BRAKES
BRAKE SPECIFICATIONS
Braking circuit with ESP (BOSCH 5.7)
(A) Hydraulic circuit(B) Electrical circuit
(1)Master cylinder in tandem(2)Braking servo(3)Brake caliper (or drum at the rear)(4)Toothed wheel(5) Wheel sensor(6)Brake fluid level sensor(7)Hydraulic block plus ECU(8) Stoplamp switch(9)Instrument panel(10)Diagnostic socket(11)Builtin systems interface (BSI)(12)Steering angle sensor(13)Gyrometer/accelerometer sensor(14)Switch
B3HP004P
XSARA

Downloaded from www.Manualslib.com manuals search engine 448
BRAKESBRAKE SPECIFICATIONS
Electrical circuit
ComponentsRef.
SupplierPart no.Observations
42wayconnector.
Integral to the hydraulic block..Changing only the ECU is prohibited.
2waygrey connector.
The sensors are inductivetype.Tightening torque:
0,8 ± 0,2 m.daN.
2waygrey connector.
The sensors are inductivetype.Mounted on the brake caliper support.
Nonadjustable airgap:
0,3 to 1,2 mm.
Tightening torque:0,8 ±0,2 m.daN.
2waygrey connector.
The sensors are inductivetype.
Mounted on the suspension arm.
Nonadjustable airgap:
0,3 to 1,2 mm.
Tightening torque:0,8 ±0,2 m.daN.
Incorporated in the COM 2000.
6wayblue connector.
Located on the central console.
6way connector.
Toothed wheel:
48 teeth.
Integral with the driveshaft stub housing for
the front wheels, joined to the hub bearing for
the rear wheels.
XSARA
5.7 ESP
0 265 006 389
0 265 006 202
0 265 006 203
0 265 006 441 BOSCH
VALEO
BOSCH
GKNElectronic
ECU
Front wheel sensor
Rear wheel sensor
(disc brakes)
Rear wheel sensor(Saloon: drum brakes)
Rear wheel sensor(Estate: drum brakes)
Steering angle sensor
Gyrometer/accelerometer sensor
Toothed wheel7
5
12
13
4

Downloaded from www.Manualslib.com manuals search engine 449
BRAKES
BRAKE SPECIFICATIONS
Gyrometer sensor
(7) Hydraulic b lock
C4AP17YCB3HP002C
Observations
P art no.
Supplier
Components
XSARA
ESP
hydraulic blockBOSCH 5.7 ESPLocated on the front LH
wheelarch:4adjustment channels.
IMPERATIVE:Respect the direction of fitting of the gyrometer/accelero
meter sensor (connector towards the rear of the vehicle).
WARNING:The gyrometer/accelerometer sensor should not be subjected to any impact.Any gyrometer/accelerometer sensor havingsuffered an impact must be replaced.Tightening torque (15):0,6 ± 0,1 m.daN.

Downloaded from www.Manualslib.com manuals search engine 450
BRAKES
HANDBRAKE
XSARA
Checking and adjusting the handbrake.
Remove the handbrake console.
Jack up and chock the vehicle with the rear wheels hanging free. Check the correct routing of the brake cables under the vehicle.
Apply and release the handbrake ten times. Set the handbrake to the
3rd notch.
Tighten the nut (1)until the rear brakes are applied.
Pull the handbrake lever vigorously 4 to 5 times.
Set the handbrake to the 3rd notch.
Check that the rear brakes are applied.
Check that the wheels can be turned freely by hand with the
handbrake released.
Lower the vehicle. Refit the handbrake console.
B3FP095D

Downloaded from www.Manualslib.com manuals search engine 451
BRAKES
BLEEDING THE BRAKESXSARA
Bleeding:The brakes can be bled either:
using brake bleeding equipment, in which case the pressure of the equipment should be set to 2 Bars.
or in the conventional way.
IMPERATIVE order of bleeding
Wheels:
Rear Right.
Front Left. Rear Left.
Front Right.
Top up using brake fluid supplied by
CITROEN Replacement Parts.

Downloaded from www.Manualslib.com manuals search engine 452
BRAKESBRAKE SPECIFICATIONS
(*) ESP + Electronic Stability Program
XSARA PICASSO
Mercosur Europe
Without ESP (*)
2.0i 16V 2.0 HDi 1.6i 1.8i 16V 2.0i 16V 2.0 HDi
Engine type RFN RHY NFV 6FZ RFN RHY
Master cylinder
23,8
Master vac
Ø Master cylinder travel
254/34
FT mm
CaliperLUCASBOSCHpiston makesC54/54ZOH54/54
Disc Ventilated266
Disc thickness/min. thickness20,4/18,4 22/20
Makes/Brake pad gradeJURID/3724FERODO/769 (37)
Rear brake plates
Supplier/TypeLUCAS/ENERGIT/C52980
Ø Cylinder or caliper22,2
mm Drum/Ø maxi228,6/230
RR MakeABEX
Brake lining grade4930/2
Compensator/Supplier/TypeTEVESITTA (loadsensitive rear braking compensator)
Cutoff pressure in Bars20/61,6

Downloaded from www.Manualslib.com manuals search engine 453
BRAKES
BRAKE SPECIFICATIONS
Engine type6FZ RFN 9HZ 9HY RHY
Master cylinder
23,8
Ø Master vac
mm Master cylinder travel
254/35
FT Piston Makes/CaliperBOSCH ZOH54/54
Disc Ventilated283
Disc thickness/minimum thickness26/24
Makes/Brake pad gradeFERODO/769 (37)
Rear brake caliper
Ø Supplier/Type
TRW C38
mm Disc plain247
RR Disc thickness/minimum thickness9/7
MakeGALFER
Brake lining gradeG 4554
Compensator – cutoff in BarsOn versions with ABS, there is no loadsensitive
rear braking compensator.
(*) ESP = Electronic Stability Program.All types
Ftec ESP (*)
1.8i 16V 2.0i 16V 1.4 HDi 2.0 HDi
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 454
BRAKES
B3FP7B9D
BRAKING SYSTEM SPECIFICATIONS
Without ABS
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 455
BRAKES
B3FP7B9DB3FP7BRD
BRAKING SYSTEM SPECIFICATIONS
With EPS (Electronic Stability Program)
With ABS
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 456
BRAKES
BRAKE SPECIFICATIONS XSARA PICASSO
Braking system specifications
“X”braking circuit.
Front: disc brakes, ventilated. Rear:drum brakes with automatic adjustment.
Cable operated handbrake acting on the rear wheels.
Load sensitive braking compensator
(non ABS versions).
(1) Hydraulic valve block «ABS Bosch 5.3»or(1) Hydraulic valve block + ECU.(2) Load sensitive braking compensator (according to version).
B3FP09HCB3FP08ND
2
