Citroen DS5 HYBRID4 2013 1.G Owner's Manual

07
339
SCREEN MENU MAP






PERSONALISATION-
CONFIGURATION
Define the vehicle parameters
Access to the vehicle

Plip action
Drivin
g position setting

Unlocking boot only
Driving assistance
Rear wipe in reverse gear
Parkin
g brake automatic

Speeds memorised
Vehicle lighting
Daytime lights
Directional headlampsInterior li
ghting
Welcome lighting
Follow-me-home headlamps

Choice of language Display configuration
Choice of units
Date and time adjustment
Display parameters
Brightness


Choice of sounds
1
2
3
3
3
2
3
3
3
2
3
3
2
3
3
1
1
2
2
2
2
1

FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
There is a difference in sound quality between
the different audiosources (radio, CD...).
For optimum sound qualit
y, the audio settings (Volume, Bass, Treble,
Ambience, Loudness) can be adapted to the different sound sources,
which may result in audible differences when changing source (radio,
CD...). Check that the audio settin
gs (Volume, Bass,
Treble, Ambience, Loudness) are adapted to
the sources listened to. It is advisable to set
the AUDIO functions (Bass, Treble, Front-Rear Fader, Left-Right Balance) to the middle position, select the musical ambience "None" and set theloudness correction to the "Active" position in CD mode or to the "Inactive" position in radio mode.

When changing the settings for treble and
bass, the ambience
setting is deselected.
When chan
ging the
ambience setting, treble and bass are reset to zero.
Choosing an ambience imposes settings for treble and bass. Modifyingone without the other is not possible. Modify the treble and bass settings or the
ambience setting to obtain the desired sound
quality.
When changing the
balance settin
g, distribution is deselected.
Choosing a distribution setting imposes a balance setting. Modifying one
without the other is not possible. Modify the balance setting or the distribution setting to obtain the desired sound quality. The
following tables contain answers to the most frequently asked questions.

341
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
The quality of receptionof the radio station
listened to graduallydeteriorates or the stored stations do not function(no sound, 87.5 MHz is
displayed...). The vehicle is too
far from the transmitter used by the station listened
to or there is no transmitter in the geographical area through which the
vehicle is travelling.
Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.
The environment
(hills, buildings, tunnels, basement car parks...) block reception, including in RDS mode. This phenomenon is normal and does not indicate
a failure of the audio equipment.
The aerial is absent or has been dama
ged (for example when goingthrough a car wash or into an underground car park). Have the aerial checked by a CITROËN dealer.

Sound cut-outs of 1 to
2 seconds in radio mode.During this brief sound cut-out, the RDS searches for any frequency
permitting better reception of the station. Deactivate the RDS function if the phenomenon is
too frequent and always on the same route.
Th
e traffi c announcement(TA) is displayed. I donot receive any traffi c
information.Th
e radio station does not broadcast traffi c information. Tune to a radio station which broadcasts traffi c
information.
Th
e stored stations arenot found (no sound, 87.5 MHz is displayed...). An in
correct waveband is selected. Press the BAND button to return to the wavebandon which the stations are stored.

FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
The CD is ejected
automatically or is not played by the player. The
CD is inserted upside down, is unplayable, does not contain any audio data or contains an audio format which the player cannot play.
The CD is protected b
y an anti-pirating protection system which is not recognised by the audio equipment.
-
Check that the CD is inserted in the player the
right way up.

-
Check the condition of the CD: the CD cannot
be played if it is too damaged.

-
Check the content in the case of a recordedCD: consult the advice in the "Audio" section.

- The audio equipment's
CD player does not
play DVDs.

- Due to their qualit
y level, certain writeableCDs will not be played by the audio system.
The CD pla
yer sound ispoor.The CD used is scratched or of poor quality. Insert good quality CDs and store them in suitable conditions.
The audio settin
gs (bass, treble, ambience) are unsuitable. Set the treble or bass level to 0, without selectingan ambience.
I
am unable to connect my Bluetooth telephone. It is possible that Bluetooth is switched off on the telephone or that the
telephone has not been made not visible.
- Check that your telephone has Bluetoothswitched on.

-
Check in the telephone's settings that it is "Visible to all".
The Bluetooth telephone is not compatible with the s
ystem. You can check the compatibility of your telephone
on www.citroen.co.uk (services)

The Bluetooth connectionis cut. The battery of the peripheral may not be suffi ciently charged. Recharge the battery of the peripheral device.

343
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
The message "USB
device error" is displayedon the screen.The U
SB memory stick is not recognised.
The memor
y stick may be corrupt. Re
format the memory stick (FAT 3 2).

