149Visibility








Wiper controls


Programming

Various automatic wiper control modes are also
available according to the following options:


- automatic rain sensitive windscreen wipers,

- rear w
iping on engaging reverse gear.

Manual controls
The wipers are controlled directly by the driver. The vehicle's
front and rear wipers are
designed to improve the driver's visibility
progressively according to the climaticconditions.

Windscreen wipers

Wiping speed:
fast
(heavy rain),
normal
(moderate rain),
intermittent
(proportional to the
speed of the vehicle),
park,
automatic
(press down and
release),
single wipe
(pull the stalk briefly towards you).

Rear wiper
If a significant accumulation of snowor ice is present, or when using a bicycle carrier on the boot, deactivatethe automatic rear wiper via theconfiguration menu.
park,
intermittent wipe,
wash-wipe
(set duration).

Reverse gear

When reverse gear is engaged, the rear wiper
will come into operation if the windscreen
wipers are operating.
Th
e function is activated or
deactivated via the configuration menu.
This function is activated by default.
Programming
)Pull the windscreen wiper stalk towards you. The windscreen wash then the
windscreen wipers operate for a fixed
period.

The headlamp washers only operate when
the dipped beam headlamps are on.
Windscreen and headlamp
wash
Rear wiper selection ring:

151Visibility
Automatic rain sensitive
windscreen wipers
The windscreen wipers operate automatically,
without any action on the par t of the driver, if
rain is detected (sensor behind the rear view mirror), adapting their speed to the intensity of
the rainfall.

Switching on

Briefly push the control stalkdownwards.
This warning lamp comes on in the
instrument panel and a messa
ge is
displayed. Brie
fly push the control stalkdownwards again, or place
the control stalk in another
position
(Int, 1 or 2).
This warning lamp goes off in the instrumentpanel and a message is displayed.
Switching off


The automatic rain sensitive windscreenwipers must be reactivated by pushing the control stalk downwards, if theignition has been off for more than one minute.

Do not cover the rain sensor, linked with the sunshine sensor and located in the centre of the windscreen behind the rear view mirror. Switch off the automatic rain sensitive wipers when using an automatic car wash.
In winter, it is advisable to wait until thewindscreen is completely clear of ice before activating the automatic rainsensitive wipers.
Operating fault
If a fault occurs with the automatic rain
sensitive wipers, the wipers will operate in intermittent mode.
Have it checked by CITROËN dealer or a
qualified workshop.
Special position of the
windscreen wipers
This position permits release of the windscreen
wiper blades.
It is used for cleaning or replacement of the blades. It can also be useful, in winter, todetach the blades from the windscreen.


To maintain the effectiveness of the "flat-blade" type of wiper blades, it is advisable to:


- handle them with care,

- clean them regularly using soapywater,

- avoid using them to retain cardboard on the windscreen,

- replace them at the first signs of wear.


)
Any action on the wiper stalk in the minute
after switching off the ignition places the
blades vertically on the screen.) To park the blades again, switch on theignition and operate the wiper stalk.

153Visibility
1.Front - rear cour tesy lamp2.Front map reading lamps 3.Rear map reading lamp s4.
Interior mood LEDs







Courtesy lamps

In this position, the courtesy lamp comes on gradually:
Front - rear courtesy lamps


Take care to avoid leaving anything in contact with the cour tesy lamps.
With the "permanent lighting" mode, the lighting time varies according to the circumstances: - with the ignition off, approximatelyten minutes,- in energy economy mode, approximatelythirty seconds,- with the engine running, unlimited.

- when the vehicle is unlocked,
- when the electronic key is removed from
the reader,
- when openin
g a door,
- when the remote control locking button is
activated, in order to locate your vehicle.
It switches o
ff gradually:
- when the vehicle is locked,
- when the i
gnition is switched on,
- 30 seconds after the last door is closed.
Permanentl
y off.
Permanent li
ghting.


Front - rear map reading
lamps
)
With the ignition on, press thecorresponding switch.

Interior mood lighting The dimmed passenger compar tment lighting improves visibility in the vehicle when the light is poor.

At night, the interior mood lighting comes onautomatically when the sidelamps are switched
on (for example, a source of light in the roof console illuminates the middle of the centre console).
The interior mood lighting switches off automatically when the sidelamps are switched off. Lamps on: there are 7 levels o
f brightness.
The level of brightness increases progressively
with each press of the button, returning to zero after the maximum level is reached.
A long press gives maximum brightness.
This adjustment is used to set the mood lighting level for the interior lamp, as well as for the door opening controls and the storage locations
(depending on version).






Foot well lighting


Activation

Its operation is identical to that of the cour tesy
lamps. The lighting comes on when one of the
doors is opened. The soft li
ghting provided by the footwell lamps
improves visibility in the vehicle when the light
is poor.
Switching on
Adjusting the brightness
of the courtesy lamp

155
Visibility

006
Child safety

General points relating to child seats
For maximum safety, please obser ve the following recommendations:
- in accordance with European regulations,
all children under the age of 12 or less
than one and a half metres tall must
travel in a
pproved child seats suited to
their weight , on seats fitted with a seat
belt or ISOFIX mountings * ,-
statistically, the safest seats in your
vehicle for carrying children are the rear seats,-a child weighing less than 9 kg must
travel in the "rearwards-facing" position both in the front and in the rear.
CITROËN recommends that childrenshould travel in the outerrrear seatsof your vehicle:-"rearwards-facing"
up to the age of 2,- "forwards-facing"
over the age of 2.

Although one of CITROËN main criteria when designing your vehicle, the safety of your children
also depends on you.

*
The rules for carr
ying children are specific toeach country. Refer to the legislation in force
in your country.
