001001002002003003COMFORT ACCESS MONITORING HYBRID SYSTEM

With the hybrid system active or when the vehicle is being driven, illumination of one of the following warning lamps indicates a fault which requires action on the par t of the driver.
Any fault resulting in the illumination of a warning lamp must be investigated further by reading the associated message in the instrument panel screen.
If you encounter any problems, contact a CITROËN dealer or a qualified workshop.
Warning / indicator lampStateCauseAction / Observations



STOPfixed, associated with another warning lamp, accompanied by an audible signal and a message in the screen.It is associated with a punctured wheel,
the brakin
g system, the power steering,
the engine oil pressure, the enginecoolant temperature, the hybrid system
or a major electrical fault.Stop as soon as it is safe to do so as the en
gine may cut out.
Park, switch off the ignition and call a CITROËN
dealer or a qualified workshop.



Serviceon temporarily. A minor fault has occurred for which
there is no specific warning lamp. Identify the fault by reading the message shown in the screen, such as, for example:
- the closing of the doors, boot or bonnet,
- the engine oil level,
- the screenwash level,
- the remote control battery,
- the tyre pressures,
- saturation of the par ticle emission filter (Diesel). - ...For any other faults, contact a CITROËN dealer or a
qualified workshop.
fixed. A major fault has occurred for which
there is no specific warning lamp. Identify the fault by reading the message shown on the screen and contact a CITROËN dealer or a yyg g
qualified workshop.
PEF: particle emissions filter,Diesel
fixed, associated
temporarily with a message on the risk of
blockage of the PEF.Thi
s indicates the start of saturation
of the par ticle emissions filter. As soon as traffic conditions allow, regenerate the
filter by driving at a speed of at least 35 mph (60 km/h)
until the ser vice warning lamp goes off.
fixed.This indicates the low level in theDiesel additive reservoir. Have the level topped up by a CITROËN dealer or a
qualified workshop as soon as possible.

Electronic key
remote control
Unlocking the vehicle
Complete unlocking
Selective unlockin
g Unlocking the boot
System which permits central unlocking or
locking of the vehicle using the lock or from adistance. It is also used to locate and start thevehicle, as well as providing protection against
theft.
This settin
g is done in the configuration menu.
Complete unlocking is activated bydefault.


Unlocking is confirmed by rapid flashing of the direction indicators for around two seconds.
At the same time, depending onversion, the door mirrors unfold.

Locking the vehicle


Locking is confirmed by fixed lighting of the direction indicators for approximately two seconds.
The door mirrors fold at the same time.
)
To unlock only the driver's door,
press the open padlock once.
) To unlock the other doors
and the boot, press the open
padlock again.
) Press the closed padlock to lock
the vehicle completely.
Hold the button down until thewindows close completely.
) Press this button until you hear
th
e boot unlock.




Be aware of children when operatingthe windows.
)
Press the open padlock tounlock the vehicle.

77Access
Unlocking the vehicle



















"Keyless Entry and Starting" system


System that allows the opening, closingand star ting of the vehicle while keeping theelectronic key on your person.
Complete unlocking
)
With the electronic key on your personand in the defined zone A
, pass your hand behind the door handle to unlock thevehicle, then pull on the handle to open
the door.
Yo u r p a s s e ngers can also open their doors,
as soon as the electronic key is in the defined zone around the vehicle.



Selective unlocking
This setting is done via the configuration menu.
By default, complete unlocking is activated.
)
To unlock only the drivers door, with the electronic key on your person, pass your hand behind the driver's door handle thenpull on the door handle to open.)
To unlock the complete vehicle, pass your hand behind one of the passenger door handles on the same side of the vehicle asthe electronic key is located, then pull on
the door handle to open.



Unlocking is confirmed by rapidflashing of the direction indicators for approximately two seconds.
The door mirrors unfold at the sametime.
If the alarm is on, the audible warningwhen opening a door with the key(integral with the remote control), willstop on star ting the engine.

Accumulations (water, dust, grime, salt...) on
the inner sur face if the door handle may affect detection.
If cleaning the inner sur face of the door handle
using a cloth does not resolve the problem, contact a CITROËN dealer or a qualified
workshop.
A sudden splash of water (stream of water, highpressure jet washer, …) may be identified by
the system as the desire to open the vehicle.

It can also be used as a remote control;see the "Key/remote control" section.

Locking the vehicle
)With the electronic key in the definedzone A , press with a finger on one of the
door handles (at the markings) to lock the
vehicle
.
Maintain pressure with your finger until the
windows close completely.
Locking is confirmed by fixed lighting of the direction indicators for approximately two seconds.The door mirrors fold at the same time.
If one of the doors or the boot is still open or if the key for Keyless Entry and Starting has been left inside the vehicle,the central locking does not take place. When the vehicle is locked, if it isunlocked inadver tently, it will relockautomatically after about thir ty secondsunless a door is opened.
The folding and unfolding of the door mirrors by the remote control can bedeactivated by a CITROËN dealer or a qualified workshop.

As a safety measure (children onboard), never leave the vehicle without taking the key for the Keyless Entry andStarting system, even for a shor t period.Guard against theft when the key for the Keyless Entry and Starting systemis in the defined zone with the vehicle unlocked. After a long period of parking, theautomatic detection functions of the key are inhibited so as to not discharge thevehicle's battery. You should then use the remote control function of the key to unlock the vehicle.

