9Familiarisation
Exterior


Welcome lighting

This additional exterior and interior lighting, controlled remotely, makes your approach to
the vehicle easier when the light is poor.
Temporary puncture repair kit

This kit is a complete system, consisting of acompressor and a sealant car tridge, for the
temporary repair of a tyre.
129

Under-infl ation detection
This system continuously monitors the pressure
in each tyre and warns you in the event of a
puncture or under-inflated tyre.
174
Blind spot sensors
In cer tain conditions, this system
detects the presence of a vehicle in
the blind spot. It informs you by means
of a warning lamp in the corresponding door mirror.
215

Customisable colour instrument panel - Type 1
1.
Rev counter (x 1 000 rpm or tr/min). 2.
Gear efficiency indicator with manualgearbox or gear lever position and gear for
the electronic gearbox system.3.Analogue speedometer (mph or km/h). 4. Cruise control or speed limiter setting. 5.
Digital speedometer (mph or km/h).
6
.Engine oil level indicator.
Dials and screens
Control buttons
7.Ser vice indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed successively on switching on the ignition.
Lighting dimmer setting (when making an
adjustment).
8. Tr i p m i l e age recorder (miles or km).9.Fuel gauge and associated low fuel
warning lamp.
10. Range (miles or km).
A.Dial COLOUR: customisation of the
background colour of the dials. B.Screen COLOUR: customisation of thebackground colour of the screens.
C.Lighting dimmer (available in night mode).D. Reminder of the ser vicing information
Reset the service indicator or the trip
mileage recorder.

39Monitoring
1. Rev counter (x 1 000 rpm or tr/min). 2.Gear efficiency indicator with manualgearbox or gear lever position and gear for
the electronic gearbox system or automaticgearbox. 3.Speedometer (mph or km/h).4. Central screen.
5. Fuel gauge and associated low fuel level
warning lamp.
Dials and screens
6.
Tr i p m i l e age recorder (miles or km).7.
Ser vice spanner (if a ser vice is due or
missed),
total mileage recorder. (miles or km)




Control buttons




















Customisable colour instrument panel - Type 2
A.Dial COLOUR: customisation of the
background colour of the dials. B. Screen COLOUR: customisation of the
background colour of the screens.C. Dashboard lighting dimmer (in night mode).D.Star t a manual test (procedure for checking
the status of systems and display of vehicle
alerts).
Reset service indicator or trip mileage
recorder.

Warning lampis onCauseAction/Observations
Left-hand
direction indicator

flashing with buzzer. The lighting stalk is pushed down.
Right-handdirection indicator

flashing with buzzer. The lighting stalk is pushed up.



Sidelamps
fixed. The lighting control is in the"Sidelamps" position.
On vehicle where the daytime running lamps are deactivated,
if the lighting control is in the "AUTO" position, the sidelampscome on as a luminous signature of the vehicle.


Dipped beam headlamps
fixed. The lighting stalk is in the "Dipped beam
headlamps" position or in the "AUTO"
position in conditions of low li
ght.



Main beamheadlamps

fixed. The lighting stalk is pulled towards you. Pull the stalk again to return to dipped beam
headlamps.
Front foglamps
fixed. The front foglamps are switched on. Turn the ring on the stalk rear wards twice to switch off
the front foglamps.
Rear foglamps fixed. The rear foglamps are switched on. Turn the ring on the stalk rear wards to switch off the rear foglamps.
Hazard warninglamps flashing with audible
signal. The hazard warning lamps switch, located on the dashboard, has beenoperated. The le
ft-hand and right-hand direction indicators and
their associated indicator lamps flash simultaneously.
Operation indicator lamps
If one of the following indicator lamps comes on, this confirms that the corresponding system has come into operation.
It may be accompanied by an audible signal and a message on the multifunction screen.

Lighting dimmer fixed. The lighting dimmer is making an
adjustment. You can adjust the level of illumination of the
instruments between 1 and 16.
Passenger's airbag systemfixed in the seat beltand passenger's front airbag warning lamps
display.
The control switch, located in the glove
box, has been placed in the "ON"
position.
The passen
ger's front airbag is activated.
In this case, do not install a "rear facing"child seat.
Move the control switch to the "OFF"
position
to deactivate the passenger's front airbag.
In this case, you can install a "rear facing" child seat.


Automatic wiping

fixed. The wiper control is pushed
downwards. Automatic front wipin
g is activated.
To deactivate automatic wipin
g, operate the control stalk downwards or put the stalk into another position.
Warning lampis onCauseAction/Observations
Stop & Startfixed. When the vehicle stops (red lights,
traffic jams, ...) the Stop & Star t system has put the engine into STOPmode.The warnin
g lamp goes off and the engine restarts
automatically in START mode, as soon as you want
to move off.
fl
ashes for a few seconds, then goesoff. STOP mode is temporaril
y unavailable. or STA R T mode is invokedautomatically. Refer to "Drivin
g - § Stop & Star t" for special cases
with STOP mode and STA R T m o d e .
Parking space sensorsfixed.The parking space sensors function
is selected.To star t measurement, operate the direction indicator
on the side of the space to be measured, and do notexceed 12 mph (20 km/h). A message is displayed
once t
he measurement has been completed.

