Citroen GRAND C4 PICASSO 2017 2.G User Guide

9
C4-Picasso-II_en_Chap00c_eco-conduite_ed02-2016
Optimise the use of your gearbox
With a manual gearbox, move off gently and change up without waiting.
During acceleration change up early.
With an automatic gearbox, give preference to automatic mode and
avoid pressing the accelerator pedal heavily or suddenly.
Control the use of your electrical
equipment
Before moving off, if the passenger compartment is too warm,
ventilate it by opening the windows and air vents before using the air
conditioning.
Above 30 mph (50 km/h), close the windows and leave the air vents
open.
Remember to make use of equipment that can help keep the temperature
in the passenger compartment down (sunroof and window blinds...).
Switch off the air conditioning, unless it has automatic regulation, as
soon as the desired temperature is attained.
Switch off the demisting and defrosting controls, if not automatic.
Switch off the heated seat as soon as possible.
Switch off the headlamps and front foglamps when the ambient light
level does not require their use.
Avoid running the engine before moving off, particularly in winter; your
vehicle will warm up much faster while driving.
As a passenger, if you avoid connecting your multimedia devices
(film, music, video game...), you will contribute towards limiting the
consumption of electrical energy, and so of fuel.
Disconnect your portable devices before leaving the vehicle.
Eco-driving
Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.
Drive smoothly
Maintain a safe distance between vehicles, use engine braking rather
than the brake pedal, and press the accelerator progressively. These
practices contribute towards a reduction in fuel consumption and
CO
2 emissions and also help reduce the background traffic noise.
I
f your vehicle has cruise control, make use of the system at speeds
above 25 mph (40 km/h) when the traffic is flowing well. The gear efficiency indicator invites you to engage the most suitable
gear: as soon as the indication is displayed in the instrument panel,
follow it straight away.
For vehicles fitted with an automatic gearbox, this indicator appears
only in manual mode.
.
Eco-driving

10
C4-Picasso-II_en_Chap00c_eco-conduite_ed02-2016
Limit the causes of excess consumption
Spread loads throughout the vehicle; place the heaviest items in the
bottom of the boot, as close as possible to the rear seats.
Limit the loads carried in the vehicle and reduce wind resistance (roof
bars, roof rack, bicycle carrier, trailer...). Use a roof box in preference.
Remove roof bars and roof racks after use.
At the end of winter, remove snow tyres and refit your summer tyres.
Observe the recommendations
on maintenance
Check the tyre pressures regularly, when cold, referring to the label in
the door aperture, driver's side.
Carry out this check in particular:
-
b
efore a long journey,
-

a
t each change of season,
-

a
fter a long period out of use.
Don't forget the spare wheel and the tyres on any trailer or caravan.
Have your vehicle serviced regularly (engine oil, oil filter, air filter,
passenger compartment filter...) and observe the schedule of
operations recommended in the manufacturer's service schedule.
With a BlueHDi Diesel engine, if the SCR system is faulty your vehicle
becomes polluting; go to a CITROËN dealer or a qualified workshop
without delay to have the emissions of nitrogen oxides brought back to
the legal level.
When refuelling, do not continue after the third cut-off of the nozzle to
avoid any over flow.
At the wheel of your new vehicle, it is only after the first 1 800 miles
(3
000 kilometres) that you will see the fuel consumption settle down to
a consistent average.
Eco-driving

11
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
Touch screen
The touch screen gives access to:
- t he heating/air conditioning controls,
-

t
he menus for adjusting settings for vehicle
functions and systems,
-

t
he audio system and telephone controls
and the display of associated information,
For safety reasons, the driver must
only carry out operations that
require close attention with the
vehicle stationary.
Some functions are not accessible
when driving.General operation
Recommendations
Use is possible in all temperatures.
Do not use pointed objects on the touch
screen.
Do not touch the touch screen with wet hands.
Use a soft clean cloth to clean the touch
screen.
Use this button to return to the
previous page.
Use this button to confirm.
Principles
Use the buttons on either side of the touch
screen for access to the menus, then press the
virtual buttons in the touch screen.
Certain functions may be displayed over 1 or
2 pages.
To deactivate/activate a function, press OFF/ON.
To modify a setting (lighting duration, etc.) or
access additional information, press the symbol
for the function.After a few moments with no action on
the secondary page, the primary page
is displayed automatically.
and, depending on equipment, allows:
-

t

he display of alert messages and the
visual parking sensors information,
-

t

he permanent display of the time and the
exterior temperature (a blue warning lamp
appears when there is a risk of ice),
-

a

ccess to the controls for the navigation
system and Internet services, and the
display of associated information.
1
Instruments

12
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
MenusUpper bar
Certain information is always present in the
upper bar of the touch screen:
-
R
epeat of the air conditioning information,
and access to the simplified menu
(temperature and air flow adjustment only).
-

R
epeat of information from the Radio
Media and Telephone menus and
navigation instructions*.
-

N
otifications zone (SMS and email)*.
* Depending on equipment.
Air conditioning.
Allows control of the settings for
temperature, air flow, etc.
Connected navigation or Mirror
Scre en*.
See more in "Audio and telematics".
Radio Media.
See more in "Audio and telematics".
Telephone.
See more in "Audio and telematics".
Driving.
Allows the activation, deactivation and
adjustment of settings for certain functions.
Applications.
Allows the display of the trip
computer, with the monochrome
digital instrument panel.Volume / mute.
See more in "Audio and telematics".
- A ccess to Configuration
.
For more information on Heating
, Manual
air conditioning and Automatic air
conditioning , refer to the corresponding
sections.
The functions accessible from this menu are
arranged under two tabs: "Vehicle settings"
and " Driving functions ".
See more in "Audio and telematics".
Instruments

