bonnet Citroen DS5 HYBRID4 2013 1.G Owner's Manual

CHECKS PR ACTICAL
INFORMATIONTECHNICAL
DATAAUDIO AND
TELEMATICS
200 Te m p o r a ry puncture repair
kit
206 Changing a wheel
213Snow chains
214Changing a bulb
222Changing a fuse
225 12 V battery
228Energy economy mode
229Changing a wiper blade
229Recovering the vehicle
231Vehic le recovery
231To w i ng a trailer
233 Fitting roof bars
234Accessories
239Opening the bonnet
240 Diesel engine
241 Running out of fuel (Diesel)
242Checking levels
245 Checks
250 Electric motor
251 Diesel engine
252Diesel weights
253 Dimensions
254 Identifi cation markings
258Emergency or assistance
261eMyWay
315 Audio system
008008009009010010011011

14 . Controls for electric windows / electric child lock / central locking.
15. eMyWay controls.
16.Gear selector.
17. Hybrid4 mode selector.
18
. Heating / air conditioning controls.
19.Audio system.
20.Hazard warning lamps. 21. Multifunction screen.22.Central adjustable air vents.
23.Clock.
24.Starting with the STA R T/STOP button.
25. Electronic key reader.
26. Wiper / screenwash / trip computer stalk.






Instruments and controls
1.
Bonnet release lever.2.
Headlamp height adjustment. 3.
Side adjustable air vents.4.
Front door window demisting/defrosting
vents.
5. Quarter light demisting windows.
6.Head-up display.7. Windscreen demisting/defrosting vent.8.Passenger's airbag. 9.
Glove box / Passenger's airbag deactivation inside. 10.12 V accessory socket. 11.
Rear electric window controls.12.Central armrest with storage.
USB por t / auxiliary socket. 13.Electric parking brake.
27. Audio equipment steering mountedcontrols. 28.
Driver's airbag.
Horn. 29. Cruise control / speed limiter controls.
30.
Switch panel (see previous page).31.Door mirror adjustment.32.
Lighting and direction indicator stalk33.
Instrument panel. 34.Seat belt and airbag warning lamps. 35.Cour tesy lamp. 36.Head-up display controls. 37.
Controls for cockpit glass roof blind. 38.CITROËN Localised Emergency Call - CITROËN Localised Assistance Call.

29Hybrid system
Main parts of the Hybrid4 system

The HDi Diesel engine - 1
, located at the front,
drives the front wheels and provides most of
the power needed to drive the vehicle.
It i
s fitted with the Stop & Start
system - 5which recharges the batteries and provides
additional power when needed (in 4x4 mode).

Th
e electric motor - 2
, located at the
rear, drives the rear wheels on its own, or
supplements the Diesel engine, according to
the hybrid mode selected.
It recovers energy and charges the batteries
during phases of deceleration of the vehicle
and is active up to 70 mph
(120 km/h).
A 200 V NI-MH hi
gh voltage battery - 3,provides a source of energy for the rear electric
motor.
Its charging rate is managed automatically by
the vehicle during phases of deceleration.It is located in a compar tment in the boot, access to which is restricted to trained servicetechnicians.
The batter
y state of charge
is indicated
by 8 horizontal or vertical bars (depending on
the screen).

Th
e conventional battery, located under the ybonnet, powers the vehicle's 12 V systems. It is recharged automatically by the high voltage
network.

Switching off the Hybrid4
s
ystem
- Before switching off the Hybrid4 system,place the gear selector in position N.
- Make a shor t press on the START/STOPbutton.
- The s
ystem shuts down and the steeringcolumn locks.

When your vehicle vehicle moves off in electric mode, it makes no noise. Be ver y careful of pedestrians as they will not hear you coming.
For more information, see the section on "Underbonnet precautions/warnings".
When stationary, switch off the ignitionand check that the Ready
lamp is off before leaving the vehicle, other wisethe hybrid system will still be active.

35
Hybrid system








Hybrid4 mode selector
The selector allows the user to choose between 4 drive modes for the vehicle.
Turn the dial to the ri
ght or left; the mode selected is confirmed by illumination of the corresponding indicator.
ZEVmode, to force electric runnin
g.Spor
tmode, to make use of the maximum
performance of the vehicle.
4WDmode, to force the vehicle into 4x4 mode.

AUTOmode, for normal use and optimised fuelconsumption.

On star ting the vehicle: with the gear selector in position N, press the brake pedal and press
the STA R T/STOP button to activate the hybrid system.
This lamp comes on when the vehicle is ready
to move off ("Auto" mode is on by default) andso the driver can press the accelerator.
This lamp comes on more or less instantly but may take a few seconds in some cases (inparticular, the time needed for pre-heating the
Diesel engine in cold weather or, for example,
in energy economy mode, ...).








Ready lamp
With the vehicle stationary, press the STA R T/STOP button and check that the Readylamp is off when leaving thevehicle, other wise the hybrid system will still be active.


For more information, refer to the section on "Underbonnet precautions / warnings".

53Hybrid system





Underbonnet precautions / warnings

The alternator-star ter motor of your hybrid
vehicle is also supplied at high voltage. If the
vehicle ignition has not been switched off, there
is a risk of the engine restar ting at any time.
Alwa
ys ensure that the
ignition is switched off (Readylamp off) before
opening the bonnet.
Also ensure that the ignition is switchedoff when refuelling to avoid the engine restarting.

