engine Citroen DS5 RHD 2012.5 1.G Manual Online

233Checks
Particle emission filter (Diesel)
The start of saturation of the particle filter is indicated by
the temporary illumination of
this warning lamp accompanied by a message in the multi-function screen.
As soon as the traffic conditions permit, regenerate the filter by driving at aspeed of at least 40 mph (60 km/h) until the warning lamp goes off.
If the warning lamp stays on, thisindicates a low additive level.


On a new vehicle, the first par ticlefilter regeneration operations may beaccompanied by a "burning" smell,which is perfectly normal.
Following prolonged operation of thevehicle at very low speed or at idle, you may, in exceptional circumstances, notice the emission of water vapour atthe exhaust on acceleration. This does not affect the behaviour of the vehicle or the environment. Re
fer to the ser vicing booklet for
details of the replacement intervalsfor these components.
Air filter and passenger compartment filter
Replace the oil filter each time the
engine oil is changed.
Refer to the servicing booklet for
details of the replacement inter val for
this component.
Oil filter
Depending on the environment (e.g. dustyatmosphere) and the use of the vehicle (e.g. city driving), replace them twice as often if necessar y.y A clogged passenger compartment filter mayhave an adverse effect on the performance
of the air conditioning system and generate undesirable odours.

Manual gearbox
The gearbox does not require anymaintenance (no oil change).
Refer to the ser vicing booklet for the
details of the level checking interval
for this component.
6-speed electronic gearbox
The gearbox does not require anymaintenance (no oil change).
Refer to the servicing booklet for
details of the checking inter val for
this component.
Automatic gearbox
The gearbox does not require any
maintenance (no oil change).
Refer to the servicing booklet for
details of the level checking interval
for this component.Brake wear depends on the style
o
f driving, par ticularly in the case
of vehicles used in town, over shor t
distances. It ma
y be necessary to
have the condition of the brakes checked, even between vehicle services.
Unless there is a leak in the circuit, a drop in
the brake fluid level indicates that the brake pads are worn.















Brake pads
For information on checking brake
disc wear, contact a CITROËN dealer
or a qualified workshop.


Brake disc wear
Electric parking brake

This system does not require any routine servicing. However, in theevent of a problem, have the systemchecked by a CITROËN dealer or a qualified workshop.
















Only use products recommended by CITROËN or products of equivalent quality and specification.
In order to optimise the operationof units as impor tant as the braking system, CITROËN selects and offersvery specific products.
To a v o i d d a m aging the electrical units,the use of a high pressure washer in the engine compar tment is strictly prohibited .


For more in
formation, refer to the "Electric parking brake - Operating faults" section.

Petrol enginesTHP
155 hp
THP
200 hp
Gearboxes
Automatic (6-speed)Manual (6-speed)

Model codes5FV

5FU
Cubic capacit
y (cc)
1 5981 598

Bore x stroke
(mm)

77 x 85.8
77 x 85.8

Max power: EU standard (kW)
115
147
Max power en
gine speed (rpm) 6 000
5 800

Max torque: EU standard (Nm) 240

275

Max torque en
gine speed (rpm) 1 400
1 700

Fuel Unleaded
Unleaded

Catalytic conver ter yesyes

Oil capacities
(in litres)
Engine (with filter replacement) -
-















Petrol engines and gearboxes

239Technical data














Petrol weights and towed loads (in kg)
Petrol enginesTHP155 hpTHP200 hp
Gearboxes
Automatic
(6-speed)

Manual(6-speed)
Model codes5FV

5FU



- Unladen wei
ght -
-


- Kerb weight
*

1 495
1 505


- Gross vehicle wei
ght (GV W)
2 035 2 050



-
Gross train weight (GTW)

on a 12 % gradient 3 3352 800



- Braked trailer (within GTW limit) on a 10 % or 12 % gradient--



- Braked trailer ** (with load transfer within the
GTW limit) 1 500
1 050



-
Unbraked trailer
745
750



- Recommended nose weight 75

75


*

The kerb weight is equal to the unladen weight + driver (75 kg).
**

The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

The
GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

*
The kerb weight is equal to the unladen weight + driver (75 kg).
Petrol enginesTHP155 hpTHP200 hp
Gearboxes

Automatic
(6-speed)Manual (6-speed)

Model codes5FV

5FU



- Unladen wei
ght -
-


- Kerb weight
*


1 495
1 505


- Gross vehicle wei
ght (GV W)
2 1702 195


-
Gross train weight (GTW)
on a 12% gradient 3 320

2 795



- Braked trailer
(within the GTW limit)
on a 10% or 12% gradient
1 150600



- Unbraked trailer
745
600



- Recommended nose weight 75

75

The
GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
Hi
gh ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.


