_conduite_ed01-2016
No alert will be given in the following situations:
- i n the presence of immobile objects
(parked vehicles, barriers, street lamps,
road signs...),
-

w
ith vehicles moving in the opposite
direction,
-

d
riving on a sinuous road or a sharp
c o r n e r,
The alert is given by a warning lamp which
comes on in the door mirror on the side in
question as soon as a vehicle - car, lorry,
cycle

- is detected.
For this, the following conditions must be met:
-

a

ll the vehicles must be moving in the
same direction,
-

t

he speed of your vehicle is between 7 and
75 mph (12 and 140 km/h),
-

w

hen you overtake a vehicle with a speed
difference of less than 6 mph (10 km/h),
-

w

hen a vehicle overtakes you with a speed
difference of less than 15 mph (25 km/h),
-

t

he traffic must be flowing normally,
-

i

n the case of an overtaking manoeuvre,
if this is prolonged and the vehicle being
overtaken remains in the blind spot,
-

y

ou are driving on a straight or slightly
curved road,
-

y

our vehicle is not pulling a trailer, a
caravan... -
w hen overtaking (or being overtaken by) a
very long vehicle (lorry, coach...) which is
at the same time detected at the rear in the
blind spot angle and present in the driver's
for ward field of vision,
-

i
n very heavy traffic: vehicles detected in
front and behind are confused with a lorry
or a stationary object,
-

w
hen overtaking quickly.
06
Driving

406
Alphabetical index
DS4_en_Chap11_index-alpha_ed01-2016
A
ABS and EBFD systems ...............................15 4
Accessories .............................. ............ 148, 191
Accessory position
....................................... 19

1
AdBlue
® ............................... ...... 24, 37, 253, 254
Adjusting headlamps .................................... 13
4
Adjusting head restraints

................................ 94
A

djusting seat
........................................... 9
2, 93
Adjusting the date

..................................... 4
7, 55
Adjusting the height and reach of the steering wheel

.................................... 99
A

djusting the seat belt height
...............15

7, 15 8
Adjusting the time

..................................... 4
7, 55
Advice on driving

..............................
....18 4, 185
Airbags
...............

..................................... 23, 161
Airbags, curtain
..................................... 16

4, 165
Airbags, front......................................... 162, 165
Airbags, lateral
...................................... 16

4, 165
Air conditioning
...............................

................10
Air conditioning, automatic

...................10

3, 10 6
Air conditioning, manual
....................... 10

3, 104
Alarm
............................................................... 83
A

nti-lock braking system (ABS)
....................15

4
Anti-pinch
........................................................ 87
A

nti-theft
..............................
.........................18 6
Armrest, front

......................................... 11

6 , 117
Armrest, rear

................................................. 12

1
Assistance call
...............................

.......150, 152
Audible warning
............................................ 14

9
Audio streaming (Bluetooth)
......................... 3

42, 345, 388, 391
Audio system

...............................
............ 47, 377
Auxiliary
........................................................ 3

42Back-up key.....................................................
74
Battery
...............................
............ 250, 292-295
Battery, charging ............................... ............
294
Battery, remote control ........................6 9, 75 -77
Black panel ...................................................... 46
Blanking screen (snow shield)

......................2

32
Blind
.............................................................. 11

4
Blind spot sensors

........................................2

10
Blue HDi

...............
...........................................43
BlueHDi
...............................

.................... 37, 253
Bluetooth (hands-free)

................. 3
64, 365, 390
Bluetooth (telephone)
............................3

64, 365
Bonnet
...............

............................................242
Boot
........

.........................................................81
Bottle holder

...............................
...................115
Brake discs

............................................ 2
51, 252
Brake lamps

...............................
...................285
Brakes
................................................... 2

51, 252
Braking assistance system

...........................15

4
Braking, dynamic emergency
....................... 19

3
Bulbs (changing)
...............................

.... 279, 285
Cable, audio

..................................................3

42
Cable, jack

..............................
......................342
Capacity, fuel tank

..............................
..........227
CarPlay connection ....................................... 359
CD
..............................

...........................342, 385
CD, MP3

....................................... 3
42, 385, 386
Central locking

.............................. 6
5, 71, 72, 78
Centre console
.............................................. 11

5
Changing a bulb
.................................... 2

79, 285
Changing a fuse
............................................ 28

8
Changing a wheel

...............................
..........271 Changing a wiper blade

........................ 1
40, 241
Changing the remote control battery ............................................... 6 9, 75, 76
CHECK ................ ...................................... 15, 43
Checking the engine oil level
..........................33
C
hecking the levels
........................24

5 -247, 249
Checking tyre pressures (using the kit)

..............................
........ 260, 267
Checks
...............

................... 243, 244, 250 -252
Checks, routine

.....................................2

50-252
Child lock

...............................
................180, 181
Children
...............................

