ENGINECHECKING AND SETTING THE VALVE TIMING
Engines: HFX KFV NFU
B1BP2M7CB1BP2M9CB1BP2M8C
Tools.
[1]
Engine flywheel peg: 4507T.A
[2]Camshaft pulley peg : 4507T.B
[3a]Camshaft peg: 4533TA.C1
[3b] Camshaft peg: 4533TA.C2
[4]Dynamic tensioner roller pin: 4200T.H
[5]Belt retaining pin: 4533T.AD
[6]Pliers for removing plastic pins: 7504T
Checking the valve timing.
Engines:
HFX – KFV – NFU.
Raise and support the front RH side of the vehicle.
Disconnect the battery positive terminal.
Engage 5th gear.
Remove the oil filter
(1).
Engines:HFX – KFV.
Remove: The timing top casing (2).
Turn the wheel to rotate the engine (normal direction of rotation).
Peg the camshaft pulley, using tool [2].
C2 C3 C3 PLURIEL

Downloaded from www.Manualslib.com manuals search engine 172
ENGINECHECKING AND SETTING THE VALVE TIMING
NOTE: Checking and setting the timing # 2003: See Mechanic’s Handbook 2003: pages 163 to 173.
Tools.
[1]
Camshaft setting peg: () 0189.A
[2]Crankshaft setting peg: ().0189.R
[3]Timing belt retaining pin :().0189.K
[4]Adaptor for angular tightening: 4069T
[5]Tool for moving and locking the tensioner roller: ().0189.S
[5a] :().0189.S1
[5b] : ().0189 S2
Pliers for removing plastic pins: 7504T
Checking the setting of the timing.
Removing.
Disconnect the battery negative terminal (see corresponding operation).
Raise and support the vehicle, front wheels hanging.
Remove:
The front RH wheel.
The plastic pins
(1).
The splashshield (2).
The upper timing cover.
C4AP12TC
XSARA XSARA PICASSO
Engines: 6FZ RFN 2003 #

Downloaded from www.Manualslib.com manuals search engine 174
ENGINECHECKING AND SETTING THE VALVE TIMING
Engines: 6FZ RFN 2003 #
Setting the timing.
Removing.
Disconnect the battery negative terminal (see corresponding operation).
Raise and support the vehicle, front wheels hanging.
Remove: The front RH wheel.
The plastic pins
(1).
The splashshield (2).
The accessories drive belt (see corresponding operation).
Unclip and move aside the fuel delivery hose from the timing cover.
Remove the upper timing cover
(1).
Turn the engine by means of the screw
(3)of the crankshaft pulley (2)to bring it to the pegging position.
B1BP2V4C
XSARA XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine ENGINE
201
CHECKING AND SETTING THE VALVE TIMING
Engines: 9HZ 9HY
B1BP304D
Tools.
[1]
Flywheel setting peg: ().0194.C
[2]
Camshaft setting peg:().0194.B
[3]
Crankshaft setting peg: ().0194.A
Checking and setting the timing.
Removing.
Raise and support the vehicle, wheels hanging.
Disconnect the positive and negative terminals of the battery.
Remove: The front RH wheel.
The front RH splashshield.
The accessories drive belt
(see corresponding operation).
Uncouple: The fuel supply unions
(1).
The air/air heat exchanger inlet and outlet pipes
(3).
The exhaust line
(at the flexible pipe).
Disconnect the connecter at
«a».
Remove and move aside the power steering fluid reservoir
(6).
Uncouple, plug and move aside the tube
(2).
Support the engine with a roller jack equipped with a block.
Remove the engine supports
(4)and (5).
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 204
ENGINECHECKING AND SETTING THE VALVE TIMING
Engines: 9HZ 9HY
Refitting.
Refit tool [1]at «b».
Remove the screw (10).
Refit:
The upper timing cover
(12).
The lower timing cover (11).
The accessories drive pulley (9).
The screw (10).
Tightening torqueScrew (10)Pretighten to:3 ± 0,3 m.daN.
Angular tighten:180°±5°.
Remove tool [1].
Refit:
The engine support
(8), tighten to 5,5 ± 0,4 m.daN.
The engine support (4), tighten to 6,1 ±0,6 m.daN.
The engine support (5), tighten to 2,5 ±0,2 m.daN.
The electrical harness (7).
The power steering fluid reservoir (6).
XSARA PICASSO
Couple:
The tube (2).
The exhaust line, tighten the clip to 2,5 ± 0,3 m.daN.
The fuel unions (1).
The air/air heat exchanger inlet and outlet pipes (3).
Connect the connector at «a».
Refit:
The accessories drive belt
(see corresponding operation).
The front RH splashshield
(see corresponding operation).
The front RH wheel, tighten to 9 ±1 m.daN.
Reconnect the positive and negative terminals of the battery.
IMPERATIVE:Perform the operations that are necessary following a
reconnection of the battery (see corresponding operation).

