65
Driving with the doors locked may
render access for the emergency
services difficult in an emergency. If your vehicle is not fitted with an
alarm, locking is confirmed by fixed
illumination of the direction indicators
for about two seconds.
Depending on version, the door mirrors
fold at the same time.
Deadlocking
Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
locking button.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.
F

To totally lock the vehicle, with the remote
control in the recognition zone A , press
with a finger or thumb at the markings on
one of the front or manual sliding side door
handles.
F

T

o deadlock the vehicle, press the marking
again within five seconds .
Ensure that no one might prevent the
correct operation of the windows.
Be particularly aware of children when
operating the windows. If fitted to your vehicle, pressing and
holding the locking controls allows
the windows to be opened. The
window stops when you release the
button.
With a tailgate
F To lock the vehicle, with the remote control
in the recognition zone A , press the
tailgate locking control.
2
Access

72
Locking the vehicle
This button is inoperative if the vehicle
has been locked or deadlocked from
outside (using the key, remote control or
Keyless Entry and Starting, according
to equipment) or if one of the doors is
still open.
Automatic
The cabin doors lock automatically while
driving (speed above 6 mph (10 km/h)); the
indicator lamp comes on.When carrying long objects with the
tailgate or rear doors open, you can
press this button to lock just the cabin
doors.
When locking from inside, the door
mirrors do not fold.
The indicator lamp also goes off when
unlocking one or more doors.
Driving with the doors locked may make
access to the passenger compartment
by the emergency services more
difficult in an emergency.
F
T
o activate or deactivate this
function, with the ignition on,
press this button until a message
appears in the screen. F

P
ress this button.
F
P
ress this button.
If the vehicle is deadlocked or locked
with the remote control or the door
handles, the button is not active. In this
case, use the key or the remote control
to unlock.
Manual
The indicator lamp comes on to confirm the
locking. The indicator lamp goes off to confirm the
unlocking.
Unlocking the vehicle
Locking / unlocking from inside
Access

73
F Vehicle unlocked, press this button.
F

L
oading area locked, press this
button. For more information on the Key,
Remote control
or Keyless Entr y
and Starting , and in particular,
programming the selective locking
of the loading area, refer to the
corresponding section.
This button is inoperative if the vehicle
has been locked or deadlocked from
outside (using the key, remote control or
Keyless Entry and Starting, depending
on equipment) or if one of the doors is
still open. Driving with the doors locked may make
access to the passenger compartment
by the emergency services more
difficult in an emergency.
The indicator lamp goes off when one
or more of the loading area
doors is
unlocked.
To save energy, with the ignition off and
the vehicle totally locked, the indicator
lamp goes off.
To deactivate this automatic locking,
go to a CITROËN dealer or a qualified
workshop.
Automatic
The loading area doors always lock while
driving.
Locking / unlocking
the loading areaManual
The indicator lamp comes on to confirm the
locking of the vehicle .
F

V
ehicle locked, press this button.
The indicator lamp goes off to confirm the
unlocking of the vehicle .
Cab
and loading area selectivity
deactivated.
Cab and loading area selectivity
activated.
F

L
oading area unlocked, press
this button.
The indicator lamp comes on to confirm the
locking of the loading area .
The indicator lamp goes off to confirm the
unlocking of the loading area .
2
Access

160
Automatic operation of
hazard warning lamps
Hazard warning lamps
When braking in an emergency, depending on
the rate of deceleration, as well as when the
ABS regulation is invoked or in the event of an
impact, the hazard warning lamps come on
automatically.
They switch off automatically the first time you
accelerate.
F
Y
ou can also switch them off by pressing
the button.
Visual warning with all of the direction
indicators flashing to alert other road users to
a

vehicle breakdown, towing or accident.
Emergency or
assistance call
This system allows you to make an emergency
or assistance call to the emergency services or
to the dedicated CITROËN service.
For more information on Audio and
telematics and in particular the
use of this equipment, refer to the
corresponding section.
F

P

ress this button, all of the direction
indicators flash.
They can operate with the ignition off.
Safety

