Familiarisation
1. Fastening the buckle. 2.Height adjustment
Squeeze the control to slide it.


Front seat belts
230,231
Centre rear seat belt in the
2nd
row (fastening)
)
Pull the webbing and inser t the tongue Ainthe right hand buckle.)
Inser t tongue B
in the left hand buckle.


Outer rear seat belts
(stowing)
231, 232

Sitting comfortably
Guide the belt in and place the tongue on the
magnet of the outer anchorage.

24
Familiarisation

Optimise the use of your gearbox


With a manual gearbox, move off gently and change up without waiting. During acceleration change up early.


With an automatic or electronic gearbox, give preference to automatic mode and avoid pressing the accelerator pedal heavily or suddenly.


Control the use of your electrical
equipment


Before moving off, if the passenger compartment is too warm, ventilate it by opening the windows and air vents before using the air conditioning.
Above 30 mph (50 km/h), close the windows and leave the air ventsopen.
Remember to make use of equipment that can help keep the temperature in the passenger compar tment down (sunroof and windowblinds...).
Switch off the air conditioning, unless it has automatic digital regulation,as soon as the desired temperature is attained.
Switch off the demisting and defrosting controls, if not automatic.
Switch off the heated seat as soon as possible.


Switch off the headlamps and front foglamps when the level of lightdoes not require their use.


Avoid running the engine before moving off, par ticularly in winter; your vehicle will warm up much faster while driving.


As a passenger, if you avoid connecting your multimedia devices (film, music, video game...), you will contribute towards limiting the
consumption of electrical energy, and so of fuel.
Disconnect your por table devices before leaving the vehicle.

















































Eco-driving

Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.


Drive smoothly


Maintain a safe distance between vehicles, use engine braking rather than the brake pedal, and press the accelerator progressively. These practices contribute towards a reduction in fuel consumption and CO2emissions and also helps reduce the background traffic noise.


If your vehicle has cruise control, make use of the system at speedsabove 25 mph (40 km/h) when the traffic is flowing well.



The gear shift indicator invites you to change up: as soon as theindication to change up is displayed in the instrument panel, follow it straight away.
With an electronic or automatic gearbox, this indicator appears only in manual mode.

1
39
Monitoring

Operation indicator lamps

If one of the following indicator lamps comes on in the instrument panel, this confirms that the corresponding system has come into operation.

Warning / indicator lampStateCauseAction / Observations
Left-hand directionindicator
flashing with buzzer. The lighting stalk is pushed down.
Right-hand direction indicator
flashing with buzzer.The lighting stalk is pushed up.
Sidelamps

fixed. The lighting stalk is in the
"Sidelamps" position.
Dipped beamheadlamps fixed. The lighting stalk is in the "Dipped
beam headlamps" position.
Main beam headlamps
fixed. The lighting stalk is pulled towardsyou. Pull the stalk to return to dipped beam headlamps.

40
Monitoring
Automatic headlamp dipping
fixed.The lighting control stalk is in the
"AUTO" position, pulled towardsyou, and the function is activated (" Driving assistance" menu).
The system is in dipped beam modeas there is sufficient ambient lightand/or the traffic conditions do notallow illumination of main beam.The camera, located in the door mirror, mana
ges the
operation of main beam, depending on the ambient
lighting and driving conditions.
Pullin
g the lighting stalk again to deactivate.
For more information on this function, refer to the Visibility section.
fixed.The lighting control stalk is in the
"AUTO" position, pulled towardsyou, and the function is activated (" Driving assistance" menu).
The system is in main beam mode as the ambient lighting and trafficconditions allow it.
Warning / indicator lampStateCauseAction / Observations
Rear foglampsfixed.The rear foglamps are switched on. Turn the ring on the stalk rear wards to switch off the
rear foglamps.
Front foglampsfixed.The front foglamps are switched on. Turn the ring on the stalk rear wards twice to switch off
the front foglamps.

For more information on the lighting controls, refer to the corresponding section.

48
Monitoring
Low fuel levelfixed, accompanied by an audible signal anda message.Wh
en it first comes on there remainsapproximately 6 litres offuelin thetank.
You are then usin
g the fuel reser ve. You must refuel as soon as possible to avoid runnin
gout of fuel.
Until sufficient fuel is added, this warning lamp will
come on every time the ignition is switched on,
accompanied by an audible signal and a message.This audible signal and message are repeated with
increasing frequency as the drops towards "0".
Fuel tank capacity: approximately 57 litres (petrol) or 55 litres (Diesel).
Never continue to drive until you run out of fuel as
this could damage the emission control and injectionsystems.
Warning / indicator lampStateCauseAction / Observations
Seat belt(s) not fastened / unfastened
fixed
or flashingaccompanied by anaudible signal. A
seat belt has not been fastened or has been unfastened.Pull the strap then inser t the tongue in the buckle.
Airbagson temporarily. This lamp comes on for a fewseconds when you turn on the
ignition, then goes off. This lamp should
go off when the engine is started.
If it does not go off, contact a CITROËN dealer or a
qualified workshop.
fixed.One of the airbag or seat beltpretensioner systems has a fault.Have it checked by a CITROËN dealer or a qualified
workshop.
Passenger airbag systemflashing. The passenger airbag system has afault. Do not have a passenger seated in the frontpassenger seat
Have it checked by a CITROËN dealer or a qualified
workshop.