Petrol weights and towed loads (in kg) - Commercial versions

241Technical data
Diesel enginese-HDi
110 / 115 hp
HDi
160 hp PEF
HDi
160 hp PEF
GearboxesElectronic gearbox system (6-speed)


Manual(6-speed)
Automatic(6-speed)

Model codes

9HR/9HD

RHH
Cubic capacit
y (cc)
1 560

1 997
Bore x stroke
(mm)
75 x 88.3
85 x 88

Max power: EU standard (kW) 82/84
11 0
120
Max power en
gine speed (rpm) 3 6003 750

Max torque: EU standard (Nm)

270340

Max torque engine speed (rpm) 1 750
2 000

Fuel Diesel

Catalytic converter
yes

Particle emission filter -
yes
Oil capacities
(in litres)
Engine (with filter replacement) -
-
-















Diesel engines and gearboxes

The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

*

The kerb weight is equal to the unladen weight + driver (75 kg). **

The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Diesel enginese-HDi 110/115 hpHDi160 hpPEFHDi160 hp PEF
GearboxesElectronic gearbox system (6-speed)


Manual(6-speed)
Automatic(6-speed)

Model codes9HR/9HDRHH



- Unladen weight---



- Kerb weight *

1 495
1 605

1 615



-
Gross vehicle weight (GVW)

2 020 2 1302 125


- Gross train wei
ght (GT W)
on a 12% gradient 3 120
3 330
3 325



- Braked trailer (within GTW limit) on a 10% or 12% gradient -
- -


- Braked trailer
**
(with load transfer with the GTW limit)

1 400
1 500 1 500


-
Unbraked trailer

745

750



- Recommended nose wei
ght 75

















Diesel weights and towed loads (in kg)

243Technical data
* The kerb weight is equal to the unladen weight + driver (75 kg).

The
GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

Diesel enginese-HDi 110 hpHDi160 hp PEFHDi160 hp PEF
GearboxesElectronic gearbox system (6 speed)


Manual(6-speed)
Automatic(6-speed)

Model codes
9HRRHH



- Unladen weight
-
- -


- Kerb weight
*1 495 1 605
1 615


- Gross vehicle wei
ght (GV W)
2 150
2 2652 255


-
Gross train weight (GTW)
on a 12% gradient 3 150
3 315
3 305



- Braked trailer (within the GTW limit)

on a 10% or 12% gradient
1 000
1 050

1 050



- Unbraked trailer
745

750



-
Recommended nose weight
75


Diesel weights and towed loads (in kg) - Commercial versions

305
operate in your vehicle.







AUDIO SYSTEM / BLUETOOTH

01 First steps


For safety reasons, the driver must only carry out
operations which require prolonged attention while the
vehicle is stationary.
When the engine is switched o
ff and to prevent
discharging of the battery, the audio system may switch off after a few minutes.



CONTENTS

02 Steering mounted controls

03 Main menu

04 Audio

05 Using the telephone

06 Audio settings

07 Screen menu map

Frequently asked questions p.
p.
p.
p.
p.
p.
p.
p. 3
06
307
3
08
309
319
327
32
8
330

333
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
A telephone connects
automatically,
disconnecting another
telephone. A
utomatic connection overrides manual connection. Modify the telephone settings to remove automatic connection.

The Apple® player is ®
not recognised whenconnecting to the USB port.
The Apple ®player is of a generation that is not compatible with the USB. Connect the Apple ®player to the AUX Jack socket using a suitable cable (not supplied).

The hard disk or deviceis not recognised whenconnecting to the USBport.
Some hard disks and devices need a power supply greater than is
provided by the audio system. Connect the device to the 230 V socket, the 12 V socket or an external power supply.
Caution
:
ensure that the device does not transmit
a voltage greater than 5 V (risk of destruction of
the system).
When streamin
g, the sound cuts momentarily. Some telephones prioritise connection of the "hands-free" profi le. Delete the "hands-free" connection profi le to
improve streaming.
In "Random all" pla
y,not all of the tracks areplayed.In "Random all" pla
y, the system can only take into account up to 999 tracks.
With the en
gine off, the
audio system switches off after a few minutes of use. When the en
gine is switched off, the audio system operating time
depends on the battery charge.
The switch-off is normal: the audio s
ystem switches to economy mode and switches off to prevent discharging the vehicle's battery.
Start the vehicle's engine to increase the batterycharge.

The message "the audio system is overheated"
appears on the display. In order to protect the installation if the surrounding temperature is toohigh, the audio system switches to an automatic thermal protection mode leading to a reduction of the volume or stopping of the playing of the CD.
Switch the audio system off for a few minutes to
allow the system to cool.