Downloaded from www.Manualslib.com manuals search engine 205
ENGINE
CHECKING AND SETTING THE VALVE TIMING
Engines: 9HZ 9HY
B1BP304D
Tools.
[1]
Flywheel setting peg: ().0194.C
[2]
Camshaft setting peg:().0194.B
[3]
Crankshaft setting peg: ().0194.A
Checking and setting the timing.
Removing.
Raise and support the vehicle, wheels hanging.
Disconnect the positive and negative terminals of the battery.
Remove: The front RH wheel.
The front RH splashshield.
The accessories drive belt
(see corresponding operation).
Uncouple:
The fuel supply unions
(1).
The air/air heat exchanger inlet and outlet pipes
(3).
The exhaust line
(at the flexible pipe).
Disconnect the connecter at
«a».
Remove and move aside the power steering fluid reservoir
(6).
Uncouple, plug and move aside the tube
(2).
Support the engine with a roller jack equipped with a block.Remove the engine supports
(4)and (5).
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 210
ENGINECHECKING AND SETTING THE VALVE TIMING
Engines: 9HZ 9HY
Refitting (continued).
Refit tool [1]at «b».
Remove the screw (10).
Refit:
The upper timing cover
(12).
The lower timing cover (11).
The accessories drive pulley (9).
The screw (10).
Tightening torqueScrew (10)Pretighten to:3 ± 0,3 m.daN.
Angular tighten:180°±5°.
Remove tool [1].
Refit:
The engine support
(8), tighten to5,5 ± 0,4 m.daN.
The engine support (4), tighten to 6,1 ±0,6 m.daN.
The engine support (5), tighten to 2,5 ±0,2 m.daN.
The electrical harness (7).
The power steering fluid reservoir (6).
XSARA PICASSO
Disengage the jack from under the engine.
Couple:
The tube
(2).
The exhaust line, tighten the clip to 2,5 ± 0,3 m.daN.
The fuel unions (1).
The air/air heat exchanger inlet and outlet pipes (3).
Connect the connector at «a».
Refit:
The accessories drive belt
(see corresponding operation).
The front RH splashshield (see corresponding operation).
The front RH wheel, tighten to 9 ± 1 m.daN.
Reconnect the positive and negative terminals of the battery.
IMPERATIVE: Perform the operations that are necessary following a
reconnection of the battery (see corresponding operation).

Downloaded from www.Manualslib.com manuals search engine 218
ENGINECHECKING AND SETTING THE VALVE TIMING
NOTE: Checking and setting the valve timing on engines: RHYRHZ N° ⁄ RPO 9127
See Mechanic’s Handbook 2003: pages 193 to196
Tools.
[1]
Belt tension measuring equipment :4122T
[2]
Tension lever:().0188.J2
[3]
Engine flywheel peg: ().0188.Y
[4]
Belt clamp: ().0188.AD
[5]
Camshaft pulley peg: ().0188.M
[6]
Engine flywheel lock: ().0188.F
[7]
Set of blocking plugs:().0188.T
[8]
Pulley extractor:().0188.P
[9]
2 mm dia.peg: ().0188.Q2Removing.
IMPERATIVE: Respect the safety and cleanliness requirements
that are specific to high pressure diesel injection (HDi) engines.
Undo the front RH wheel bolts.
Raise and support the vehicle on the front RH side.
Disconnect the battery negative terminal.
Remove:
The underengine sounddeadening.
The front RH wheel.
The front RH splashshield. The engine cover.
Unclip and move aside the cooling hose.
Remove the accessories drive belt
(see corresponding operation).
XSARA XSARA PICASSO
Engines: RHY RHZ N° RPO 9128 #

Downloaded from www.Manualslib.com manuals search engine 276
INJECTION
SPECIAL FEATURES: PARTICLE FILTER / FILLING OF THE ADDITIVE RESERVOIR
Imperative: Respect the safety and cleanliness requirements.
Tools.
Filling kit comprising the following items:1Container of Eolys2Filters2Tubes1Empty container2Hooks1Adaptor
Filling.
IMPERATIVE: Respect the safety and cleanliness requirements specific to HDi engines.
IMPERATIVE: For all operations on the additive circuit, wear protective goggles and gloves
that are resistant to hydrocarbons.
Place the vehicle on a lift.
Disconnect the battery negative terminal.
Unclip the the factory filler connector
(1).
Couple the container of additive to the tube (2)using the adaptor and the tube (with tap)from the
filling kit.
Screw the filler connector on the additive container
(3)at «b».
Place the additive container (3)on the component lift.
Open the tap located on the filler connector at «a».
Tilt the additive container (3)(to facilitate the end of filling).
Close the tap at «a».
Remove the filler connector and the tube (4).
Couple the tube (2).
Reconnect the battery negative terminal.
IMPERATIVE: The filling kit should be recycled after this operation. Any «Eolys» additive
containers that have been opened should not be kept.
XSARA PICASSO
B1HP1UVC
C4BP1EGC

Downloaded from www.Manualslib.com manuals search engine 308
RECOMMENDATIONS PRECAUTIONS: MA PILOTED MANUAL GEARBOX
Safety requirements.
ESSENTIAL:Given the special features of the MA type piloted
manual gearbox, observe the requirements detailed below.
IMPERATIVE: Always disconnect the battery negative terminal
before operating on the actuators.
NOTE:
After disconnecting the battery, never try to remove the clutch
actuator on the vehicle before having checked that it is in the closed
position
(rod pushed in).
IMPERATIVE:After Sales checks done with the engine running must be
performed with «Neutral»engaged and the handbrake on (unless there
is a clear mention otherwise in the repair procedures).
IMPERATIVE:The areas of movement of the clutch fork and of the gear
engagement lever must always be kept free during the actuatoroperating phases.
CLUTCH
GEARBOX
TRANSMISSION
IMPERATIVE:When initialising the clutch actuator and/or gearbox
actuator, do not allow any person to walk or stand in front of the vehicle.
WARNING:When the engine is running, it is forbidden to perform
repairs on the clutch and gearbox actuators on the vehicle (whether
manually or using a diagnostic tool).
WARNING:Each time the driver’s door is opened and each time the
igntion is switched on, the gearbox ECU prompts the initialising of the
clutch and gearbox actuators
(there is movement of the clutch fork and
of the gear lever).
WARNING:Whether the ignition is switched on or not, an action on the
gear selector causes the clutch fork and the gear engagement lever to
move on the gearbox.