278
Checking levels
Take care when working under the bonnet, as certain areas of the engine may be extremely hot (risk of burns) and the cooling fan could start at
any time (even with the ignition off).
Engine oil level
The check is carried out either when
the ignition is switched on using the
oil level indicator in the instrument
panel for vehicles so equipped, or
using the dipstick.Checking using the dipstick
The location of the dipstick is shown in the
corresponding underbonnet layout view.
F
T
ake the dipstick by its coloured grip and
remove it completely.
F

W
ipe the end of the dipstick using a clean
non-fluffy cloth.
F

R
efit the dipstick and push fully down, then
pull it out again to make the visual check:
the correct level is between the marks A
and B .
Check all of these levels regularly, in line with the manufacturer's service schedule. Top them up if necessary, unless other wise indicated.
If a level drops significantly, have the corresponding system checked by a CITROËN dealer or a qualified workshop.
A = MA X
To ensure that the reading is correct, your
vehicle must be parked on a level sur face
with

the engine having been off for more than
30 minutes.
It is normal to top-up the oil level between
two services (or oil changes). CITROËN
recommends that you check the level, and
top-up if necessary, every 3 000 miles
(5 000 kms). B = MIN
If you find that the level is above the A mark or
below the B mark, do not star t the engine .
-

I
f the level is above the MAX mark (risk
of damage to the engine), contact a
CITROËN dealer or a qualified workshop.
-

I
f the level is below the MIN mark, you
must top-up the engine oil.
Practical information

279
Oil grade
Before topping-up the oil or changing the oil,
check that the oil is the correct grade for your
engine and conforms to the manufacturer's
recommendations.
Topping-up the engine oil level
The location of the oil filler cap is shown in the
corresponding underbonnet layout view.
F
U
nscrew the oil filler cap to reveal the filler
aperture.
F

A
dd oil in small quantities, avoiding any
spills on engine components (risk of fire).
F

W
ait a few minutes before checking the
level again using the dipstick.
F

A
dd more oil if necessary.
F

A
fter checking the level, carefully refit the
oil filler cap and the dipstick in its tube.
After topping-up the oil, the check when
switching on the ignition with the oil
level indicator in the instrument panel
is not valid during the 30 minutes after
topping-up.
Engine oil change
Refer to the manufacturer's service schedule
for details of the interval for this operation.
In order to maintain the reliability of the engine
and emission control system, never use
additives in the engine oil. The brake fluid level should be close
to the "MA X" mark. If it is not, check
the brake pad wear.
Brake fluid level
Changing the fluid
Refer to the manufacturer's service schedule
for details of the interval for this operation.
Fluid specification
The brake fluid must conform to the
manufacturer's recommendations.
Coolant level
The coolant level should be close
to the "MA X" mark but should never
exceed it.
In addition, as the cooling system is pressurised,
wait at least one hour after switching off the
engine before carrying out any work.
To avoid any risk of scalding, unscrew the cap
by two turns to allow the pressure to drop. When
the pressure has dropped, remove the cap and
top up the level. The cooling fan may star t after switching
off the engine: take care with ar ticles and
clothing that might be caught by the fan
blades. When the engine is warm, the temperature of
the coolant is regulated by the fan.
Check the coolant level regularly, according
to the use made of your vehicle (every
3 000

miles or 5 000 kms / 3 months); if
necessary, top-up using coolant recommended
by the manufacturer.
Topping-up the coolant between services is
normal.
Power steering
fluid level
The power steering fluid level should
be close to the "MA X" mark. With
the engine cold, unscrew the cap to
check the level.
7
Practical information