13
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
Driving menu
Vehicle settings tab
The functions are grouped into 4 families.Families Functions with CITROËN Connect Radio Functions with CITROËN Connect Nav
Driving
lighting -

"
Guide-me-home lighting": activation/deactivation of the
automatic guide-me-home lighting.
-

"
Welcome lighting": activation/deactivation of the exterior
welcome lighting.
-

"
Directional headlamps": activation/deactivation of the static
intersection lighting/directional lighting.
-

"
Daytime running lamps" (LED) depending on country of
sale. -

"
Directional headlamps": activation/deactivation of the static
intersection lighting/directional lighting.
-

"
Daytime running lamps": (LED) depending on country of
sale.
Vehicle
access -

"
Unlock driver's door": activation/deactivation of the
selective unlocking of the driver's door.
-

"
Unlock boot only": activation/deactivation of the unlocking
from the tailgate.
-

"
Motorised tailgate": activation/deactivation of the motorized
operation of the tailgate.
-

"
Hands-Free Tailgate Access": activation/deactivation of the
hands-free tailgate access function. -

"
Unlock driver's door": activation/deactivation of the
selective unlocking of the driver's door.
-

"
Unlock boot only": activation/deactivation of the unlocking
from the tailgate.
-

"
Motorised tailgate": activation/deactivation of the motorized
operation of the tailgate.
-

"
Hands-Free Tailgate Access": activation/deactivation of the
hands-free tailgate access function.
1
Instruments

14
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
FamiliesFunctions with CITROËN Connect Radio Functions with CITROËN Connect Nav
Comfort -

"
Rear wiper in reverse": activation/deactivation of the rear
wiper linked to reverse gear.
-

"
Mood lighting": activation/deactivation of the mood lighting.
-

"
Mirror adaptation in reverse": activation/deactivation of
the automatic tilting of the mirrors when reverse gear is
engaged. -

"
Rear wiper in reverse": activation/deactivation of the rear
wiper linked to reverse gear.
-

"
Guide-me-home lighting": activation/deactivation of the
automatic guide-me-home lighting.
-

"
Welcome lighting": activation/deactivation of the exterior
welcome lighting.
-

"
Mood lighting": activation/deactivation of the mood lighting.
-

"
Mirror adaptation in reverse": activation/deactivation of
the automatic tilting of the mirrors when reverse gear is
engaged.
Security -

"
Collision risk alert": activation/deactivation of the collision
risk alert.
-

"
Recommended speed display": activation/deactivation of
the speed limit recognition system.
-

"
Fatigue Detection System": activation/deactivation of the
driver fatigue detection system. -

"
Collision risk alert": activation/deactivation of the collision
risk alert.
-

"
Recommended speed display": activation/deactivation of
the speed limit recognition system.
-

"
Fatigue Detection System": activation/deactivation of the
driver fatigue detection system.
For more information on one of these functions, refer to the corresponding section.
Instruments

15
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
Driving functions tab
Corresponding functionComments
Adjusting Speeds Memorisation of speed settings for the speed limiter, cruise control or dynamic cruise control.
Under-inflation initialisation Reinitialisation of the under-inflation system.
Diagnostic List of current alerts.
Lane assist Activation/deactivation of the "active lane departure warning" function.
Parking sensors Activation/deactivation of the function.
Automatic headlamp dipping Activation/deactivation of the "Automatic headlamps" function.
Stop & Star t Activation/deactivation of the function.
Blind spot sensors Activation/deactivation of the function.
Panoramic visual aid Activation/deactivation of the function then choice of options.
Active cruise control Choice of the standard cruise control or the dynamic cruise control.
Traction control Activation/deactivation of the function.
For more information on one of these functions, refer to the corresponding section.
1
Instruments

16
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
ButtonComments
Turn off the screen.
Adjustment of brightness.
Choice and settings for three personalised profiles and one shared profile.
Settings for the touch screen and instrument panel...
Activation and adjustment of Wi-Fi settings.
Configuration
The functions available through the upper bar are detailed in the table below. Certain adjustments are accessible in the secondary page.
Instruments

17
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
ButtonComments
Adjustment of the display settings (scrolling of text, animations, etc.) and brightness.
Select a colour scheme for the 12 inch colour instrument panel.
Select the type of information displayed in the 12 inch colour instrument panel.
Choice of units:
-

t
emperature (°Celsius or °Fahrenheit)
-

d
istance and fuel consumption (l/100 km, mpg or km/l).
Choice of language used for the touch screen and the 12 inch colour instrument panel.
Setting the date and time.
1
Instruments

18
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
Monochrome digital instrument panel
1. Rev counter (x 1 000 rpm or tr/min), graduation depending on engine (petrol or
Diesel).
2.
G

ear efficiency indicator, selector position
and gear for an automatic gearbox.
3.
D

igital speedometer (mph or km/h).
4.
C

ruise control or speed limiter settings.
Dials and screens
5. Fuel gauge.
6. Service indicator, then total mileage
recorder (miles or km).
T

hese functions are displayed in turn when
the ignition is switched on.
7.
T

rip recorder (miles or km).
8.
R

ecall of heating and air conditioning
settings. A. M
ain lighting dimmer buttons.
B. R ecall of servicing information.
R

esetting of the function selected to zero
(service indicator or trip recorder).
R

ecall of the remaining driving range with
the SCR system and the AdBlue
®. W
arning log (current warnings).
Control buttons
Instruments
