engine Citroen GRAND C4 PICASSO RHD 2017 2.G Owner's Manual

321
Running out of fuel (Diesel)
On vehicles fitted with Diesel engines, the fuel
system must be primed if you run out of fuel.
For all versions other than BlueHDi, refer to the
corresponding engine compartment view.Other HDi engines
(except BlueHDi version)
For more information on Diesel misfuel
prevention , refer to the corresponding
section.
If the engine does not start first time,
don't keep trying but start the procedure
again from the beginning.
BlueHDi engines
F Fill the fuel tank with at least five litres of Diesel.
F

S
witch on the ignition (without starting the
engine).
F

W
ait around 6 seconds and switch off the
ignition.
F

R
epeat the operation 10 times.
F

O
perate the starter to run the engine. F

A
dd at least five litres of Diesel fuel to the
tank.
F

O
pen the bonnet.
F

I
f necessary, unclip the styling cover for
access to the priming pump.
F

S
queeze and release the priming pump
repeatedly until resistance is felt (there
may be resistance at the first press).
F

O
perate the starter to start the engine
(if the engine does not start at the first
attempt, wait around 15 seconds before
trying again).
F

I
f the engine does not start after a
few
attempts, operate the priming pump
again then start the engine.
F

R
efit the styling cover and clip it in place.
F

C
lose the bonnet.
8
In the event of a breakdown

322
Petrol enginePureTech 110 S&SPureTech 130 S&S
Gearbox Manual (6-speed)Manual (6-speed)EAT6 automatic (6 -speed)
Model code 3D
3D... 3E... 3A... 3D... 3E... 3A...
HNX...
M/1S - M/2SM HNY…
M/1S - M/2SM HNY…
T/1S - T/2S
Cubic capacity (cc) 1 199
Bore x stroke (mm) 75 x 90.5
Max power*: EU standard (kW) 96
Max power engine speed (rpm) 5 500
Max torque: EU standard (Nm) 230
Max torque engine speed (rpm) 1 750
Fuel Unleaded
Catalytic converter yes
Engine oil capacity (in litres)
(with filter replacement) 4.25
Petrol engines and gearboxes
3D...:
CITROËN C4 Picasso (5 -seat). 3A...: CITROËN Grand C4 Picasso (7-seat).
3E...: CITROËN Grand C4 Picasso (5 -seat).
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
Technical data

323
3D...: CITROËN C4 Picasso (5 -seat). 3A...: CITROËN Grand C4 Picasso (7-seat).
3E...: CITROËN Grand C4 Picasso (5 -seat).
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
** For Israel. Petrol engine
THP 150 / 160THP 165 S&S THP 165 S&S**
Gearbox EAT6 automatic (6 -speed) EAT6 automatic (6 -speed) EAT6 automatic (6 -speed)
Model code 3D... 3E... 3A...
3D... 3E... 3A...3D... 3E... 3A...
5GX - 5GY...
A-A/1-A/2-A/D- A/1D- A/2D- Y-Y/1-Y/ 2 5G Z T/S
5GY...
A /S - A /1S - A /2S
Cubic capacity (cc) 1 5981 5981 598
Bore x stroke (mm) 77 x 85.877 x 85.877 x 85.8
Max power*: EU standard (kW) 110 / 121121121
Max power engine speed (rpm) 6 0006 0006 000
Max torque: EU standard (Nm) 240240240
Max torque engine speed (rpm) 1 4001 4001 400
Fuel UnleadedUnleadedUnleaded
Catalytic converter yesyesyes
Engine oil capacity (in litres) (with filter
replacement) 4.25
4.254.25
9
Technical data

324
* The weight values are calculated with a towbar.
** The kerb weight is equal to the unladen weight + driver (75 kg).
***
T
he weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Petrol engine
PureTech 110 S&S*PureTech 130 S&S*
Gearbox Manual (6-speed)Manual (6-speed)EAT6 automatic (6 -speed)
Model code 3D
3D... 3E... 3A... 3D... 3E... 3A...
HNX...
M/1S - M/2SM HNY…
M/1S - M/2SM HNY…
T/1S - T/2S
Unladen weight 1 2801 280 - 1 295 - 1 297 1 298 - 1 315 - 1 317
Kerb weight** 1 3551 355 - 1 370 - 1 372 1 373 - 1 390 - 1 392
Gross vehicle weight (GV W) 1 9051 905 - 2 075 - 2 125 1 918 -1 957 - 2 136
Gross train weight (GTW)
on a 12% gradient 3 035
3 175 - 3 125 - 3 175 3 188 - 3 007 - 3 186
Braked trailer (within the GTW limit)
on a 10% or 12% gradient 1 130
1 270 - 1 050 - 1 050 1 270 - 1 050 - 1 050
Braked trailer*** (with load transfer within the
GTW limit) 1 330
1 470 - 1 350 - 1 350 1 470 - 1 350 - 1 350
Unbraked trailer 640640 - 647 - 648 640 - 647 - 648
Recommended nose weight 707070
Petrol weights and towed loads (in kg)
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
When towing, the speed must never exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High exterior temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the exterior temperature is above 37 °C,
limit the towed load.
Technical data

