fuse box diagram Citroen DS5 HYBRID RHD 2016 1.G Owner's Manual

219
Changing a fuse
The fuse extraction tweezer is fitted to the back
of the dashboard fusebox cover.
For access to it:
F
r
emove the cover completely and turn it
ove r,
F

r
emove the tweezer.
Access to tooling
Before changing a fuse, it is necessary to:
F i dentify the cause of the failure and
correct it,
F

s
witch off all electrical consumers,
F

i
mmobilise the vehicle and switch off the
ignition,
F

i
dentify the failed fuse using the allocation
tables and diagrams presented on the
following pages.
changing a fuse
good Failed
To remove or fit a fuse, it is essential to:
F

u

se the special tweezer to extract the fuse
from its housing and check the condition of
its filament.
F

a

lways replace the failed fuse with a fuse
of the same rating (same colour); a fuse of
different rating could cause a fault (risk of
f i r e).
The replacement of a fuse not
mentioned in the tables below could
cause a serious malfunction of your
vehicle. Contact a CITROËN dealer or a
qualified workshop.
If the fault recurs after replacing a fuse, have
the electrical system checked by a CITROËN
dealer or a qualified workshop. Tw e e z e r
Practical information
