sensor Citroen DS4 RHD 2011.5 1.G Owner's Manual

SAFETY DRIVING FITTINGS CHILD SAFETY
192Electric parking brake
200 Manual parking brake
201 Manual gearbox
202Gear effi ciency indicator
203 6 -speed electronic gearboxsystem
207 Automatic gearbox
211 Hill start assist
212Stop & Start
215 Blind spot sensors
219 Speed limiter
221Cruise control
223Parking space sensors
225 Parking sensors
172 Direction indicators
172 Hazard warning lamps
173 Horn
173 Emergency or assistance call
174 Tyre under-infl ation detection
176Braking assistance systems
17 7 Tr ajectory control systems(ESP)
179Front seat belts
183Airbags
160Child seats
166 ISOFIX child seats
169 Child lock
14 4 Interior fi ttings
15 0Front armrest
15 4Boot fi ttings
008008009009006006007007

Exterior
Parking sensors
This system measures the size of a free parking space between two vehicles or obstacles.
Stop & Start system
This system puts the engine temporarily into standby during stops in the traffic (traffic lights, traffic jams, etc...). The engine
restarts automatically as soon as you want to move off. The Stop & Start system reduces fuel consumption and exhaust emissions, as well as noise levels when stationary.
223

Directional lighting

This lighting automatically provides
additional visibility when cornering.
13
1
Panoramic windscreen
This large glazed area provides
incomparable visibility and light in the passenger compartment.
12

Cornering lighting

At low speed, this lighting comes on
automatically to improve vision when cornering, at intersections, when parking...
making use of the front foglamp on the sidein question.
132

9Familiarisation
Exterior


Welcome lighting

This additional exterior and interior lighting, controlled remotely, makes your approach to
the vehicle easier when the light is poor.
Temporary puncture repair kit

This kit is a complete system, consisting of acompressor and a sealant car tridge, for the
temporary repair of a tyre.
129

Under-infl ation detection
This system continuously monitors the pressure
in each tyre and warns you in the event of a
puncture or under-inflated tyre.
174
Blind spot sensors
In cer tain conditions, this system
detects the presence of a vehicle in
the blind spot. It informs you by means
of a warning lamp in the corresponding door mirror.
215

100
Opening
A.
Folding/unfolding the key
(first press this button).
3-button remote
control

When a sensor detects a low level of light,
the remote switching on of the dipped beam headlamps, the sidelamps and the side spotlamps makes your approach to the vehicle easier.

Welcome lighting
Complete or selective unlocking of
the vehicle(rapid flashing of the direction
indicators).
Opening the windows (hold until the desired position is reached).
Selective unlockin
g of the boot.Normal lockin
g
(press once; fixed lighting of the
direction indicators).
Closin
g the windows(hold until the desired position is reached).
129 In the same wa
y, the passenger compartment
lighting, such as the cour tesy lamps and the
footwell lamps, comes on.

15
Familiarisation
Instruments and controls
1.
Steering wheel adjustment control. 2.Steering mounted control paddles for the
6 -speed electronic gearbox system.
3.Lighting and direction indicator controlstalk.4. Speaker (tweeter).
5. Windscreen demisting vent.
6.Sunshine sensor. 7. Passenger’s airbag. 8.Glove box/Audio/video sockets/Passenger’s airbag deactivation switch/Fusebox.9.
Bonnet release. 10.Heated seat control. 11.
Lumbar massage control. 12.
Electric parking brake. 13.Gear lever, 6 -speed electronic gearbox system.14 .Large multifunctional storage unit.

Sitting comfortably
Door mirrors
Adjustment
A.
Selection of the mirror to be adjusted. B. Adjustment of the position of the mirror in
th
e four directions.
C. De-selection of the mirror.
94

Other functions available...

Folding/Unfolding. Automatic tilting of the mirror in reversegear for parking.
Blind spot sensors.



Rear view mirror


Manual day/night model
1.Selection of the "day" position of the mirror.
2. Adjustment of the mirror.


Automatic day/night model
96
A.
Brightness detection in automatic day/night
mode. B. Adjustment of the mirror.1.
Fastening the buckle.2.Height adjustment.


Front seat belts
179

Monitoring
Illumination of the warning lamp indicates the state of the system.
Side switch panel
17 7
B.Deactivate the parking sensors.
225
C.
Deactivate the Stop & Start system.
212
D.Activate blind spot monitoring.
215
E.
Activate the electric child lock.
169
F.Deactivate the volumetric alarm protection.
11
0
A.
Deactivate the ESP/ASR system.

25
Familiarisation

Cruise control/speed limiter controls


Steering wheel with
integrated controls
60
Optional functions controls
219, 221
59
2.
Dashboard lighting dimmer.
298, 349

Audio system controls
298, 349


Bluetooth system or telephonecontrols
1.Black panel (black screen).
40
or
Control of the type 2 instrument panel central screen.
13
8
3. Cour tesy lamp on/off.

223
or
Parking space sensors.

Monitoring

Driving safely
)Activate the function by pressing control switch A; the button’s warning lampcomes on.
Blind spot sensors
215 The warning lamp located in the door mirro
r comes on to warn you that a vehicle has arrived
in the blind spot detection zone.
) Select the function by pressing controlswitch B; the corresponding warning lamp comes on in the instrument panel.)
Operate the direction indicators on the side
with the space to be measured; a messa
ge
appears to confirm measurement is in
pro
gress. ) Drive at a speed below 12 mph (20 km/h) during measurement.


Parking space sensors
One of these messages appears to indicate the
level of difficulty of the manouevre:


-
Parking possible.
223
-Parking difficult.

-
Parking not advised.

Lighting dimmer fixed. The lighting dimmer is making an
adjustment. You can adjust the level of illumination of the
instruments between 1 and 16.
Passenger's airbag systemfixed in the seat beltand passenger's front airbag warning lamps
display.
The control switch, located in the glove
box, has been placed in the "ON"
position.
The passen
ger's front airbag is activated.
In this case, do not install a "rear facing"child seat.
Move the control switch to the "OFF"
position
to deactivate the passenger's front airbag.
In this case, you can install a "rear facing" child seat.


Automatic wiping

fixed. The wiper control is pushed
downwards. Automatic front wipin
g is activated.
To deactivate automatic wipin
g, operate the control stalk downwards or put the stalk into another position.
Warning lampis onCauseAction/Observations
Stop & Startfixed. When the vehicle stops (red lights,
traffic jams, ...) the Stop & Star t system has put the engine into STOPmode.The warnin
g lamp goes off and the engine restarts
automatically in START mode, as soon as you want
to move off.
fl
ashes for a few seconds, then goesoff. STOP mode is temporaril
y unavailable. or STA R T mode is invokedautomatically. Refer to "Drivin
g - § Stop & Star t" for special cases
with STOP mode and STA R T m o d e .
Parking space sensorsfixed.The parking space sensors function
is selected.To star t measurement, operate the direction indicator
on the side of the space to be measured, and do notexceed 12 mph (20 km/h). A message is displayed
once t
he measurement has been completed.
