C2
OPERA TIONS TO BE CARRIED ORT AFTER A REPAIR
GENERAL
Sun roof.The antipinch function has to be reinitialised.
Place the sun roof switch in the maximum tilt position.
Keep the sun roof switch pressed until the sun roof ceases its movement.
Release the sun roof switch within 5 seconds.
Keep the sun roof switch pressed until the end of the sun roof opening sequence.
Multifunction screen.It is necessary to adjust the date, time and ortside temperature.
Adjust the display language of the multifunction screen if necessary.
NOTE:The default display language of the multifunction screen is French.
Navigation.Warning, the vehicle has to be in the open air (on switching on the ignition, the ECU searches for satellites).
Vehicle location is only effective after some ten minutes.Reprogramme the customer paramanders.
Radio.Reprogramme the radio stations.
Radiotelephone RT3.Reprogramme the radio stations.

Downloaded from www.Manualslib.com manuals search engine 309
CLUTCH
GEARBOX
TRANSMISSION
RECOMMENDATIONS PRECAUTIONS: MA PILOTED MANUAL GEARBOX
Operations on electrical components.Do not disconnect:
The battery when the engine is running.
The ECU with the ignition switched on.
The clutch and gearbox actuators with the ignition switched on.
When carrying out electrical checks: The battery must be correctly charged.
Never use a voltage source higher than 16V.
Never use a lamp to supply an actuator directly.
Before disconnecting connector, check: The condition of the various contacts (for deformation, corrosion, etc).
The presence and the status of the mechanical unlocking.
Driving the vehicle.
IMPERATIVE:
Never move the vehicle with the ignition switched off.
Never push the vehicle to attempt to start it
(impossible with a piloted
manual gearbox).
Towing.
Conditions for towing.
It is necessary to lift the front of the vehicle to tow it, after having
positioned the gear lever in neutral. If there is a gearbox fault or
malfunction, the vehicle can remain immobilised depending on theseriousness of the fault.
If a gear is engaged,the conditions for immobilisation of the
vehicle are:
Combustion engine stopped (the engine should not be started).
The clutch is open (clutched).
In these conditions are met, you can lift the front of the vehicle to tow it.
If it should not be possibe to lift the front of the vehicle, there are
ways to unblock it:
Engage «N», using a diagnostic tool.
Engage «N», without using a diagnostic tool.
Engines: HFX KFV NFU 8HX
C2

Downloaded from www.Manualslib.com manuals search engine 331
CLUTCH
GEARBOX
TRANSMISSION
RECOMMENDATIONS PRECAUTIONS: AL4 AUTOMATIC GEARBOX
Engines: KFV NFU RFN RHZ
If a gearbox malfunction occurs, there are two possible
configurations depending on the seriousness of the fault:
Gearbox in backup mode with a replacement programme of
(the
fault values are taken in substitution).
Gearbox in backup mode with an emergency programme (3rd
hydraulic).WARNING:In the emergency programme, an impact is felt
when changing P/R, N/R and N/D.
Réception client.
Discuss with the customer, to find out all the malfunction symptoms.Oil quality Oil level.
Oil quality.
If the gearbox has suffered a serious fault resulting in a malfunction
or the destruction of a clutch, the oil will overheat and become
contaminated with impurities: the oil is said to be
«burnt».
This is characterised by a black colour and the presence of an
unpleasant smell.
ESSENTIAL: The gearbox must be replaced.
Oil level (see corresponding operation).
An excessive oil level can result in the following consequences:
Excessive heating of the oil.
Oil leaks.
An insufficent level causes the destruction of the gearbox.
Top up the level of oil in the gearbox (if necessary).
Check using a diagnostic tool.
Read the fault codes
(engine and gearbox).
Absence of fault codes.Carry out parameter measures, actuator tests and a road test.
Presence of fault codes.Carry out the necessary repairs.
Delete the fault codes.
Carry out a road test to check the repair and, if need be, modify the
gearbox ECU parameters
(this is essential after an initialisation
of the ECU).
XSARA XSARA PICASSO
Procedure to be followed prior to carrying out repairs on AL4 autoactive gearbox

Downloaded from www.Manualslib.com manuals search engine 334
CLUTCH
GEARBOX
TRANSMISSION
Engines: KFV NFU RFN RHZ
Downloading.
Updating the gearbox ECU by downloading:
Follow the procedure using the diagnostic tool.
The downloading operation enables the automatic gearbox to be updated, or adapted to an evolution of the engine ECU.
Before commencing the downloading, take the value of the oil usage counter present in the automatic gearbox ECU.
After the downloading operation, carry out the following: A clearing of faults.
A pedal initialisation.
A reinitialisation of the autoadaptives.
A programming
(if necessary).
A writing of the value of the oil usage counter previously read.
A road test.
ESSENTIAL: Every update of the automatic gearbox ECU should be accompanied by an update of the engine ECU.
RECOMMENDATIONS PRECAUTIONS: AL4 AUTOMATIC GEARBOX C3 XSARA XSARA PICASSO
Procedure for initialising the automatic gearbox ECU

