remote start Citroen DS5 2016 1.G Owner's Manual

002003004
DS5_en_Chap00a_sommaire_ed02-2015
cOMFORT
Ac
cES
SdRIvING
72 Front seats
77
Rea
r seats
80
M

irrors
81
St

eering wheel adjustment
82
Fr

ont fittings
86
Rea

r fittings
87
Bo

ot fittings
88
Tr

iangle (stowing)
89
He

ating and Ventilation
91
Dual

-zone digital air
conditioning
95
Fr

ont demist - defrost
95
Re

ar screen demist - defrost 98 Dr
iving recommendations
100
St

arting / Switching off the
engine
103
El

ectric parking brake
109
Hi

ll start assist
110
Man

ual gearbox
111
Au

tomatic gearbox
115
Ge

ar shift indicator
116
Ty

re under-inflation detection
118
Stop

& Start
122
La

ne departure warning
system
123
Bl

ind spot sensors126 He
ad-up display
128
Mem

orising speeds
130
Speed

limiter
133
Cr

uise control
136
Pa

rking sensors
138
Re

versing camera
52 El
ectronic key - remote
control
54
Ke

yless Entry and Starting
61
Ce

ntral locking
62
Boo

t
63
Alar

m
66
El

ectric windows
68
Co

ckpit glass roof

DS5_en_Chap02_ouvertures_ed02-2015
Electronic key
remote control
Unlocking the vehicle
complete unlockingS elective unlocking
System which permits central unlocking or
locking of the vehicle using the lock or from a
distance. It is also used to locate and start the
vehicle, as well as providing protection against
theft. F
To u

nlock only the driver's door,
press the open padlock once.
Unlocking is confirmed by rapid flashing
of the direction indicators for around
two seconds.
At the same time, depending on
version, the door mirrors unfold. F
To u

nlock the other doors and
the boot, press the open padlock
again.
F
Pr
ess the open padlock to
completely unlock the vehicle.
This setting is done in the vehicle
configuration menu.
Complete unlocking is activated by
default.

DS5_en_Chap02_ouvertures_ed02-2015
Unlocking the vehicle
Keyless Entry and Starting
System that allows the unlocking, locking
and starting of the vehicle while keeping the
electronic key on your person.
complete unlocking
F With the electronic key on your person and
in the recognition zone A , pass your hand
behind one of the door handles to unlock
the vehicle.
Your passengers can also open their doors, as
soon as the electronic key is in the recognition
zone.
Selective unlocking
F To unlock only the drivers door, with the
e lectronic key on your person, pass your
hand behind the driver's door handle.
This setting is done via the vehicle
configuration menu.
By default, complete unlocking is
activated.
Unlocking is confirmed by rapid
flashing of the direction indicators for
approximately two seconds.
The door mirrors unfold at the same
time.
If the alarm is on, the audible warning
triggered when opening a door with the
key (integral with the remote control), will
stop when the ignition is switched
o

n.
It can also be used as a remote control.
For more information, refer to the
"Electronic key / remote control" section.
For reasons of safety and theft protection,
do not leave your electronic key in the
vehicle, even when you are close to it.
It is recommended that you keep it on
your person. F
To u

nlock the complete vehicle, pass your
hand behind one of the passenger door
handles on the same side of the vehicle as
the electronic key is located.

55
DS5_en_Chap02_ouvertures_ed02-2015
Locking the vehicle
F With the electronic key on your person in
the recognition zone A , press with a finger
or thumb on one of the door handles (at the
markings) to lock the vehicle.
F
Ma

