isofix CITROEN DS4 2023 Owners Manual

11 6
General points relating to
child seats
The regulations on carrying children are
specific to each country. Refer to the
legislation in force in your country.
For maximum safety, please obser ve the
following recommendations:
-

i

n accordance with European regulations,
all children under the age of 12 or less
than one and a half metres tall must
travel in approved child seats suited to
their weight , on seats fitted with a seat belt
or ISOFIX mountings,
-

s
tatistically, the safest seats in your
vehicle for carr ying children are the rear
seats,
-

a c
hild weighing less than 9 kg must
travel in the rear ward facing position
both in the front and in the rear. It is recommended
that children travel on
the rear seats of your vehicle:
-
re
arward facing
up to the age of 3,
- fo rward facing
over the age of 3.
Child seat at the rear
"Rearward facing"
When a "rear ward facing" child seat is installed
on a rear passenger seat , move the vehicle's
front seat for ward and straighten the backrest
so that the rear ward facing child seat does not
touch the vehicle's front seat.
"Forward facing"
When a "for ward facing" child seat is installed
on a rear passenger seat , move the vehicle's
front seat for ward and straighten the backrest
so that the legs of the child in the for ward
facing child seat do not touch the vehicle's front
seat.
Ensure that the seat belt is correctly
tensioned.
For child seats with a support leg, ensure
that this is in firm contact with the floor. If
necessary, adjust the passenger seat.
05
Safety

122
Recommended child seats
Group 0+: from bir th to 13 kgL1
"RÖMER Baby-Safe Plus"
Installed in the rearward facing position. Groups 2 and 3: 15 – 36 kg
L5
"RÖMER KIDFIX XP"
Can be fitted to the vehicle's ISOFIX mountings.
The child is restrained by the seat belt. Groups 2 and 3: 15 – 36 kg
L6
"GRACO Booster"
The child is restrained by the seat belt.
05
Safety

124
(a)Universal child seat: child seat that
can be installed in all vehicles using
the seat belt.
(b) Group 0: from birth to 10 kg. Infant
car seats and "car cots" cannot be
installed on the front passenger seat.
(c) Refer to the current legislation in your
country before putting your child in
this seat.
(d) To install a child seat at the rear,
rear ward or for ward facing, move the
front seat for ward, then straighten the
backrest to allow enough room for
the child seat and the child's legs.
U: seat suitable for the installation of
a child seat secured using the seat
belt and universally approved for
"rearward facing" and/or "forward
facing" use.
U(R1): identical to U , with the vehicle's seat
backrest inclined fully forwards.
U(R2): identical to U , with the vehicle's seat
adjusted to the highest position.
X: seat not suitable for the installation
of a child seat of the weight group
indicated. Remove and stow the head restraint
before installing a child seat with a
backrest on a passenger seat. Refit the
head restraint once the child seat has
been removed."ISOFIX" mountings
Your vehicle has been approved in accordance
with the latest ISOFIX regulation
.
The seats, represented below, are fitted with
regulation ISOFIX mountings:
There are three rings for each seat:
-

t
wo rings A , located between the vehicle
seat back and cushion, indicated by a
marking,
05
Safety

125
- a ring B, behind the seat and identified by
a marking, referred to as the TOP TETHER
for fixing the upper strap.
This ISOFIX mounting system provides fast,
reliable and safe fitting of the child seat in your
vehicle.
The ISOFIX child seats are fitted with two
latches which are secured on the two rings A .
Some seats also have an upper strap , known
as the Top Tether, which is attached to ring B .
To secure the child seat to the TOP TETHER :
-

r
emove and stow the head restraint before
installing the child seat on the seat (refit it
once the child seat has been removed),
-