Downloaded from www.Manualslib.com manuals search engine 341
CLUTCH
GEARBOX
TRANSMISSION
AL4 AUTOMATIC GEARBOX
In passenger compartment (continued).
The information is transmitted to the gearbox ECU.
NOTE:The vehicle is equipped with the «shift lock»«P».
Two switches placed on the gear control gate permit the driver to choose one of the following
three driving programmes:

Normal programme: Operates as the default programme (eco law, autoadaptive mode).
Sport programme (a): Permits a more dynamic, sporty performance.
Snow programme (b): Facilitates starting and adhesion on slippery surfaces.
To return to the normal programme, press a second time on the sport switch or snow switch.
Engine: KFV
C3
B2CP3DKD

Downloaded from www.Manualslib.com manuals search engine 345
CLUTCH
GEARBOX
TRANSMISSION
AL4 AUTOMATIC GEARBOX
NOTE:The «shift lock»«P».
Unlocking the «SHIFT LOCK»(normal operation).
Switch on the ignition.
Press the brake pedal and keep it pressed.
Move the gear selection lever out of position
«P».
Unlocking the «SHIFT LOCK»(with an operating fault).NOTE:It is impossible to unlock the «shift lock»
«Shift lock».
Gear lever position switch. Automatic gearbox ECU.
Electrical harnesses.
Battery voltage.
Remove:
The gear lever knob
(1)(pull upwards).
The cover (2)(Unclip).
The top of the central console (3).
Unlock the «shift lock» (4)with the aid of a screwdriver.
Move the gear selection lever out of position «P».
Engine: KFV
C3
C5FP0ETCB2CP3GZC

Downloaded from www.Manualslib.com manuals search engine 346
CLUTCH
GEARBOX
TRANSMISSION
XSARAAL4 AUTOMATIC GEARBOX
Engines: NFU RFN RHZ
SHIFT LOCK.
NOTE:
The «shift lock»«P».
U
nlocking the «SHIFT LOCK»(normal operation).
Switch on the ignition.
Press the brake pedal and keep it pressed. Move the gear selection lever out of position
«P».
Unlocking the «SHIFT LOCK»(with an operating fault).NOTE:It is impossible to unlock the «shift lock»
«Shift lock».
Gear lever position switch.
Automatic gearbox ECU.
Electrical harnesses. Battery voltage.
Remove:
The cover
(1).
Unlock the «shift lock» (2) with the aid of a screwdriver.
Move the gear selection lever out of position «P».
C5FP06ZC
C5FP06YC

Downloaded from www.Manualslib.com manuals search engine 347
CLUTCH
GEARBOX
TRANSMISSION
AL4 AUTOMATIC GEARBOX
SHIFT LOCK.
NOTE:
The «shift lock»«P».
Unlocking the «SHIFT LOCK»(normal operation).
Switch on the ignition.
Press the brake pedal and keep it pressed.
Move the gear selection lever out of position
«P».
Unlocking the «SHIFT LOCK»(with an operating fault).
NOTE:It is impossible to unlock the «shift lock»
«Shift lock»
«shift lock»by pressing at «a»with a screwdriver placed in the gear selection
control gate.
Move the gear selection lever out of position
«P».
Engine: RFN
XSARA PICASSO
B2CP3N8C

Downloaded from www.Manualslib.com manuals search engine 480
ELECTRICAL
SYSTEM
CHARGING CIRCUIT ALTERNATOR WITH MONOFUNCTION REGULATOR
Checking the alternator output.
Connect as shown in the diagram opposite, using an ammeter (A), a voltmeter (V),
and a rheostat
(R)or a Volt/Ammeter/Rheostat combination.
Referring to the vehicle’s equipment specification
(see table opposite), adjust the
engine speed and rheostat charge to obtain
U = 13.5 V.
Reminder:The excitation energising current will flow through the warning lamp;
check that the warning lamp comes on when the ignition is switched on. It shouldgo out when the engine has started
(accelerate slightly).
Checking the voltage regulator.
Set the rheostat to zero and disconnect all the electrical consumers.
Display
3000alternator rpm. If U alternator is > 14.7 V, the regulator is faulty.
Note:These tests should be performed with the engine hot and the battery fully
charged.
Method of reading the alternator speed.
Fit a reflecting shim on the pulley of the alternator.
Adjust a stroboscope to the frequency equivalent to the control speed.
(e.g. 2000 rpm = 2000/60 = 83 Hz).
Adjust the engine speed so that the shim appears fixed.
D1AP025C
A: Ammeter.B:Battery.G: Generator.L: Warning lamp.K1and K2:Switch.R: Electric charge.S:Shunt 200mV/200A.V:Voltmeter.1 : Alternator.

Downloaded from www.Manualslib.com manuals search engine 497
AIRCON
SPECIAL FEATURES: AIR CONDITIONING SYSTEM (R 134.a)
Checking the compressor oil level (Continued)
2/ Slow leak.
Slow leaks do not lead to oil loss, therefore the same procedure should be followed as if there was no leak at all.
3/ Fast leak.
This type of leak causes both oil loss as well as allowing air to enter the system.
It is therefore necessary to:
Replace the dehydrator.
Drain as much oil as possible
(when replacing the faulty component).
Either before or during filling of the system with
R 134.afluid, introduce 80 ccof NEWoil into the system.