325
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
When towing, the speed must never exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High exterior temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the exterior temperature is above 37 °C,
limit the towed load.Petrol engine
THP 150 / 160THP 165 S&STHP 165 S&S***
Gearbox EAT6 automatic (6 -speed) EAT6 automatic (6 -speed) EAT6 automatic (6 -speed)
Model code 3D... 3E... 3A...
3D... 3E... 3A...3D... 3E... 3A...
5GX - 5GY...
A-A/1-A/2-A/D- A/1D- A/2D- Y-Y/1-Y/ 2 5G Z T/S
5GY...
A /S - A /1S - A /2S
Unladen weight 1 405 - 1 428 - 1 4301 310 - 1 318 - 1 3201 390 - 1 425 - 1 425
Kerb weight* 1 480 - 1 503 - 1 5051 385 - 1 393 - 1 3951 465 - 1 500 - 1 500
Gross vehicle weight (GV W) 1 940 - 2 140 - 2 1601 930 - 2 100 - 2 1501 930 - 2 100 - 2 150
Gross train weight (GTW)
on a 12% gradient 2 740 - 2 940 - 2 960
3 330 - 3 350 - 3 350 3 330 - 3 350 - 3 350
Braked trailer (within the GTW limit)
on a 10% or 12% gradient 800
1 400 - 1 250 - 1 200 1 400 - 1 250 - 1 200
Braked trailer** (with load transfer within the
GTW limit) 800
1 600 - 1 550 - 1 500 1 600 - 1 550 - 1 500
Unbraked trailer 600685 - 690 - 690 685 - 690 - 690
Recommended nose weight 707070
* The kerb weight is equal to the unladen weight + driver (75 kg).
**
T
he weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
*** For Israel.
9
Technical data

326
Diesel engines and gearboxes
.../S: e-HDi model fitted with Stop & Start.
3D...: CITROËN C4 Picasso (5 -seat). 3E...:
CITROËN Grand C4 Picasso (5 -seat).
3A...: CITROËN Grand C4 Picasso (7-seat).
Diesel engine
HDi 115BlueHDi 100 S&S
Gearbox Manual (6-speed)Manual (6-speed)
Model code 3D... 3E... 3A...
3D... 3E... 3A...
9HC... 8 - 8/1 BHY...
6/1S - 6/2SM
Cubic capacity (cc) 1 5601 560
Bore x stroke (mm) 75 x 88.375 x 88.3
Max power*: EU standard (kW) 8573
Max power engine speed (rpm) 3 6003 750
Max torque: EU standard (Nm) 270254
Max torque engine speed (rpm) 1 7501 750
Fuel DieselDiesel
Catalytic converter yesyes
Particle filter noyes
Engine oil capacity, with filter replacement
(in litres) 3.75
3.75
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
Technical data

327
Diesel engines and gearboxes
.../S: e-HDi model fitted with Stop & Start.
3D...: CITROËN C4 Picasso (5 -seat). 3E...:
CITROËN Grand C4 Picasso (5 -seat).
3A...: CITROËN Grand C4 Picasso (7-seat).
Diesel engine
BlueHDi 115/120 S&SBlueHDi 135/15 0 S&S
Gearbox Manual (6-speed)EAT6 automatic
(6-speed) Manual (6-speed) EAT6 automatic
(6-speed)
Model code 3D... 3E... 3A... 3D... 3E... 3A... 3D... 3E... 3A... 3D... 3E... 3A...
BHZ - BHX...M/S - M/1S BHZ - BHX...
T/1S - T/2S AHX-AHR-AHV-AHS...
M/S - M/1S AHX...
T/S - T/1S
Cubic capacity (cc) 1 5601 997
Bore x stroke (mm) 75 x 88.385 x 88
Max power*: EU standard (kW) 85 / 8811 0
Max power engine speed (rpm) 3 5003 750
Max torque: EU standard (Nm) 300370
Max torque engine speed (rpm) 1 7501 750
Fuel DieselDiesel
Catalytic converter yesyes
Particle filter yesyes
Engine oil capacity, with filter replacement
(in litres) 3.75
6 .1
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
9
Technical data

