Citroen DS4 RHD 2014.5 1.G Owner's Manual

319
Diesel engineHDi 160BlueHDi 180
Gearbox Manual
(6- speed) Automatic
(6- speed) EAT6 automatic
(6- speed )
Model code:
NX... RHH8
RHH8/1 RHHAAHW T/S
AHW T/1S - /2S
-

U
nladen weight 1 3201 430 1 410
-

K
erb weight* 1 3951 505 1 495
-

G
ross vehicle weight (GV W) 1 8801 940 1 975
-

G
ross train weight (GTW)
o

n a 12 % gradient 3 180
3 1403 275
-

B
raked trailer (within GTW limit)
o

n 12 % gradient 1 300
1 2001 300
-

B
raked trailer** (with load transfer with the
GTW limit) 1 550
1 4501 550
-

U
nbraked trailer 695750 74 5
-

R
ecommended nose weight 757575
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
When towing, the maximum authorised speed is reduced (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
* The kerb weight is equal to the unladen weight + driver (75 kg).
**

T
he weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Technical data

Dimensions (in mm)

321
Identification markingsVarious visible markings for the identification of your vehicle.
A.
V
ehicle identification number (VIN)
under the bonnet.
This number is engraved on the bodywork near
the suspension damper mounting.
B.
Vehicle identification number on the dashboard.This number is indicated on a self-adhesive
label which is visible through the windscreen. D. Tyre/paint label.
This label is affixed to the driver's front pillar.
Low tyre pressures increase fuel
consumption. The tyre pressures must be checked
when the tyres are cold, at least once
a month.
C. Manufacturer's label.
The VIN is indicated on a self-destroying label
affixed to the driver's centre pillar. It bears the following information:
-
t
he tyre pressures, for unladen and laden
conditions,
-
t
he tyre sizes (including the load index and
speed rating),
-
t
he spare tyre inflation pressure,
-
t
he paint colour code.
Technical data

Audio and telematics

325
EMERGENCY OR ASSIST ANCE CALL

EMERGENCY OR ASSIST ANCE CALL
CITROËN Localised Emergency Call
In an emergency, press this button for more than
2 seconds. Flashing of the green LED and a voice
message confirm that the call has been made to the
C
ITROËN Localised Emergency Call centre*.
Pressing this button again immediately cancels the call. The green LED
goes off.
Pressing this button (at any time) for more than 8 seconds cancels
the

call.
CITROËN Localised Assistance Call
When the ignition is switched on, the green
LED comes on for 3 seconds indicating that
the system is operating correctly.
If the orange LED flashes: there is a
system fault.
If the orange LED is on continuously: the
backup battery must be replaced.
In either case, contact a CITROËN dealer.
Pressing this button again immediately cancels the request.
The cancellation is confirmed by a voice message.
Press this button for more than 2 seconds to request
assistance if the vehicle breaks down.
A voice message confirms that the call has been made*.
Operation of the system
The green LED remains on (without flashing) when communication is
established. It goes off at the end of communication.
This call is dealt with by the
C
ITROËN Localised Emergency Call centre
which receives locating information from the vehicle and can send a
detailed alert to the appropriate emergency services. In countries in
which the team is not operational, or when the locating service has
been expressly declined, the call is dealt with directly by the emergency
services (112) without the vehicle location.
If an impact is detected by the airbag control unit, and
independently of the deployment of any airbags, an emergency call
is made automatically.
*

These services are subject to conditions and availability
.


Consult a CITROËN dealer
. If you purchased your vehicle outside the CITROËN dealer network,
we invite you to have a dealer check the configuration of these services
and, if desired, modified to suit your wishes. In a multi-lingual country
,
configuration is possible in the official national language of your choice.
For technical reasons, particularly to improve the quality of Telematic
services to customers, the manufacturer reserves the right to carry out
updates to the vehicle's on-board telematic system.
If you benefit from the CITROËN Connect Box offer, you also have available
additional services in your MyCITROËN personal space, via the CITROËN
Internet website in your country, accessible on www.citroen.com.

327
The system is protected in such a way that it will only
operate in your vehicle.
7-inch touch screen tablet
01 General operation
For safety reasons, the driver must carry out operations
which require prolonged attention while the vehicle is
stationary.
When the engine is switched off and to prevent
discharging of the battery, the system switches off
following the activation of the energy economy mode.
CONTENTS
02

First steps - Control
panel
04
Media
05
Navigation
06
Configuration
07

Connected service
s
08
Telephone p.
p.
p.
p.
p.
p.
p.
Frequently asked questions p.
GPS satellite navigation system
Multimedia audio system
Bluetooth
® telephone
328
330
350 332
370
378
380
390
03

Steering mounted
controls p. 331

01GENERAL OPERATION
* Depending on equipment.
"Driving assistance"
allows access to the trip
computer and certain vehicle
functions to be activated,
deactivated and adjusted. "Media"
allows selection of a radio
station, the various music
sources and the display of
photographs.
"Navigation"*
allows settings for navigation
and the choice of a destination.
"Configuration"
allows sound settings and the
brightness of instruments and
controls to be adjusted. "Connected services
"*
allows connection to an
applications portal to facilitate,
make safe and personalise
journeys by means of a
connection key available on
subscription from a CITROËN
dealer.
"Telephone"
allows the connection of a
mobile telephone via Bluetooth.