Ensure that no one prevents the correct operation of the windows.Be aware of children when operatingthe windows.

79Access
Deadlocking
Deadlocking renders the exterior and
interior door controls inoperative. It also deactivates the manual centralcontrol button. Therefore, never leave anyone inside the vehicle when it is deadlocked.
Using the remote control
) Press the closed padlock to lock
the vehicle completely.
Maintain pressure with
your
finger for more than twoseconds to close the windows.) Press the closed padlock again within
five seconds to deadlock the vehicle.

With the electronic ke
y in the reader or the
Keyless Entry and Starting key inside the
vehicle, pressin
g the "STA R T/STOP" button,
with no action on the pedals, allows the ignition
to be switched on and so activate the ancillary
equipment.
Ignition on without starting
the engine
(accessory position)
)
Press the "STA R T/STOP" button,
the instrument panel comes on
but the engine does not star t.) Press the button again to switch
off the ignition and so allow the
vehicle to be locked.

If you use the accessory position for too long, the system automatically goes intoeconomy mode to avoid the risk of a flat
battery.


With the Keyless Entry and
startin
g system
By the doors: )
With the electronic key in the defined
zone A , press a finger on the door handle (at the markings) to lock the vehicle.
)
Within five seconds, press the door handle
again to deadlock the vehicle.
Ensure that no one is preventing the correct closing of the windows. Be aware of children when operating
the windows.

81Access
Do not throw the remote control batteries away, they contain metalswhich are harmful to the environment. Take them to an approved collectionpoint.
Changing the battery of the electronic key
Battery ref.: CR2032 / 3 volts.
This replacement battery is available from a
CITROËN dealer or a qualified workshop.
A message appears in the instrument panel
screen when replacement o
f the battery is needed. ) Unclip the cover using a small screwdriver at the cutout. )
Lift off the cover. )
Remove the flat battery from its location.)
Fit the new battery into its location
observing the original direction of fitment.) Clip the cover onto the casing.
Remote control problem -
reinitialisation

Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction,
you can no longer unlock, lock or locate your
v
ehicle.
)Place the mechanical key (integral with theremote control) in the lock to unlock your
vehicle.)Place the electronic key in the reader.)Switch on the ignition by pressing STA R T/STOP.
The electronic key is fully operational again.
If the problem persists, contact a CITROËN
dealer or a qualified workshop as soon as
possible.

Lost electronic key
Visit a CITROËN dealer with the vehicle's registration document and your personal identification documents and if possible the key code label.
The CITROËN dealer will be able to retrieve the key code and the transponder code required to order a new key.
Electronic key
The electronic key is a sensitive system; do not operate it while it is in your pocket as there is a possibility that it may unlock the vehicle, without you being aware of it.Do not repeatedly press the buttons of your electronic key out of range and out of sight of your vehicle. You run the risk of stopping it from working and the remote control would have to be reinitialised.The electronic key cannot operate as a remote control when it is in the reader or even when the ignition is switched on.
Locking the vehicle
Driving with the doors locked may make access to the passenger compar tment by the emergency services more difficult in an emergency.
As a safety precaution (with children on board), take the Keyless Entry and Starting electronic key when you leave the vehicle, even for a shorttime.
Electrical interference
The Keyless Entry and Starting electronic key may not operate if close to certain electronic devices: telephone, laptop computer, strongmagnetic fields, ...
Anti-theft protection
Do not make any modifications to the electronic engine immobiliser system; this could cause malfunctions. Don't forget to turn the steering to engage the steering lock.
When purchasing a second-hand vehicle
Have all of the keys in your possession paired by a CITROËN dealer, to ensure that only your keys allow your vehicle to be unlocked and star ted.

83Access














Central locking control
Automatic central lockingof the doors
(anti-intrusion security)
The doors and boot can lock automatically while driving (speed above 6 mph (10 km/h)).
To activate or deactivate this function (activated
by default):
If the vehicle is deadlocked or locked from the outside, the button is not active. In this case, use the remote control to unlock the vehicle or pull an interior door handle to open a door.
If one of the doors is open, central locking from the inside does not take place.
Driving with the doors locked may make access to the passenger compar tment by the emergency ser vices more
difficult in an emergency.
)
Press the closed padlock tolocate your locked vehicle in a car park.
Locating your vehicle
)Operate the button.
This allows the doors and the boot to be locked or unlocked. This is indicated b
y lighting of the cour tesy
lamps and flashing of the direction indicatorsfor a few seconds.
) Operate this button until amessage appears in theinstrument panel screen.

Transporting long or voluminousobjects
If you want to drive with the boot open,press the central locking control button to lock the doors.

Boot
)After unlocking the boot or the vehicleusing the electronic key - remote control,press the opening control then raise the
tailgate.

Opening from outside
)
Press this button until the boot is heard to unlock.

Tailgate release

System allowing the mechanical unlocking of
the boot in the event of a battery or central
locking system malfunction.

If the tail
gate is not closed correctly, with
the hybrid system active
or the vehiclemoving(speed above 6 mph (10 km/h)),a message appears in the instrument panelscreen for a few seconds.


Locking after closing

If the fault persists after closing again, the boot
w
ill remain locked.
Unlocking
)Fold back the rear seats to gain access to
the lock from inside the boot.)Insert a small screwdriver into hole Aof thelock to unlock the tailgate. )Move the latch to the left.



Closing
)
Lower the tailgate using the interior grab handle.



Opening from inside