328
Diesel weights and towed loads (in kg)
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
When towing, the speed must never exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High exterior temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the exterior temperature is above 37 °C,
limit the towed load.Diesel engine
HDi 115BlueHDi 100 S&S*
Gearbox Manual (6-speed)Manual (6-speed)
Model code 3D... 3E... 3A...
3D... 3E... 3A...3D... 3E... 3A...
9HC8 9HC8/1 BHY...
6/1S - 6/2SM
Unladen weight 1290 - 1 310 - 1 3121 298 - 1 318 - 1 320 1 296 - 1 318 - 1 320
Kerb weight** 1 365 - 1 385 - 1 3871 373 - 1 393 - 1 395 1 371 - 1 393 - 1 395
Gross vehicle weight (GV W) 1 940 - 2 110 - 2 1501 940 - 2 110 - 2 1501 950 - 2 120 - 2 175
Gross train weight (GTW)
on a 12% gradient 3 340 - 3 350 - 3 350
2 740 - 2 910 - 2 9503 150 - 3 120 - 3 175
Braked trailer (within the GTW limit)
on a 10% or 12% gradient 1 400 - 1240 - 1 200
8001 200 - 1 000 - 1 000
Brakes trailer***
(with load transfer within the GTW limit) 1 600 - 1 540 - 1 500
8001 400 - 1 300 - 1 300
Unbraked trailer 680 - 690 - 690685 - 695 - 695645 - 659 - 660
Recommended nose weight 707070
* The weights are calculated with a towbar fitted.
** The kerb weight is equal to the unladen weight + driver (75 kg).
***
T
he weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Technical data

329
Diesel weights and towed loads (in kg)
* The kerb weight is equal to the unladen weight + driver (75 kg).
* * T he weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
When towing, the speed must never exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High exterior temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the exterior temperature is above 37 °C,
limit the towed load. Diesel engine
BlueHDi 115/120 S&SBlueHDi 135/150 S&S
Gearbox Manual (6-speed)EAT6 automatic
(6-speed) Manual (6-speed) EAT6 automatic
(6-speed)
Model code 3D... 3E... 3A... 3D... 3E... 3A... 3D... 3E... 3A... 3D... 3E... 3A...
BHZ - BHX...M/S - M/1S BHZ - BHX...
T/1S - T/2S AHX-AHR-AHV-
AHS...
M/S - M/1S AHX...
T/S - T/1S
Unladen weight 1 320 - 1 345 - 1347 1 320 - 1 357 - 1 359 1 415 - 1 428 - 1 430 1 435 - 1 474 - 1 476
Kerb weight* 1 395 - 1 420 - 1 422 1 395 - 1 432 - 1 434 1 490 - 1 503 - 1 505 1 510 - 1 549 - 1 551
Gross vehicle weight (GV W) 1 950 - 2 100 - 2 175 1 975 - 2 025 - 2 205 2 030 - 2 200 - 2 250 2 030 - 2 200 - 2 280
Gross train weight (GTW)
on a 12% gradient 3 350 - 3 350 - 3 375 3 375 - 3 225 - 3 405 3 530 - 3 560 - 3 650 3 530 - 3 580 - 3 580
Braked trailer (within the GTW limit)
on a 10% or 12% gradient 1 400 - 1 250 - 1 200 1 400 - 1 200 - 1 200 1 500 - 1 450 - 1 400 1 500 - 1 380 - 1 300
Braked trailer**
(with load transfer within the GTW limit) 1 600 - 1 550 - 1 500 1 600 - 1 500 - 1 500 1 700 - 1 750 - 1 700 1 700 - 1 680 - 1 600
Unbraked trailer 660 - 672 - 674 660 - 675 - 675 745 - 750 - 750 750
Recommended nose weight 70707070
9
Technical data

332
Accessories ..........................................129, 226
Accessory position ....................................... 12
9
Access to the 3rd row