With the hybrid system active or when the vehicle is being driven, illumination of one of the following warning lamps indicates a fault which requires action on the par t of the driver.
Any fault resulting in the illumination of a warning lamp must be investigated further by reading the associated message in the instrument panel screen.
If you encounter any problems, contact a CITROËN dealer or a qualified workshop.
Warning / indicator lampStateCauseAction / Observations



STOPfixed, associated with another warning lamp, accompanied by an audible signal and a message in the screen.It is associated with a punctured wheel,
the brakin
g system, the power steering,
the engine oil pressure, the enginecoolant temperature, the hybrid system
or a major electrical fault.Stop as soon as it is safe to do so as the en
gine may cut out.
Park, switch off the ignition and call a CITROËN
dealer or a qualified workshop.



Serviceon temporarily. A minor fault has occurred for which
there is no specific warning lamp. Identify the fault by reading the message shown in the screen, such as, for example:
- the closing of the doors, boot or bonnet,
- the engine oil level,
- the screenwash level,
- the remote control battery,
- the tyre pressures,
- saturation of the par ticle emission filter (Diesel). - ...For any other faults, contact a CITROËN dealer or a
qualified workshop.
fixed. A major fault has occurred for which
there is no specific warning lamp. Identify the fault by reading the message shown on the screen and contact a CITROËN dealer or a yyg g
qualified workshop.
PEF: particle emissions filter,Diesel
fixed, associated
temporarily with a message on the risk of
blockage of the PEF.Thi
s indicates the start of saturation
of the par ticle emissions filter. As soon as traffic conditions allow, regenerate the
filter by driving at a speed of at least 35 mph (60 km/h)
until the ser vice warning lamp goes off.
fixed.This indicates the low level in theDiesel additive reservoir. Have the level topped up by a CITROËN dealer or a
qualified workshop as soon as possible.

OFF
89Access
System which protects and provides a deterrent
against theft and break-ins. It provides the
following types of monitoring:





Alarm


- Exterior perimeter

The system checks for opening of the vehicle.
The alarm is triggered if anyone tries to open adoor, the boot or the bonnet...




- Interior volumetric

The system checks for any variation in the
volume in the passenger compartment.
The alarm is triggered if anyone breaks a
window, enters the passenger compar tment or moves inside the vehicle.
- Tilt
The system checks for any change in the attitude of the vehicle.
The alarm is triggered if the vehicle is lifted,
moved or knocked.


Self-protection function
The system checks for the putting out of ser vice of its components. The alarm is triggered if the battery, thebutton or the wires of the siren are putout of ser vice or damaged.
For all work on the alarm system, contact a CITROËN dealer or aqualified workshop.
Locking the vehicle with full
alarm system
Activation
)Switch off the ignition and get out of the vehicle.
)
Press the locking button on the
r
emote control or lock the vehicleusing the Keyless Entry and Starting system. The monitoring system is active: the indicator
lam
p in the button flashes once per second.
After the locking button on the remote control
is pressed or the vehicle locked using the
Keyless Entry and Star ting system, the exterior
perimeter monitoring is activated after a delay of 5 seconds, the interior volumetric monitoring after 45 seconds and the anti-tilt after one
minute and 30 seconds.
If an opening (door, boot...) is not closed fully, the vehicle is not locked but the exterior
perimeter monitoring will be activated after a
delay of 45 seconds.
) Press the unlocking button on
the remote control or unlock the
vehicle using the Keyless Entryand Star ting system.

Deactivation of the volumetric monitoring
The volumetric protection system is deactivated: the indicator lamp in the button goes off.

Practical information




12 V battery
The presence of this label indicates the use of a 12 V lead-acid battery withspecial technology and specification, for which the involvement of a CITROËNdealer or qualified workshop is requiredwhen replacing or disconnecting the battery.
Failure to observe this recommendation may cause premature wear of the battery.The battery is located under the bonnet.
To
gain access to it:) open the bonnet using the interior releaselever, then the exterior safety catch,)
remove the plastic cover on the (+)
terminal
,) if necessary, unclip the fusebox to remove
the battery.
Access to the battery
) Raise the locking tab D
fully to release thecable terminal clamp E.


Reconnecting the (+) cable
)
Position the open clamp E
of the cable on
the positive post (+) of the battery. ) Press ver tically on the clamp E
to position
it correctly on the battery.) Lock the clamp by spreading thepositioning lug and then lowering the tab D.

Do not apply excessive force on the tab as locking will not be possible if the clamp is not positioned correctly; star tthe procedure again.
Before doing any work on your vehicle,
switch off the ignition ( Readylamp off)to avoid any risk of injury resulting from automatic operation of the engine. Y
our vehicle is fitted with a conventional 12 V
battery, located under the bonnet, in addition
to the hi
gh voltage battery used by the hybridsystem.
In cer tain conditions, if the 12 V battery is
too discharged to activate the hybrid system,
recharging from another conventional 12 V battery is possible.
Do not carry out this recharge if the Readylamp is on.
Procedure
for star ting the engine using another battery or charging a discharged battery.



Disconnecting the (+) cable

239Checks
Opening the bonnet
Opening
)
From inside
: pull the release lever, located
on the left below the dashboard, towards you.
Before doing anything under the bonnet,
switch off the ignition (Ready lamp off) to avoid any risk of injury resulting fromautomatic operation of the engine.


Closing
)
Lower the bonnet and release it at the endof its travel. )
Check that it is latched correctly.


)From the outside: lift the safety catch and
raise the bonnet.
A bonnet strut opens the bonnet and holds itopen.


Never touch, handle or remove the orange "high voltage" cables.

The use of a high pressure jet wash under the bonnet is strictly prohibited,in order to avoid damage to the electriccomponents.