68
Access





Emergency procedure
The integral key is used to lock and unlock the
vehicle when the electronic key cannot operate
and in the event of a fault with the Keyless Entry and Star ting system:
- cell battery flat, vehicle battery discharged
or disconnected, ...
- vehicle located in an area with stron
g
electromagnetic signals.
Emergency unlocking/locking
using the integral key
Unlocking
)
Tu r n t h e k ey towards the front of the vehicle
to unlock the vehicle.



Depending on your version, the direction indicators flash for a fewseconds, the door mirrors unfold andthe welcome lighting comes on.
If the alarm was activated, the siren willsound on opening the door with the key (in the remote control). It stops whenthe ignition is switched on.
)Press and hold the latch 1to extract the integral key 2.The integral key is also used to deactivate/reactivate the passenger's airbag.
It provides a backup means of locking thepassenger doors.
It also allows locking of the vehicle without activation of the alarm.

69
2
Access

Normal locking
)Turn the key towards the rear of the vehicle
to lock the vehicle completely.

Deadlocking
)Turn the key towards the rear in the driver's door lock to lock the vehicle completely.)Turn the key towards the rear again withinfive seconds to deadlock the vehicle.
Depending on your version, the direction indicators flash for a few seconds, the door mirrors fold.
If your vehicle has an alarm, thisfunction is not activated by locking withthe integral key.

76
Access






Motorised tailgate
Check that there is enough space to allow for
the movement of the tailgate.

Activation and deactivation of the motorised
tailgate function is done in the "Drivingassistance " menu, then " Vehicle settings
".
This function is deactivated by default.
Tailgate controls
A: Exterior control
B: Interior control
Never place a finger in the tailgatelocking system: risk of a seriousaccident!


The tailgate is not designed to suppor t a bicycle carrier.
When installing a bicycle carrier on atowbar, it is essential to deactivate theautomatic operation.
To avoid the risk of injury, ensure thatthere is no person close to the rear of the vehicle when opening and closing the motorised tailgate. Be careful of rear passengers.
The motorised tailgate has an obstacle detection system that automatically interrupts its operation if it contacts an obstacle (the movement is reversed bya few degrees to allow the tailgate tobe freed).

95
3
Comfort

Repositioning a seat


Before operating the rear seats, check that the outer rear seat belts are notloose, to avoid damaging them. The
centre belt must be stowed. Fix the tongues of the three belts to their anchorage points.
Continuity panels
These continuity panels are not designed to support a weight greater than 30 kg.Releasin
g / locking the continuity panels) Before unfolding the continuity panels, check that the seats in the 2 ndrow are fullyback. )
Slide the continuity panel latch upwards to
release. ) Straighten the continuity panel, then slide
the latch downwards to lock it.
)If necessary, straighten the continuity panels for the seats in the 2nd row and lockthem in place.)Raise the backrest and push it rear wards
until it locks in position

Each seat has a continuity panel at the bottom
of the backrest, that once unfolded:
- provides a continuous load surface in the boot, whatever the position of the seats,
- avoids objects sliding under the seats in
the 2nd row.

96
Comfort
Access to the third row
seats
Access to the third-row seats is via the outer second-row seats.
)Pull the lever E
. The seat unlocks andthe seat cushion comes up against thebackrest. )Hold the lever E
in the raised position, pushing for wards. The whole seat slides
towards the front seat. Space becomes free behind the seat, the third-row passengers can get to their seats.





Leaving the vehicle from
the third-row seats
Repositioning a seat, from
the outside, with the door
open

In the event of a failure of this system(lever E ), the passengers in the thirdrow can also leave the vehicle after first folding the backrests of the second-row seats using the strap D. Do not allow children to operate the seats without supervision.
)
Lift the lever E. The seat unlocks andthe seat cushion comes up against the backrest.
)
Push the seat backrest, still holding the lever E
in the raised position.
If there are passen
gers seated in the third row:)manually return the assembly as far as possible rear wards; the seat does not return to the fully back position, soas to retain legroom for the third-row passengers,)fold the seat cushion until it locks.
Ensure that there is no object on or under the seat that you want to move.


Before operating the seats, ensure that the tables on the back of the first-row
seats are folded away.