A telephone connects
automatically,
disconnecting another
telephone. Automatic connection overrides manual connection. Modify the telephone settings to remove automatic connection.
The A
pple®
player is ®
not recognised whenconnecting to the USBport. The A
pple ®player is of a generation that is not compatible with the USB. Connect the Apple ®player to the AUX Jack socket using a suitable cable (not supplied).
When I connect my
Apple ®
player or my ®
BlackBerry®
to the®
USB port, I have alert messages on the currentconsumption by the USBport. When charging, the current consumption o
f these smartphones is greater
than the rating of the USB port, which is 500mA.

The hard disk or deviceis not recognised whenconnecting to the USBport.
Some hard disks and devices need a power supply greater than is
provided by the audio system. Connect the device to the 230 V socket, the 12 V socket or an external power supply.
Caution
:
ensure that the device does not transmit
a voltage greater than 5 V (risk of destruction of
the system).
When streamin
g, the sound cuts momentarily. Some telephones prioritise connection of the "hands-free" profi le. Delete the "hands-free" connection profi le toimprove streaming.

FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
In "Random all" play,not all of the tracks areplayed.In "Random all" pla
y, the system can only take into account up to 999 tracks.
With the en
gine off, the
audio system switches
off after a few minutes of use. When the en
gine is switched off, the audio system operating time
depends on the battery charge.
The switch-o
ff is normal: the audio system switches to economy mode and switches off to prevent discharging the vehicle's battery.
Start the vehicle's engine to increase the batterycharge.

The message "the audio system is overheated"
appears on the display. In order to protect the installation if the surroundin
g temperature is toohigh, the audio system switches to an automatic thermal protection mode leading to a reduction of the volume or stopping of the playing of the CD. Switch the audio s
ystem off for a few minutes to
allow the system to cool.

345

Index


Alphabetical index - Visual search

A
ABS...............................................................187Accessories.......................................33, 83, 234Accessory position.....................................33,83Accessory socket, 12V ...........................110,111Adjusting headlamps .....................................160Adjusting head restraints.......................100, 103Adjusting seat belt height..............................191Adjusting the steering wheel..........................109Airbags ....................................................67, 195Airbags, curtain...................................... 195, 196Airbags, front.........................................193, 196Airbags, lateral.......................................195, 196Air conditioning........................................47, 120Air conditioning, digital............................117, 118Air fi lter..........................................................r246Air fl ow.............................................................47Air vents.........................................................116Alarm...............................................................89Anti-lock braking system (ABS).....................187Anti-pinch.........................................................93Anti-theft..........................................................33Armrest.......................................................... 110Armrest, front ................................................. 112Armrest, rear..................................................r113Ashtray, portable............................................110ASR...............................................................187Assistance, emergency braking.....................187Assistance call.......................................185, 259Audible warning.............................................185Audio streaming (Bluetooth) ..........301,328, 330Audio system.................................................315Automatic headlamps ..............................60, 157Automatic illumination of headlamps .....153, 156
Automatic operation
of hazard warning lamps.............................184Automatic rain sensitivewindscreen wipers ...............................163,165Auxiliary socket......................11 2, 301, 302,327
Backup starting ........................................34,226Backup switching off........................................f34Battery...............8,28,50-52,107, 225-227,245Battery, charging............................................226Battery, remote control..............................85, 86Black panel......................................................73Bluetooth (hands-free) ...........................284,329Bluetooth (telephone) ............................284, 329Boot.................................................................88Boot (opening) .................................................80Boot fl oor, adjustable.....................................114Brake discs....................................................247Brake lamps...................................................219Brake pads....................................................247Brakes .....................................................62,247
Changing a bulb.....................................214-221Changing a fuse.....................................222-224Changing a wheel...................................206-212Changing a wiper blade .........................166, 229Changing the date .....................................74,75Changing the remote control battery...............85Changing the time .............................74, 75, 305Checking levels......................................242-245Checking the engine oil level...........................71Checking tyre pressures (using the kit).........200Checks............................................240, 245-247Children ..................................172-181, 192, 194Child lock .......................................................181Child seats .............................................172-180Child seats, conventional.......................175, 176Cigar lighter....................................................r111Clock................................................................74Closing the boot...............................................88Closing the doors.......................................80,82Connectors, audio.................112, 301, 302, 327Coolant level............................................68, 243Coolant temperature indicator.........................r68Courtesy lamps..............................................167Cruise control........................................142, 145Cup holder.....................................................r110
B
Cables, high voltage........................................52Capacity, fuel tank...........................................95CD.........................................................298,322CD MP3 .........................................298, 323,324Central locking ...........................................80, 82
CDate (setting).....................................74, 75, 305Daytime running lamps ..................214,217, 218Deactivating ESP........................................... 189Deactivating the passenger airbag................194Deadlocking ...............................................83,84
D
