45
Hybrid system

Air conditioning
QuestionAnswer

It seems to me that the vehicle runs less on electric when the heating or air conditioning is
operatin
g, is that right?
The demand for heating or air conditioning may require the star ting of the Diesel engine until thedesired level of comfort is attained.
Normal h
ybrid operation is simply put back. The period can be longer under low or very high
ambient temperatures.
It seems to me that when it is ver
y hot and the
air conditioning is working, the vehicle runs on electric for shor ter periods. Is that right? When it is hot, the periods when the Diesel en
gine is put on standby and the vehicle runs onelectric are necessarily restricted in order to limit the difference between the temperature in the
vehicle and the level of comfort selected.
In very hot weather, it is always possible to press the Eco OFF button (which brings the vehicle out of ZEV mode and prevents electric running or the stopping of the engine) to give preference to
temperature control (keeps the air conditioning running).

Special Hybrid4 features
QuestionAnswer
Can I tow with m
y hybrid vehicle and how much? A Hybrid4 vehicle can tow between 500 kg and 800 kg (see the "Towing" section).
This allows a jet ski or two-wheeler on a trailer to be towed, for example.
The "technical" reason for the limit is related to maintaining adequate cooling capacity for the internal combustion engine as well as the hybrid components that are also cooled by the engine's cooling system.
Wh
y does engine braking seem so strong? When you take your foot off the accelerator, the engine braking results mainly from the energyrecovery by the electric motor.
This leads to a higher level of deceleration than a conventional vehicle and so allows the recoveryof free energy.

We recommend the use of genuine
CITROËN towbars and their harnesses that have been tested and approved from the design stage of your vehicle,and that the fitting of the towbar is
entrusted to a CITROËN dealer or aqualified workshop.
If the towbar is not fitted by a CITROËN dealer, it is imperative that it isfitted in accordance with the vehiclemanufacturer's instructions.


Driving advice


Distribution of loads
)
Distribute the load in the trailer so that the
heaviest items are as close as possible to
t
he axle and the nose weight approaches the
maximum permitted without exceeding it.
Air density decreases with altitude, thus
reducing engine performance. Above
1 000 metres, the maximum towed load must
be reduced by 10 % for every 1 000 metres of altitude.


Side wind
)
Take into account the increased sensitivity
to side wind.



Cooling

To w i ng a trailer on a slope increases the
temperature of the coolant.
As the
fan is electrically controlled, its cooling capacity is not dependent on the engine speed.)
To lower the engine speed, reduce your speed.
)
If the warning lamp and the STOPwarning lamp come on,stop the vehicle and switch off
the engine as soon as possible.

Braking

To w i ng a trailer increases the braking distance.
To avoid overheating of the brakes on a longmountain type of descent, the use of engine braking is recommended.

Tyres
)Check the tyre pressures of the towingvehicle and of the trailer, obser ving the recommended pressures.



Lighting
)Check the electrical lighting and signalling on the trailer.


The rear parking sensors will be deactivated automatically if a genuine CITROËN towbar is used.



Driving with a trailer places greater demands on the towing vehicle and thedriver must take par ticular care.

The maximum towed load on a long incline depends on the gradient and the ambient
tem
perature.
In all cases, keep a check on the coolant
temperature.

R
efer to the "Technical data" section for detailsof the weights and towed loads which apply toyour vehicle.
