Page 7 of 421
5
DS4_en_Chap00b_vue-ensemble_ed01-2016
Interior
Boot fittings 122-124
- r ear parcel shelf
-
h
ooks
-
1
2 V socket
-
torch
-
l
ashing eyes
Rear seats
9
8 -99
Rear fittings
1
21
-
1
2 V socket
-
r
ear armrest
-
s
ki flap
Child seats
1
66 -179
ISOFIX mountings
1
75 -179Front seats
9
2-97
Seat belts
1
57-160
Airbags
16
1-165
Glove box
1
12
Deactivating the passenger's front airbag
1
63, 168 -170
Front fittings
1
12-113, 115 -120
-
a
uxiliary socket / USB port
-
1
2 V socket
-
f
ront armrest
-
2
30 V / 50 Hz socket
-
m
ats
-
s
torage drawersPanoramic windscreen
1
14
-
b
linds
-
s
un visor
Over view
Page 28 of 421
26
DS4_en_Chap01_instruments-de-bord_ed01-2016
Warning/indicator lampis on Cause Action/Observations
Electric parking
brake fixed.
The electric parking brake is applied. Release the electric parking brake to switch off the
warning lamp: with your foot on the brake pedal, pull
the electric brake control.
Observe the safety recommendations.
For more information on the Electric parking brake ,
refer to the corresponding section.
Deactivation of
the automatic
functions of the
electric parking
brake fixed.
The "automatic application" (on
switching off the engine) and
"automatic release" functions are
deactivated or faulty. Activate the function (depending on the country of
sale) via the vehicle configuration menu or contact a
CITROËN dealer or a qualified workshop.
Passenger's
airbag system fixed in the seat belt
and passenger's front
airbag warning lamps
display. The control switch, located in the
glove box, has been placed in the
"ON"
position.
The passenger's front airbag is
activated. In this case, do not install a rear ward facing child seat
on this seat.
Move the control switch to the "OFF"
position to
deactivate the passenger's front airbag. In this case,
you can install a rear ward facing child seat, unless
there is a fault with the airbags (airbag warning
lamp
on).
Passenger's
airbag system fixed in the instrument
panel and/or seat belt
and front passenger's
airbag warning lamps
display. The control switch, located in the
glove box, is set to the OFF
position.
The passenger's front airbag is
deactivated. You can install a rear ward facing child seat, unless
there is a fault with the airbags (airbag warning
lamp
on).
Set the control to the "ON" position to activate the
passenger's front airbag. In this case, do not install a
rear ward facing child seat on this seat.
01
Instruments
Page 114 of 421
11 2
DS4_en_Chap03_ergonomie-et-confort_ed01-2016
Illuminated glove box
It has dedicated locations for storing a water
bottle, the vehicle's handbook pack...
Its lid has locations for storing a pen, a pair of
glasses, tokens, maps, a cup...
F
T
o open the glove box, raise the handle.
The glove box is illuminated when the lid is
opened.
It gives access to the passenger's front airbag
deactivation switch A.
Front fittings
The connection of an electrical device
not approved by CITROËN, such as a
USB charger, may adversely affect the
operation of vehicle electrical systems,
causing faults such as poor telephone
reception or inter ference with displays
in the screens.
F
T
o use the cigarette lighter, press it in and wait
a few seconds until it pops out automatically.
F
T
o connect a 12 V accessory
(max power:
120 W), remove the cigarette
lighter and connect a suitable adaptor.
You can use this socket to connect a telephone
charger, a bottle warmer...
After use, put the cigarette lighter
back into
place straight away.
Cigarette lighter / 12 V accessory socket
03
Ease of use and comfort
Page 164 of 421
162
Front airbags
System which protects the driver and front
passenger in the event of a serious front impact
in order to limit the risk of injury to the head and
thorax.
The driver's airbag is fitted in the centre of the
steering wheel; the front passenger's airbag is
fitted in the dashboard above the glove box.
Deployment
The airbags are deployed, except the
passenger's front airbag if it is deactivated, in
the event of a serious front impact to all or part
of the front impact zone A, in the longitudinal
centreline of the vehicle on a horizontal plane
and directed from the front to the rear of the
vehicle.
The front airbag inflates between the thorax
and head of the front occupant of the vehicle
and the steering wheel, driver's side, and the
dashboard, passenger's side to cushion their
for ward movement.
05
Safety
Page 273 of 421
271
DS4_en_Chap08_en-cas-de-panne_ed01-2016
Spare wheelProcedure for changing a wheel with a damaged or punctured tyre for the spare wheel, using the tools supplied with the vehicle.
The tools are installed in the boot under the
f l o o r.
To gain access to them:
F
o
pen the boot,
F
r
aise the floor,
F
s
ecure it by hooking its cord on the hook
on the rear shelf support,
F
w
ith a standard size spare wheel, unclip
and remove the box in the middle of the
wheel containing the tools,
or
F
w
ith a "space-saver" spare wheel; lift the
wheel at the rear towards you for access to
the storage box containing the tools.
Access to the tools
1. Wheelbrace. F or removing the wheel trim and the wheel
fixing bolts.
2.
J
ack with integral handle.
F
or raising the vehicle.
3.
B
olt cover removal tool.
F
or removing the bolt head protectors on
alloy wheels.
4.