intain pressure with your finger or thumb
until the windows close completely.
Locking is confirmed by fixed
lighting of the direction indicators for
approximately two seconds.
The door mirrors fold at the same time. If one of the doors or the boot is still
open or if the key for Keyless Entry and
Starting system has been left inside
the vehicle or if the ignition is on, the
central locking does not take place.
When the vehicle is locked, if it is
unlocked inadvertently, it will lock itself
again automatically after about thirty
seconds unless a door is opened.
If the alarm was previously activated, it
will not be reactivated automatically.
The folding and unfolding of the door
mirrors by the remote control can be
deactivated by a CITROËN dealer or a
qualified workshop.
As a safety measure (children on
board), never leave the vehicle without
taking the key for the Keyless Entry and
Starting system, even for a short period.
Guard against theft when the key for the
Keyless Entry and Starting system is
in the recognition zone with the vehicle
unlocked.
In order to preserve the charge of the
cell battery in the remote control, the
"hands-free" functions go into extended
stand-by after 21 days of non-use. To
restore these functions, press one of
the remote control buttons or start the
engine with the electronic key in the
reader.
Ensure that nothing and no person
prevents the correct operation of the
windows.
Be particularly aware of children when
operating the windows.
This function allows you to identify
your vehicle from a distance,
particularly in poor light. Your vehicle
must be locked.
Locating your vehicle
F Press the closed padlock on the remote
c
ontrol.
This will switch on the courtesy lamps and
the direction indicators will flash for around
ten
sec

onds.
Access

DS5_en_Chap02_ouvertures_ed02-2015
deadlocking
Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
locking button.
You must therefore never leave
anyone inside the vehicle when it is
deadlocked.Using the remote control
F Press the closed padlock to lock
the vehicle completely.
Maintain pressure with your finger to
close the windows.
With Keyless Entry and
Starting
By the doors:
F Wi th the electronic key on your person
in the recognition zone A , press with a
finger or thumb on the door handle (at the
markings) to lock the vehicle.
F
Wi

thin five seconds, press the door handle
again to deadlock the vehicle.
Ensure that nothing or any person
prevents the correct closing of the
windows.
Be particularly aware of children when
operating the windows.
F
Pr

ess the closed padlock again within
five
s

econds to deadlock the vehicle.

57
DS5_en_Chap02_ouvertures_ed02-2015
Back-up key
Unlocking / Locking using the integral key with Keyless
Entry and Starting
The integral key is used to lock and unlock the
vehicle when the electronic key cannot operate:
-
ce
ll battery flat, vehicle battery discharged
or disconnected, ...
-
ve

hicle located in an area with strong
electromagnetic signals.
F
Ma

intain a pull on button 1 , to extract the
integral key 2 .
If the alarm is activated, the audible
signal triggered on opening a door
with the key (integral with the remote
control) will stop when the ignition is
switched on.Locking the driver's
door
F Insert the integral key in the door lock, then
t urn it to the rear.
Unlocking the driver's
door
F Insert the integral key in the door lock, then
turn it to the front.
Access

59
DS5_en_Chap02_ouvertures_ed02-2015
Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
Take them to an approved collection
point.
changing the cell battery
Battery ref.: CR2032 / 3 volts.
This replacement battery is available from a
CITROËN dealer or a qualified workshop.
A message appears in the instrument panel
screen when replacement of the battery is
needed.
F
Un
clip the cover using a small screwdriver
at the cutout.
F
Li

ft off the cover.
F
Re

move the flat battery from its location.
F
Fi

t the new battery into its location
observing the original direction of fitment.
F
Cl

ip the cover onto the casing.
Remote control problem -
reinitialisation
Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction,
you can no longer unlock, lock or locate your
vehicle.
F
Pl

ace the mechanical key (integral with the
remote control) in the lock to unlock your
vehicle.
F
Pl

ace the electronic key in the reader.
F
Sw

itch on the ignition by pressing
START/STOP.
The electronic key is fully operational again.
If the problem persists, contact a CITROËN
dealer or a qualified workshop as soon as
possible.
Access

