Page 5 of 364
58 Instrument panel
59 Indicator and warning lamps
68Gauges and indicators
72 Adjustment buttons
74 Setting the date and time
74 Clock
76Tr i p c o m p u ter
80Electronic key - remote control
81 "Keyless Entry and Starting"
88Boot
89 Alarm
91Electric windows
93 Cockpit glass roof
95Fuel tank
96 Misfuel prevention (Diesel)
100 Front seats
105 Rear seats
108Mirrors
109Steering wheel adjustment
110Interior fi ttings
114 Boot fi ttings
115Tr i a ngle (stowing)
116 Heating and Ventilation
118Dual-zone digital air conditioning
122Rear screen demist - defrost
28 Presentation
31 Starting / switching off
35 Ready lamp
35 Hybrid4 mode selector
38 Energy consumption / generation indicator
40Display of hybrid power fl ow
43 Hybrid4 frequently askedquestions
46 Eco off
47Eco-driving
49Consumption
50 High voltage battery
54 Car washing machine or
tunnel
55Vehicle recovery
001001002002003003COMFORT ACCESS MONITORING HYBRID SYSTEM
Page 60 of 364
Instrument panel
1.
Energy consumption / generation indicator (available power as a percentage).
For more information refer to the "H
ybrid
system" section.2. Fuel gauge.3.Engine coolant temperature gauge. 4.
Speedometer (mph or km/h).5.
Cruise control or speed limiter
settings.A
.Main lighting and controls dimmer.
B.- Successive shor t presses: under-inflation
detection, recall servicin
g information, alert
log.
- Long press: reset the function selected to
zero (ser vice indicator or trip recorder). 6
. Gear engaged.
7.Instrument panel screen: electrical flow,
trip recorder, aler t messa
ges or state of functions (e.g.: oil pressure, battery, door open, ...), trip computer, media, satellite
navigation.8. Digital speedometer (mph or km/h). 9.Ready lamp: indicates that the vehicle is
ready to drive.
Dials and screens
Control buttons