338
Emergency or assistance call
If an impact is detected by the airbag
control unit, and independently of
the deployment of any airbags, an
emergency call is made automatically.
Localised Emergency Call
In an emergency, press this
button for more than 2 seconds.
Flashing of the green indicator
lamp and a voice message
confirm that the call has
been made to the "Localised
Emergency Call"* centre.
Pressing this button again immediately cancels
the call.
The green indicator lamp goes off.
At any time, pressing this button for more than
8 seconds cancels the call.
The green indicator lamp remains on (without
flashing) when communication is established.
It goes off at the end of the call.
This call is dealt with by the "Localised
Emergency Call" centre, which receives
locating information from the vehicle and
can send a detailed alert to the appropriate
emergency services.
In countries in which a centre is not
operational, or when the locating service
has been expressly declined, the call is dealt
with directly by the emergency services (112)
without the vehicle location. *

T
hese services are subject to conditions and
availability.
C

onsult a CITROËN dealer.If you benefit from the C
ITROËN

C

onnect Box offer with the SOS and
assistance pack included, there are
additional services available to you in
your MyCITROËN personal space, via
the Internet website for your country.
Audio and Telematics

339
Localised Assistance Call
If you purchased your vehicle outside
the CITROËN dealer network, we
invite you to have a dealer check the
configuration of these services and, if
desired, modified to suit your wishes.
In a multi-lingual country, configuration
is possible in the official national
language of your choice.
For technical reasons, particularly
to improve the quality of Telematic
services to customers, the
manufacturer reserves the right to
carry out updates to the vehicle's on-
board telematic system.
The fault with the system does not
prevent the vehicle being driven. Press this button for more than
2 seconds to request assistance
if the vehicle breaks down.
A voice message confirms that
the call has been started*.
Pressing this button again immediately cancels
the request.
The cancellation is confirmed by a voice
message.
Geo-location
You can deactivate geo-location by
simultaneously pressing the "Localised
Emergency Call" and "Localised Assistance
Call" buttons, followed by a press on "Localised
Assistance Call" to confirm.
To reactivate geo-location, simultaneously
press the "Localised Emergency Call" and
"Localised Assistance Call" buttons again,
followed by a press on "Localised Assistance
Call" to confirm.
The orange indicator lamp is on fixed: the back-
up battery should be replaced.
In both cases, the emergency and assistance
calls service may not work.
Contact a qualified repairer as soon as
possible.
Operation of the system
When the ignition is switched on,
the green indicator lamp comes
on for 3 seconds indicating that
the system is operating correctly.
The orange indicator lamp
flashes then goes off: the system
has a fault.
*



T
hese services are subject to conditions and
availability.
Consult a CITROËN dealer.
.
Audio and Telematics

510
Radio ................... 394, 398, 450, 454, 488, 489
Radio, digital (Digital Audio Broadcasting - DA B) ................................... 396, 397, 452, 453
Radio Media

........ 3
88, 390, 392, 444, 446, 448
Range
................

.............................................. 42
S
R
Range, AdBlue® ..............................................35
RDS ................
.......................................395, 451
Rear screen, demisting
......................... 13

3, 13 4
Recharging the battery

................................. 32

3
Recirculation, air
................... 1

25, 126, 128, 131
Reduction of electrical load

.......................... 2

70
Regeneration of the particle filter

.................2

81
Reinitialisation of the under-inflation detection system

......................................... 26

3
Reinitialising the remote control

...............5
4, 70
Reminder, key in ignition

............................... 2

01
Reminder, lighting on

.................................... 14

8
Remote
control
...... 4

7-50, 52, 55 -59, 67, 68, 71, 74, 75
Removing a wheel

..............................
..........299
Removing the mat

...............................
..........11 9
Replacing bulbs
..... 3

03, 304, 310, 311, 313 -315
Replacing fuses
..............................

......316, 317
Replacing the air filter

................................... 2

81
Replacing the oil filter

................................... 2

81
Replacing the passenger compartment
filter
........

..................................................... 281
Reservoir, headlamp wash

........................... 28

0
Reservoir, screenwash
................................. 28

0
Resetting the service indicator

.......................33
R

esetting the trip recorder
.............................. 38
R

ev counter
................................................ 1

4 -16
Reversing camera
...............................