DS5_en_Chap02_ouvertures_ed02-2015
Lost electronic key
Visit a CITROËN dealer with the vehicle's registration certificate, your personal identification documents and if possible the key code label.
The CITROËN dealer will be able to retrieve the key code and the transponder code required to order a new key.
Electronic key
The electronic key is a sensitive system; do not operate it while it is in your pocket as there is a possibility that it may unlock the vehicle, without
you being aware of it.
Do not repeatedly press the buttons of your electronic key out of range and out of sight of your vehicle. You run the risk of stopping it from
working and the remote control would have to be reinitialised.
The electronic key cannot operate as a remote control when it is in the reader or even when the ignition is switched on.
Locking the vehicle
Driving with the doors locked may make access to the passenger compartment by the emergency services more difficult in an emergency.
As a safety precaution (with children on board), take the electronic key with you when you leave the vehicle, even for a short time.
Electrical interference
The electronic key may not operate if close to certain electronic devices: telephone, laptop computer, strong magnetic fields, ...
Anti-theft protection
Do not make any modifications to the electronic engine immobiliser system; this could cause malfunctions.
When purchasing a second-hand vehicle
Have all of the keys in your possession paired by a CITROËN dealer, to ensure that only your keys allow your vehicle to be unlocked and
started.

61
DS5_en_Chap02_ouvertures_ed02-2015
Central locking
Driving with the doors locked may make
access to the passenger compartment
by the emergency services more
difficult in an emergency. If one of the doors or the boot is
open, automatic central locking does
not complete: the sound of the locks
rebounding can be heard.
Transporting long or voluminous
objects
If you want to drive with the boot open
but the vehicle's side doors locked,
press the central locking control button
to lock the doors.
Manual central
locking
F Press this button to operate the central
locking of the vehicle (doors and boot) from
inside the vehicle.
F
Pr

essing the button again unlocks the
vehicle completely.
When locking / deadlocking from the
outside
If the vehicle is locked or deadlocked from the
outside, the button is not active.
F
Af

ter normal locking, pull one of the interior
door handles to unlock the vehicle.
F
Af

ter deadlocking, you have to use the
remote control, the Keyless Entry and
Starting system or the integral key to
unlock the vehicle.
Automatic central locking
of doors (anti-intrusion
security)
The doors and boot lock automatically when
driving, as soon as the speed exceeds 6 mph
(10 km/h).
To activate or deactivate this function
(activated by default):
F
wi

th the ignition on, press this
button until a message appears
in the instrument panel.
Access

63
DS5_en_Chap02_ouvertures_ed02-2015
System which protects and provides a deterrent
against theft and break-in. It provides the
following types of monitoring:
Alarm
- Exterior perimeter
The system checks for opening of the vehicle.
The alarm is triggered if anyone tries to open a
door, the boot or the bonnet...
- Interior volumetric
The system checks for any variation in the
volume in the passenger compartment.
The alarm is triggered if anyone breaks a
window, enters the passenger compartment or
moves inside the vehicle.
- Tilt
The system checks for any change in the
attitude of the vehicle.
The alarm is triggered if the vehicle is lifted,
moved or knocked.
Self-protection function
The system checks for the putting out of
service of its components.
The alarm is triggered if the battery, the
button or the wires of the siren are put
out of service or damaged.For all work on the alarm system,
contact a CITROËN dealer or
a
q

ualified workshop.
Locking the vehicle with full
alarm system
Activation
F Switch off the ignition and get out of the vehicle.
F Press the locking button on the
r emote control or lock the vehicle
using the Keyless Entry and
Starting system.
Following an instruction to lock the
vehicle from the remote control or using
the Keyless Entry and Starting system,
the exterior perimeter monitoring is
activated after a delay of 5 seconds,
the interior volumetric monitoring
after 45 seconds and the anti-tilt after
90
s

econds.
If an opening (door, boot...) is not closed
fully, the vehicle is not locked but the
exterior perimeter monitoring will be
activated after a delay of 45 seconds.
The monitoring system is active: the indicator
lamp in the button flashes once per second.
Access