..................................... 88
A

ctive Safety Brake................... 27, 32, 175, 177
AdBlue
® additive ................ 1 9, 36, 43, 279, 280
Adjusting head restraints ................................ 80
A
djusting the air distribution
.....................9
6, 99
Adjusting the air flow

.................................9
6, 99
Adjusting the date

........................................... 52
A

djusting the height and reach
of the steering wheel

.................................... 93
A

djusting the seat
........................ 7
6, 78, 84, 86
Adjusting the seat belt height

.......................23

3
Adjusting the temperature

........................9
6, 99
Adjusting the time

........................................... 52
A

dvice on care and maintenance
.................2

78
Advice on driving

..............................
....12 2, 123
Airbags
...............

.....................................33, 238
Airbags, curtain
..................................... 2

40, 241
Airbags, front......................................... 239, 241
Airbags, lateral
...................................... 2

40, 241
Air conditioning
...............................

............9, 98
Air conditioning, automatic

.......................9
5, 99
Air conditioning, manual
...........................9

5, 97
Air intake

...............
.......................................... 99
Air vents
..............................

............................94
Alarm
............................................................... 71
A

nti-lock braking system (ABS)
....................23

0
Anti-pinch
...................................................... 2

25
Anti-slip regulation (ASR)

............................. 23

0
Anti-theft
..............................

.........................129
Armrest, front

..........................................8
3, 107
Assistance call
...............................

...............228
Assistance, emergency braking
...........1

78, 230
Automatic headlamps
..................................... 24B

attery
...............................
..... 267, 277, 315 -318
Battery, charging
...............................
............
317
Battery, remote control
.............................5
9, 60
Black panel ...................................................... 48
Black screen .............................. .....................
48
Blanking screen (snow shield) ......................26
3
Blind, panoramic sunroof

..............................2

25
Blind spot monitoring system

..........2
5, 184, 186
Blind spot monitoring system, assisted
................

.................................25, 186
Blind spot sensors

..................................2
5, 184
Blinds, side

............................................ 1
08, 113
BlueHDi
...............................

............43, 282, 321
Bonnet
...............

............................................271
Boot
........

.........................................................64
Boot (fittings)

...............................
..................11 6
Boot (opening)

...............................
..................53
Bottle holder

...............................
...................107
Brake discs

....................................................2

78
Brake lamps

...............................
...........305-308
Brakes
...............................................3

0, 35, 278
Braking, automatic emergency
............. 2

7, 32, 175, 177
Braking, dynamic emergency
............... 13

0, 13 5
Bulbs (changing)
........................... 3

01, 305-308Cartridge, fragrance
.....................................
10
5
Central locking
................................... 5
4, 56, 57
Changing a bulb
............................ 3
01, 305-308
Changing a fuse ............................................ 31 0
Changing a wheel ............................... ..
291-294
Changing a wiper blade ........................2 24, 268
Changing the remote control battery

..............59
C

hecking the engine oil level
..........................42
C

hecking the levels
................................2

74-276
Checking tyre pressures (using the kit)

..............................
................284
Checks
...............

................... 272, 273, 277, 278
Child lock

...............................
........................258
Children
...............................

. 249, 252, 253, 255
Children (safety)
...............................

.............258
Child seats

............ 2
37, 242, 243, 247-249, 257
Child seats, conventional

..............................24

8
Child seats, ISOFIX

......................25

1-253, 255
Citroën Connect Box

....................................2

28
Citroën Localised Emergency Call

...............2

28
Closing the boot

...............................
...............64
Closing the doors

............................... 5
4, 56, 57
Collision Risk Alert

.................... 2
7, 32, 175, 176
Configurations, seats
...................................... 91
C

onfiguration, vehicle
............................... 1
1, 13
Control, emergency boot release

...................68
C

ontrol, emergency door
................................63
C

ontrol, heated seats
......................................8

2
Control stalk, lighting

......................2
4, 208, 212
Control stalk, wipers

.....................2
20, 221, 223
Courtesy lamps

.............................................12

0
Cruise control
........................ 1

48, 151, 156, 166
Cruise control, dynamic

................................15

9
Cruise control by speed limit recognition
.................................................. 1

51
Cruise control, dynamic with Stop function

........................16

6
Cup holder

...............................
......................107
AB
Capacity, fuel tank .............................. ..........259
Cap, fuel filler ................................................ 25
9
C
Alphabetical index
