Page 221 of 400

Citroen DS5 HYBRID RHD 2016 1.G Owners Manual 219
Changing a fuse
The fuse extraction tweezer is fitted to the back
of the dashboard fusebox cover.
For access to it:
F
r
 emove the cover completely and turn it
ove r,
F

r
 emove the tweezer.

Page 223 of 400

Citroen DS5 HYBRID RHD 2016 1.G Owners Manual 221
dashboard fuses
The fusebox is placed in the lower dashboard
(left-hand side).
Access to the fuses
F See the "Access to tooling" section.
Table of fuses
Fuse n° Rating
(A) Functions
F6 A or B 1

Page 224 of 400

Citroen DS5 HYBRID RHD 2016 1.G Owners Manual Engine compartment fuses
The fusebox is placed in the engine
compartment near the battery.
Access to the fuses
F Unclip the cover.
F C hange the fuse.
For information on the special requirements
and

Page 246 of 400

Citroen DS5 HYBRID RHD 2016 1.G Owners Manual 1. Power steering fluid reservoir.
2. Screenwash and headlamp wash fluid
reservoir.
3.
 C

oolant header tank.
4.
 B

rake fluid reservoir.
5.
 B

attery / Fuses.
6.
 F

usebox.
7.
 R

emote earth po

Page 247 of 400

Citroen DS5 HYBRID RHD 2016 1.G Owners Manual 245
1. Power steering fluid reservoir.
2. Screenwash and headlamp wash fluid
reservoir.
3.
 C

oolant header tank.
4.
 B

rake fluid reservoir.
5.
 B

attery / Fuses.
6.
 F

usebox.
7.
 R

emote eart

Page 313 of 400

Citroen DS5 HYBRID RHD 2016 1.G Owners Manual 3 11
Diesel ...................................................... 21, 241
