Citroen NEMO DAG 2010.5 1.G Owner's Manual

116
Equipment
ROOF RACK AND ROOF BARS
To install the transverse roof bars or a
roof rack, use the fixings provided for this
purpose.
Maximum load: 75 kg.
OTHER ACCESSORIES
A wide range of accessories and original
parts is offered by the CITROËN network.
These accessories and parts have been
tested and approved both for reliability and
for safety.
They all benefit from CITROËN's
recommendation and warranty.
Never exceed the gross vehicle weight
(GVW). Range of professional equipment
The replacement parts department publishes
an accessories catalogue offering various
equipment and fittings, such as:
- wooden protective floor, non-slip wooden
floors, wooden side protectors, glass
protection grilles,
- roof rack, set of transverse roof bars, loading roller,
- towbars, towbar harnesses with 7/13 sockets, 7/7 sockets, 13 socket... The fitting of electrical equipment or
accessories not listed by CITROËN
may result in the failure of your vehicle's
electronic system or high consumption.
Please note this specific warning. You
are advised to contact a representative
of CITROËN to be shown the range of
recommended equipment and accessories.
Depending on the country in which the
vehicle is sold or operated, it is compulsory
to have a high visibility vest, warning
triangle, replacement bulbs and fuses
available in the vehicle.
You are advised to contact a
representative of CITROËN before
installing accessory radiocommunication
transmitters with external aerial on
your vehicle. Your CITROËN dealer will
inform you of the specification (frequency
band, maximum output power, aerial
position, specific installation conditions)
of the transmitters which can be fitted,
in accordance with the Motor Vehicle
Electromagnetic Compatibility Directive
(2004/104/EC).
When fitting a towbar and harness
outside the CITROËN dealer
network, the installation must be done
using the electrical pre-equipment on the
vehicle and following the manufacture's
recommendations.

117
6
ACCESSORIES
Equipment
Range of accessories for private vehicles
Another range is also available from
CITROËN dealers.
"Comfort":
insulated module, coat hanger fixed to a
head restraint, reading lamp, rear parking
sensors...
"Transport solutions":
boot liner, rear door net, set of transverse
and longitudinal roof bars, roof boxes...
"Style":
embellishers... "Security and safety":
anti-intrusion alarm, window etching,
breathalyzer, first aid kit, high visibility vest,
warning triangle, child seats and booster
cushions, snow chains...
"Protection":
rubber mats, over-carpets, 3D mats, seat
covers compatible with lateral airbags...
"Multimedia":
audio systems, hands-free kit, speakers,
portable satellite navigation systems, speed
camera detectors...
By going to a CITROËN dealer, you can also
obtain cleaning and maintenance products
(interior and exterior) - including ecological
products from the "TECHNATURE" range -
products for topping up (screenwash...), touch-
up pens and paint aerosols for the exact colour
of your vehicle, recharges (cartridge for the
temporary puncture repair kit...), ...
To avoid any risk of jamming of the pedals:
- ensure that the mat is positioned and
secured correctly,
- never fit one mat on top of another.

118
Battery
BATTERY
Models without Stop & Start

A. Metallic positive point of your vehicle.

B. Slave battery.

C. Earth of your vehicle.

D. Metallic positive point on your vehicle. Charging the battery using a battery charger Starting using another battery
- Connect the red cable to the metallic
point A then to the positive (+) terminal of
the slave battery B .
- Connect one end of the green or black cable to the negative (-) terminal of the
slave battery B .
- Connect the other end of the green or black cable to the earth point C on your
vehicle (never to the metallic point D of
your vehicle).
- Operate the starter, let the engine run.
- Wait for the engine to return to idle, then disconnect the cables.
Never charge a battery without first
disconnecting the terminals.
- Disconnect the two quick-fit battery terminals.
- Follow the instructions for use given by the battery charger manufacturer.
- Check that the battery posts and terminals are clean. If they are covered
with sulphate (white or greenish deposit),
disconnect them and clean them.
- Reconnect the two quick-fit terminals, starting with the negative (-) terminal.

119
7
QUICK HELP
Battery
Models with Stop & Start

A. Protective cover.

B. Positive metallic point on your vehicle.

C. Slave battery.

D. Earth on your vehicle.

E. Terminal release button.

F. Check sensor button.

G. State of charge sensor.

H. Metal negative point of your vehicle. Charging the battery using a battery charger - Follow the instructions for use given by
the battery charger manufacturer.
- Check that the battery posts and terminals are clean. If they are covered
with sulphate (white or greenish deposit),
disconnect them and clean them.
- Reconnect connector F of the check
sensor G .
- Refit the protective cover A to the
metallic point B .
Starting using another battery
- Remove the protective cover A from the
metallic point B .
- Connect the red cable to metallic point B ,
then the (+) terminal to the slave battery C .
- Connect one end of the green or black cable to the (-) terminal of the slave
battery C .
- Connect the other end of the green or black cable to the earth point D of your
vehicle (never to the metallic point H of
your vehicle).
- Operate the starter, let the engine run.
- Wait for the engine to return to idle, then disconnect the cables.
- Refit the protective cover A to the
metallic point B .
The Stop & Start battery does not have
to be disconnected for charging.
- Press the release button E to disconnect
the terminal F .
- Disconnect the connector F of the check
sensor G .
- Remove the protective cover A from the
metallic point B .
- Connect the charger cables: (+) on the metallic point B ; (-) on the metallic point H . Never remove the check sensor
G
from the metallic point H , except
when replacing the battery.