..........259
Reversing camera (on interior mirror)

....................................... 25

8
Reversing lamp
............................. 3

10, 313, 315
Roof bars
...............................................2

72, 273
Roof rack

...............................................2
72, 273
Running out of fuel (Diesel)

.......................... 3

27Safety, children
......................1 71, 174-176, 182,
187, 188, 190, 193
Saturation of the particle filter (Diesel)

.........2

81
Screen, instrument panel

.......................... 4
0, 41
Screen menu map

............... 3
52, 354, 356, 358,
360, 362, 370, 372, 374, 378, 384,
386, 388, 390, 392, 400, 402, 404,
412, 414, 416, 434, 440, 442, 444,
446, 448, 456, 458, 460, 468, 470, 472
Screen, multifunction
(with audio system)

.....................................4
87
Screenwash
..............................

....................15 8
Screenwash, rear
...............................

...........157
SCR (Selective Catalytic Reduction)

............28

3
Seat and bench seat, rear, fixed

...........11

3 , 11 6
Seat and bench seat, rear, on rails

...............11

6
Seat belts
......................1

66, 168, 169, 180, 181
Seat belts, rear
...............................

...............167
Seat, front bench, 2-seat

......................10

4, 167
Seat, rear bench
..............................

.............11 6
Seats, electric
............................................... 10

2
Seats, front
...............................

....... 99, 101, 102
Seats, front bench
...............................

..........105
Seats, heated
...............................

.........103, 105
Seats, rear
............................................. 11

0 , 113
Selector, gear
................................................ 2

14
Serial number, vehicle

..................................3

37
Service indicator
....................................... 3

1, 33
Service (warning lamp)

...................................28
S

ervicing
...............................
..........................12
Settings
...............

.. 412, 414, 416, 468, 470, 472
Settings, system

...............................
..... 420, 476
Sidelamps
............. 1

46, 304-306, 310, 313, 315
Side repeater
..............................

..................305
Sliding side door, electric
............................ 4

9, 57, 64, 65, 78 - 84
Sliding side door, hands-free

.............. 87
, 89, 90
Sliding side door, manual

.........................7

5 -77
Sliding side window

......................................12

4
Pads, brake ...................................................
28
2
Paint colour code
.......................................... 3
37
Parking brake

..................................1

8, 205, 282
Parking sensors, audible and visual

....................................... 25

6
Parking sensors, front

................................... 25

6
Parking sensors, rear............................255, 256
Plates, identification ...................................... 337
Platform cab

......................................... 3

15, 332
Player, Apple
® .............................. 3 99, 455, 495
Player, MP3 CD ............................... ..............494
Player, USB

.................................. 3
98, 454, 492
Port, USB

............................. 1
22, 398, 454, 492
Pressures, tyres
................... 2

90, 295, 302, 337
Pre-tensioning seat belts

.............................. 16

9
Priming pump
...............................

.................327
Priming the fuel system

................................ 3

27
Profiles
.................................................. 4

18, 474
Protecting children

.................1
71, 174-176, 182,
187, 188, 190, 193
Puncture
................

........................................ 290
P
Alphabetical index

512
W
Warning and indicator lamps ..........................17
W arning lamp, braking system .......................18
W
arning lamp, Diesel engine pre-heater
.......21
W

arning lamp, door(s) open
...........................20
W

arning lamp, driver's seat belt not
fastened
...............

....................................... 168
Warning lamps
................................................ 17
W

arning lamp, SCR emissions control
system

................
........................................... 27
Warning lamp, seat belts

..............................16

8
Warning lamp, Service.................................... 28
Warning lamp, Stop

........................................ 18
W

arning lamp, water in Diesel filter
................20
W

asher jets, heated
.............................. 1
32, 159
Weights
...............

................. 332, 333, 335, 336
Welcome lighting.......................................52, 67
Wheel, spare
................ 2

62, 289, 296, 297, 302
Windows, rear
....................................... 12

3, 124
Windscreen, heated
.............................. 1

32, 159
Wiper blades (changing)
....................... 1

59, 274
Wiper, rear ............................................. 157, 15 8
Wipers
.............................................2

9, 156, 157
Wipers, automatic rain sensitive

...........15

6, 157
Alphabetical index