r
aise the carpet cover to expose the TOP
TETHER,
-

p
ass the upper strap of the child seat behind
the seat backrest, between the apertures
for the head restraint rods, When fitting an ISOFIX child seat to the
left-hand rear seat, before fitting the
seat, first move the centre rear seat belt
towards the middle of the vehicle, so
as to avoid the seat inter fering with the
operation of the seat belt.
The incorrect installation of a child seat in
a vehicle compromises the protection of
the child in the event of an accident.
Strictly obser ve the fitting instructions
provided with the child seat.
For information on the possibilities for
installing ISOFIX child seats in your
vehicle, refer to the summary table.
Also consult the installation notes of the
child seat’s manufacturer to find out how
to install and remove the seat.
-
f
ix the hook of the upper strap to the ring B
,
-
t
ighten the upper strap.
"RÖMER Baby- Safe Plus and its ISOFIX
base"
(size category: E )
Group 0+: from bir th to 13 kg
Installed rearward-facing using an ISOFIX base which is attached to rings A .
The base has a height adjustable support leg that rests on the vehicle's floor.
This child seat can also be secured with a
seat belt. In this case, only the shell is used and attached to the vehicle seat using the three-point seat belt.
Recommended ISOFIX child
seats
05
Safety

126
Baby P2C Mini and its ISOFIX base(size categories: C, D, E )
Group 0+: from bir th to 13 kg
Installed rearward-facing using an ISOFIX base which is attached to rings A .
The base has a height adjustable support leg that rests on the vehicle's floor.
This child seat can also be secured with the seat belt.
In this case only the seat shell is used and is attached to the vehicle's seat by the three-point seat belt. RÖMER Duo Plus ISOFIX
(size category: B1 )
Group 1: 9 –18 kg
Installed only in the forward-facing position. Attached to the rings A and the ring B ,
referred to as the TOP TETHER, using an upper strap.
Three seat body angles: sitting, reclining, lying.
This child seat can also be used on seats not equipped with ISOFIX mountings. In
this case, it must be secured to the vehicle's seat by the three-point seat belt. Adjust the
position of the vehicle's front seat so that the child's feet are not touching the backrest. Baby P2C Midi and its ISOFIX base
(size categories: D, C, A, B, B1 )
Group 1: 9 –18 kg
Installed rearward-facing using an ISOFIX base which is attached to rings A .
The base has a height adjustable support leg that rests on the vehicle's floor.
This child seat can also be used for ward facing.
This child seat cannot be secured with a seat
belt.
We recommend that you use the seat in the rear ward facing position up to the age of 3
years.
05
Safety

127
Summary table of locations for ISOFIX child seats
In line with European regulations, this table indicates the options for installing ISOFIX child seats on seats in the vehicle fitted with ISOFIX mountings.
In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from A to G, is indicated on the child
seat next to the ISOFIX logo.
Weight of the child/indicative age
Under 10 kg (group 0)
Up to about 6
monthsUnder 10 kg
(group 0)
Under 13 kg (group 0+)
Up to about 1 year From 9 to 18 kg (group 1)
From about 1 to 3 years
Type of ISOFIX child seat Cot* rearward facing rearward facing forward facing
ISOFIX size categor y F G C D E C D A B B1
Universal and semi-universal ISOFIX child seats which can be installed on the outer rear seats IL- SU
** IL- SU IL- SU IUF
IL- SU
I UF: seat suitable for the installation of
an Isofix U niversal seat, " For ward
facing", secured using the top tether.
IL- SU:
seat suitable for the installation of an
I sofix S emi-Universal seat which is either:
-

"
rear ward facing" fitted with an upper
strap or a support leg,
-

f
or ward facing fitted with a support
leg,
-

a
n infant car seat fitted with an upper
strap or a support leg.
For advice on securing of the upper strap, refer
to the "ISOFIX mountings" section.
Remove and stow the head restraint
before installing a child seat with backrest
on a passenger seat. Refit the head
restraint once the child seat has been
removed. *

I
nfant car seats and "car cots" cannot be
installed in the front passenger seat.
**

T
he ISOFIX cot, secured to the lower rings
of an ISOFIX seat, occupies all of the space
on the rear bench seat.
05
Safety

223
ABS ...............................................................108