120
Battery Batteries contain harmful substances
such as sulphuric acid and lead. They
must be disposed of in accordance with the
law and must not, in any circumstances be
discarded with household waste.
Take used batteries to an authorised waste
disposal site.
It is advisable to disconnect the battery
if the vehicle is not to be used for a
period of more than one month. To do
this on models with Stop & Start:
- press the release button E to disconnect
connector F ,
- disconnect connector F of check sensor G .
Never remove the check sensor G from the
metallic point H , except when replacing the
battery.
The presence of this label, in particular
with the Stop & Start system, indicates
the use of a 12 V lead-acid battery with
special technology and specification, for
which the involvement of a CITROËN dealer
is required when replacing or disconnecting
the battery.
Failure to observe this recommendation may
cause premature wear of the battery.
After refitting the battery, the Stop &
Start system will only be active after
a continuous period of immobilisation of
the vehicle, a period which depends on the
climatic conditions and the state of charge of
the battery (up to about 8 hours). Before charging
The charging operation must be carried out in
a ventilated area away from naked fl ames or
any possible sources of sparks to eliminate the
risks of explosion and fi re.
Do not attempt to charge a frozen battery: it
must fi rst be thawed to eliminate the risks of
explosion. If the battery has frozen, before
charging it have it checked by a specialist who
will check that the internal components have
not been damaged and that the container is
not cracked, which could mean that there is a
risk of a leak of toxic and corrosive acid.
Before disconnecting
Never disconnect a terminal when the
engine is running.
Before disconnecting the battery, you must
wait for 2 minutes after switching off the
ignition.
Close the windows and doors before
disconnecting the battery. After reconnecting
After every reconnection of the battery,
switch on the ignition and wait 1 minute
before starting to allow the electronic
systems to be initialised. If difficulties are
experienced after this, contact a CITROËN
dealer.
If the battery has been disconnected
for some time, it may be necessary to
reinitialise the following functions:
- the display parameters (date, time,
language, distance and temperature
units),
- the radio stations,
- the central locking.
Some settings are cleared and must be
reprogrammed. Contact a CITROËN dealer.

121
7
QUICK HELP
Changing a wheel
CHANGING A WHEEL
Parking the vehicle
As far as possible, park the vehicle on level,
stable and non-slippery ground.
Apply the handbrake, switch off the ignition
and engage first gear (on a hill).
It is imperative that you ensure that the
occupants get out of the vehicle and wait in
a safe location.
If possible, place a chock under the
wheel diagonally opposite the wheel to be
changed. Tools
The tools required are stored in a tool kit
located behind the driver's seat (Light van)
or behind the rear bench seat (Combi).

1. Wheelbrace.

2. Centring guide.

3. Screwdriver.

4. Jack with handle.

5. Removable towing eye.
The jack and all of the tools are specific
to your vehicle. Do not use them for other
purposes.
Never go underneath the vehicle when it is
raised only by the jack; use an axle stand. Taking out the spare wheel
The spare wheel retaining bolt is located on
the rear left part of the loading sill.

1. Slacken the wheel retaining bolt using the
wheelbrace.

2. Unscrew fully to unwind the winch cable.

3. Take out the spare wheel using the
wheelbrace.

4. Raise the cover A .

5. Remove the cable B from its housing.

6. Release the spare wheel and place it
near the wheel to be changed.

122
Changing a wheel Removing

1. Park the vehicle on level, stable and non-
slippery ground. Apply the parking brake.
Switch off the ignition and engage first
gear or reverse, depending on the slope.

2. Detach the wheel trim (large model) using
the wheelbrace 1 , pulling at the valve
passage hole.
Slide the screwdriver 3 into the notch on
the trim (small model) and use the tool as
a lever, pressing to unclip the trim.

3. Slacken the wheel bolts using the
wheelbrace.
4. Position the jack underneath the body,
in accordance with the illustration, at
the mark A (in the side member recess)
as close as possible to the wheel to be
changed.

5. Extend the jack 4 until its base is in
contact with the ground. Ensure that the
centreline of the jack base is vertical in
relation to the location used.

6. Raise the vehicle.

7. Remove the bolts and detach the wheel.
Putting the wheel back in place

1. Install the support on the wheel.

2. Place the cable B in position.

3. Lower the cover A .

4. Position the wheel.

5. Turn the wheelbrace clockwise to raise
the spare wheel completely.

123
7
QUICK HELP
Changing a wheel
Refitting the wheel
6. Put the trim back in place, starting by
placing its notch facing the valve, and
press with the palm of your hand.

7. Stow the tools and the wheel.

8. Check the wheel inflation pressure
(see "Identification") and have the
balance checked. Refer to the "Identification markings"
section of chapter 8 to locate the tyre
label.
Have the tightening of the bolts and the
pressure of the spare wheel checked by a
CITROËN dealer without delay.

1. Put the wheel in place using the centring
guide 2 to assist you.

2. Screw in the 3 bolts by hand and remove
the centring guide. Position the 4th bolt.

3. Pre-tighten using the wheelbrace 1 .

4. Fold the jack 4 and detach it.

5. Tighten the wheel bolts using the
wheelbrace. Also, have the original wheel repaired
and refitted by a CITROËN dealer as
soon as possible.

124
Changing a wheel
TEMPORARY PUNCTURE REPAIR KIT
This kit is located at the front of the
passenger compartment. It consists of:
- a repair cartridge A , containing the
sealant, equipped with:

125
7
QUICK HELP
Changing a wheel
- If a pressure of at least 1.5 bars is not
reached within 5 minutes :