S
ocket for the security bolts (located in the
glove box).
F
or adapting the wheelbrace to the special
"security" bolts. All of these tools are specific to your
vehicle and can vary according to
equipment.
Do not use them for any other
purposes.
The jack must only be used to change
a wheel with a damaged or punctured
tyre.
Do not use any jack other than the one
supplied with this vehicle.
If the vehicle does not have its original
jack, contact a CITROËN dealer or a
qualified workshop to obtain the correct
jack for it.
The jack meets European standards,
as defined in the Machinery Directive
2006/42/CE.
The jack does not require any
maintenance.
List of tools
08
In the event of a breakdown
Page 292 of 421
290
DS4_en_Chap08_en-cas-de-panne_ed01-2016
Fuse N°Rating Functions
F8 3 AAlarm siren, alarm ECU.
F13 10 ACigarette lighter / Front 12 V socket.
F14 10 A12 V socket in boot.
F16 3 ALighting for the large multifunctional storage unit, rear map
reading lamps, glove box illumination.
F17 3 ASun visor illumination, front map reading lamps.
F28 15 AAudio system, radio (after-market).
F30 20 ARear wiper.
F32 10 AHi-Fi amplifier.
Fusebox 2 Fuse N° Rating Functions
F36 15 ARear 12 V socket.
F37 -Not used.
F38 -Not used.
F39 -Not used.
F40 25 A230 V / 50 Hz socket.
Fuse tablesFusebox 1
08
In the event of a breakdown
Page 409 of 421
407
Alphabetical index
DS4_en_Chap11_index-alpha_ed01-2016
DAB (Digital Audio Broadcasting) -
Digital radio .........................3 40, 341, 383, 384
Date (setting)
...............................
.............. 47, 55
Daytime running lamps
................. 1
31, 280, 283
Deactivating the passenger airbag
............... 16
2
Deadlocking
...............................
............... 66, 72
Defrosting
...............................
...............1 0 0 , 111
Dimensions
..............................
.....................307
Dipstick
................
.................................... 33, 245
Direction indicators
....... 1
30, 131, 280, 281, 285
Display screen, instrument panel
............................................... 1
4, 15, 203
Display screen, multifunction (with audio system)
....................................... 47
D
oors
..............................................................
.80
Doors, rear
...............................
.....................181
Drawer, storage
...............................
..............120
Driving economically ....................................... 10
Driving positions (storing)
...............................97
D
ynamic stability control (DSC)
....................15
5Filling the fuel tank
........................ 2
27, 229, 230
Filter, air
...............
.........................................250
Filter, oil
......................................................... 25
0
Filter, particle
........................................ 2
49, 250
Filter, passenger compartment
..................... 25
0
Fitting a wheel
...............................
................275
Fitting roof bars
.............................................24
0
Fittings, boot
.................................................12
2
Fittings, interior
............................................. 11
2
Fittings, rear
...............................
...................121
Flap, fuel filler
...............................
......... 227, 229
Flashing indicators
................ 1
30, 131, 281, 283
Foglamps, front
.....................1
29, 136, 280, 284
Foglamps, rear
.............................. 1
29, 285, 287
Frequency (radio)
..................................33
8, 339
Fuel .......................................................... 10, 230
Fuel consumption
............................................ 10
F
uel tank................................................ 227, 229
Fusebox, dashboard
..................................... 28
8
Fusebox, engine compartment
..................... 28
8
Fuses
................
.............................................288
E D
FGEco-driving ...............................
......................10
Eco-driving (advice) ........................................ 10
E
conomy mode
...............................
..............239
Electronic brake force distribution (EBFD)
...............................
.........................15 4
Emergency braking assistance (EBA)
..............................
....................15 4, 155
Emergency braking system
..........................15
5
Emergency call
..................................... 15
0, 152
Emergency warning lamps
........................... 14
9
Emissions control system, SCR
.....................25 G
auge, fuel....................................................
227
Gearbox, automatic
........ 1
0, 198, 206, 251, 292
Gearbox, manual
.................... 1
0, 197, 206, 251
Gear efficiency indicator
...............................
20
3
Gear lever
..............................
.........................
10
Gear lever, automatic gearbox
.....................
19
8
Gear lever, manual gearbox
.........................
19
7
Glove box
......................................................
11
2
Guide-me-home
...............................
.............
132
H
Hazard warning lamps .................................. 14 9
Hazard warning lamps, automatic operation
...............................
......................149
Headlamp adjustment
................................... 13
4
Headlamps, automatic illumination
...............................
........... 128, 132
Headlamps, dipped beam
..................... 2
80, 282
Headlamps, directional
................. 1
34, 135, 280
Headlamps, halogen
..................................... 28
0
Headlamps, main beam
........................ 2
80, 282
Headlamps, Xenon
....................................... 28
0
Headlamp wash
............................................ 13
9
Head restraints, front
...................................... 94
H
ead restraints, rear
....................................... 98
H
eating
................
.................................... 10, 104
Hill start assist
............................................... 2
02
Hooks
...............................
.............................12 2
Energy economy mode
.................................
23
9
Engine compartment
............................ 2
43, 244
Engine, Diesel
...................... 2
30, 244, 298, 305
Engine, petrol
................................2
30, 243, 303
Engines
..............................
.......... 302, 303, 305
Environment
...............................
...............
10, 77