) Press the closed padlock on the remote control.
This will switch on the cour tesy lamps and the direction indicators will flash for a few seconds.
Locating your vehicle
This function allows you to identify
your vehicle from a distance,particularly in poor light. Your vehicle must be locked.
Anti-theft protection

Electronic engine immobiliser
The key contains an electronic chip which has
a special code. When the ignition is switched
on, this code must be recognised in order for star ting to be possible.
This electronic engine immobiliser locks theengine management system a few minutes
after the ignition is switched off and prevents starting of the engine by anyone who does nothave the key.
In the event o
f a fault, you are
informed by illumination of this
warning lamp, an audible signal
and a messa
ge in the screen.
In this case, your vehicle will not start; contact
a CITROËN dealer as soon as possible.
Folding the key
)First press this button to fold the key.
If you do not press the button when folding the key, there is a risk of damage to the mechanism.

Keep safely the label attached to the keys given to you on acquisition of the vehicle.

127Visibility

Switching off the lighting when switching off the ignition

When the ignition is switched off, allof the lamps switch off immediately, except for the dipped beam headlamps if automatic guide-me-home lighting is activated.
Temporarily keeping the dipped beamheadlamps on after the vehicle's ignition has been switched off makes the driver's exit easier when the light is poor.
Switching on
)
With the ignition off, "flash" the headlamps using the lighting stalk.)
A further "headlamp flash" switches thefunction off.

Switching off
The manual guide-me-home lighting switches
o
ff automatically after a set time.
Manual guide-me-home
lighting

Switching on the lightingwhen switching on the ignition
To reactivate the lighting control stalk, turnthe ring Ato position A"0"
- lighting off, then to the position of your choice.
If the lighting is switched on manually after switching off the ignition, there is an audible signal when a front door is opened to warn the driver that they have forgotten to switchoff the vehicle's lighting, with the ignition off.
They switch off automatically after a periodwhich depends on the state of charge of thebattery (entry to energy economy mode).
Parking lamps
Side markers for the vehicle by illumination of
the sidelamps on the traffic side only.) Within one minute of switching off the
ignition, operate the lighting control stalk up
or down dependin
g on the traffic side(for example: when parking on the left;
lighting control stalk upwards; the right hand sidelamps are on).
This is confirmed by an audible signal and
illumination of the corresponding direction
indicator warning lamp in the instrument panel.
To switch o
ff the parking lamps, return the
lighting control stalk to the central position.

When a low level of ambient light is detected by a sunshine sensor, the number plate
lamps, sidelamps and dipped beam headlamps are switched on automatically, without any action on the par t of the driver. They can also come on if rain is detected, at the same time as automatic operation of the windscreen wipers.
As soon as the brightness returns to a sufficient level or after the windscreen wipers are switched off, the lamps are switched off automatically.
Automatic illumination of
headlam
ps
Activation
)
Turn the ring to the "AUTO"
position. The
activation of the function is accompanied
by the display of a message in the screen.


Deactivation
)
Turn the ring to another position.
Deactivation of the function isaccompanied by the display of a message
in the screen.
Automatic "guide-me-
home" li
ghting

Operating fault
In the event of a malfunction of
the sunshine sensor, the lighting comes on, this warning lamp is
displayed in the instrument panel and/or a
message appears in the screen, accompanied by an audible signal.
Contact a CITROËN dealer or a qualified
workshop.
In fog or snow, the sunshine sensor may detect sufficient light. In thiscase, the lighting will not come on automatically.
Do not cover the sunshine sensor,coupled with the rain sensor and located in the centre of the windscreen
behind the rear view mirror; theassociated functions would no longer be controlled.
When the automatic illumination of headlamps
function is activated, under low ambient
li
ght the dipped beams headlamps come on
automatically when the ignition is switched off.

Programming
Activation or deactivation, as well
as the duration of the guide-me-home lighting, is set in the vehicle configuration menu.

131Visibility








Directional lighting


When the dipped or main beam headlamps
are on, this function, allows the light beams to better follow the road.
The use of this function, coupled with the
xenon headlamps and the cornerin
g lighting,
considerably improves the quality of your lighting round bends.
Thi
s function is inactive:


- when stationary or at low speeds,

- when reverse is engaged.

The s
ystem is activated by default. with directional lighting
without directional lighting


Programming
The system is activated or deactivated in the vehicle configuration menu.
The state o
f the system stays in memory onswitching off the ignition.
Contact a CITRO
ËN dealer or a qualified
workshop.

Operating fault
If a fault occurs, this warning lamp
flashes in the instrument panel,
accompanied by a message in the screen.

Direction indicators
)Left: lower the lighting stalk passing thepoint of resistance.)Right: raise the lighting stalk passing the point of resistance.
"Motorway" function
)
Press briefly upwards or downwards,
without going beyond the point of
resistance; the direction indicators will
flash 3 times.










Hazard warning lamps
A visual warning by means of the direction
indicators to alert other road users to a vehicle
breakdown, towing or accident. )Press this button, the direction indicators
fl
ash.
They can operate with the ignition off.

If you forget to cancel the direction indicators for more than twenty seconds, the volume of theaudible signal will increase if the speedis above 40 mph (60 km/h).