...........173 , 175 -178
Children (safety)
...............................

.....180, 181
Child seats

.............1
60, 166, 167, 171-173, 179
Child seats, conventional

..............................17

2
Child seats, ISOFIX

...............................17

5 -178
Cigar lighter

...............................
....................112
Citroën Localised Emergency Call

.......15

0, 152
Closing the boot

...............................
......... 65, 81
Closing the doors

.......................... 6
5, 71, 72, 80
Configuration, vehicle
......................... 1

6, 47, 53
Connection, Bluetooth
..........................3

64, 365
Connection, MirrorLink
.........................3

54, 356
Control, electric windows

................................ 87
C

ontrol, emergency boot release
...................8

2
Control, emergency door
.......................... 6

8, 74
Control, heated seats

......................................95
C

ontrols, steering mounted
.................. 3
16, 379
Control stalk, lighting

............................ 1
28, 131
Control stalk, wipers

...................... 1
37, 138, 141
Courtesy lamps

..................................... 1
33, 142
Cruise control
........................................ 21

3, 218
Cup holder

...............................
......................115
C B

408
Alphabetical index
DS4_en_Chap11_index-alpha_ed01-2016
Key ................................................ 70, 72, 76, 77
Key, electronic .............................. 70 -72, 74, 190
Keyless Entry and Starting

................. 7
0, 73, 77
Key not recognised

....................................... 19

0
Key with remote control

.................... 6
4, 65, 186
Kit, hands-free
............................. 3

64, 365, 390
M
K
Maintenance, routine ...................................... 10
M ap reading lamps ....................................... 14
2
Markings, identification
................................. 3

08
Massage function

...............................
............96
Mat
.......

......................................................... 11 9
Memorising a speed

............................... 5
3, 213
Menu
.................................... 3

18, 320, 324, 332,
334, 336, 346, 348, 350, 360, 362
Menu, main

..............................
.....................380
Menus (audio)

.............................. 3
32, 334, 336
Menus (Touch screen tablet)

................3

13, 317
Mirror, rear view

............................................ 10

2
Mirrors, door.................................. 10 0, 101, 210
Misfuel prevention
...............................

..........229
Mountings, Isofix
...............................

............175
MP3 CD

................
.................................385, 386
Kit, puncture repair .......................................
26
0
Kit, temporary puncture repair
.............. 2
60, 267
Labels, identification
..................................... 3

08
Lamp, boot

...............................

............. 123, 144
Lamps, parking
............................................. 13

1
Lane Departure Warning System (LDWS)
....................................................... 20

9
Level, brake fluid

........................................... 24

6
Level, Diesel additive

.................................... 24

9
Level, engine coolant

.................................... 2

47
Level, engine oil

...............................

....... 33, 245
Level, power steering fluid

............................ 24

6
Levels and checks

......................... 24

3-247, 249
Lighting, cornering
...............................

......... 13 6
Lighting, dashboard
........................................ 45
L

ighting dimmer

..............................

.... 14, 15, 45
Lighting, directional
....................................... 13

5
Lighting, guide-me home

...................... 13

1, 132
Lighting, interior
.................................... 14

2, 143
Lighting, mood
..............................

................ 143
Lighting, welcome

......................................... 13

3
Loading
..............................

..................... 10, 240
Load reduction mode

.................................... 23

9
Localised Assistance Call

..................... 15

0, 152
Locating your vehicle

................................ 6

7, 73
Locking
............................................................ 77
L

ocking from the inside

................................... 78
L

ong objects, transporting

............................ 12

1
Low fuel level

..............................

.................. 227
I
L
J
Jack ....................................................... 271, 342
Jump starting .............................. ..................293
Ignition
................

................................... 188, 191
Ignition on...................................................... 191
Immobiliser, electronic
............................ 7
7, 186
Indicator, AdBlue
® range ................................. 37
I
ndicator, engine oil level .......................... 3 3, 43
Indicator lamps, operation

........................ 1
7, 26
Indicator lamps, status

.................................... 26
I

ndicators, direction
.............................. 1
30, 281
Inflating tyres

..............................
............ 10, 308
Inflating tyres and accessories (using the kit)

..............................
........ 260, 267
Input, auxiliary
...............................

................388
Instrument panels
..........................1

4-16, 43, 46
Intelligent Traction Control
............................ 15

5
ISOFIX
...............

................................... 176 , 17 7
Isofix mountings
...............................

.............175
Navigation
...............................

...... 318, 320, 324
Number plate lamps

......................................28

6
Oil change

...............................
......................245
Oil consumption

............................................24

5
OIl, engine
...............................

......................245
Opening the bonnet

......................................2

42
Opening the boot

..............................
........ 70, 81
Opening the doors

...............................
..... 70, 80
N
O
