Poste de conduite direction à gauche (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_1
DRIVER’S POSITION, LEFT-HAND DRIVE (2/2)
The fittings described DEPEND ON THE VEHICLE VERSION AND COUNTRY.
1 Side air vent.
2 Side demister outlet.
3 Stalk for:
– direction indicator lights,
– exterior lights,
– front fog lights,
– rear fog light,
– horn.
4 Audible warning
5 Instrument panel.
6 Location for driver’s airbag.
7 – Steering column stalk for winds-
creen and rear screen wash/
wiper.
– On-board computer information
readout control.
8 Ignition switch.
9 Hazard warning lights switch.
10 Centre air vents.
11 Electric central locking switch.12 Central demister outlet.
13 Location for radio, navigation system
or storage compartments.
14 Location for passenger airbag.
15 Side demister outlet.
16 Side air vent.
17 Passenger airbag activation/deacti-
vation switch.
18 Glove compartment
19 Activation/deactivation control for
the parking distance control.
20 Rear screen and door mirror de-
icing control
21 ECO mode switch.
22 ESC control (4x4 (4WD) version).
23 Activation/deactivation controls for
the Stop and Start function.
24 4x2 (2WD), 4x4 (4WD) mode selec-
tor or storage compartment.25 Cigarette lighter or accessories
socket.
26 Handbrake.
27 Door mirror adjustment control.
28 Gearstick.
29 LPG control
30 Accessories socket.
31 Bottle holders.
32 Heating and ventilation controls.
33 Cruise control/speed limiter main
control.
34 Radio remote control.
35 Cruise control/speed limiter controls.
36 Beam height adjustment control.
37 Bonnet release control.
38 Fuse box.

JauneNoir Noir texte
1.41
ENG_UD37333_2
Poste de conduite direction à droite (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_1
DRIVING POSITION, RIGHT-HAND DRIVE (2/2)
The presence of the equipment DEPENDS ON THE VEHICLE VERSION AND COUNTRY.
1 Side air vent.
2 Side demister outlet.
3 Location for passenger airbag or
storage compartment.
4 Rear screen and door mirror de-icing
control
5 Hazard warning lights switch.
6 Electric central locking switch.
7 Central demister outlet.
8 Centre air vents.
9 Location for radio, navigation system
or storage compartments.
10 Stalk for:
– direction indicator lights,
– exterior lights,
– front fog lights,
– rear fog light,
– horn.11 Instrument panel.
12 Cruise control/speed limiter controls.
13 – Steering column stalk for wind-
screen and rear screen wash/
wiper.
– On-board computer information
readout control.
14 Side demister outlet.
15 Side air vent.
16 Ignition switch.
17 Bonnet release control.
18 Beam height adjustment control.
19 Radio remote control.
20 Cruise control/speed limiter main
control.
21 Heating and ventilation controls.
22 Gear lever.
23 Handbrake.
24 Door mirror adjustment control.
25 Cigarette lighter or accessories
socket.
26 ECO mode switch.
27 ESC control (version 4x4 (4WD)).
28 Activation/deactivation controls for
the Stop and Start function.
29 Mode selector 4x2 (2WD), 4x4
(4WD) or storage compartment.
30 Glovebox.
31 Fuse box.
32 Passenger airbag activation, deacti-
vation switch.

JauneNoir Noir texte
3.29
ENG_UD32165_1
Equipement multimédia (H79 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_3
MULTIMEDIA EQUIPMENT
The presence and location of this
equipment depends on the vehicle’s
multimedia equipment.
1 Radio or navigation system
2 Steering column control;
3 Microphone.
Please refer to the instruction
manual for details of how it works.
Using the telephone
We remind you of the need
to conform to the legislation
in force concerning the use
of such equipment.
Hands-free telephone
integrated control
On equipped vehicles, use micro-
phone 3 and steering column control 2.
1
2
3

JauneNoir Noir texte
7.3
FRA_UD39333_8
Index (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_7
ALPHABETICAL INDEX (3/5)
L
levels ................................................................4.4, 4.8 → 4.10
levels:
coolant ........................................................................... 4.9
windscreen washer reservoir ....................................... 4.10
lifting the vehicle
changing a wheel ............................... 5.2 – 5.4, 5.9 → 5.11
lighting:
exterior .........................................1.61 – 1.62, 5.16 → 5.23
interior .......................................... 3.11 – 3.12, 5.24 → 5.27
lights ......................................................................1.61 → 1.64
additional ..................................................................... 5.17
adjustment ........................................................ 1.63 – 1.64
lights:
adjusting ........................................................... 1.63 – 1.64
brake lights .................................................................. 5.18
daytime running lights .................................................. 5.16
dipped beam headlights ...................................... 1.61, 5.16
direction indicators ................................... 1.59 – 1.60, 5.16
fog lights ............................................................. 1.62, 5.17
hazard warning ................................................. 1.59 – 1.60
main beam headlights ......................................... 1.61, 5.16
reversing lights ............................................................. 5.18
side lights ............................................................ 1.61, 5.16
locking the doors ................................................................. 1.4
LPG ............. 1.70 – 1.71, 2.3, 2.12 → 2.14, 3.26, 5.28 → 5.35
M
maintenance ...................................................................... 2.20
maintenance:
bodywork .......................................................... 4.16 – 4.17
interior trim ........................................................ 4.18 – 4.19
mechanical ..................................4.4, 4.8, 4.14, 6.9 → 6.14
map reading lights .................................................. 3.11 – 3.12
methods of restraint in addition to the front seat belts ..............
1.18 → 1.20, 1.22mirrors ............................................................................... 3.13
multimedia equipment ....................................................... 3.29
N
navigation .......................................................................... 3.29
navigation system .............................................................. 3.29
O
oil change ..................................................................4.5 → 4.7
opening the doors ..................................................... 1.9 – 1.10
operating faults ......................................................5.45 → 5.49
overspeed buzzer ................................................... 1.49 – 1.50
P
paintwork
maintenance ..................................................... 4.16 – 4.17
reference ........................................................................ 6.2
parking distance control.........................................2.49 → 2.52
power-assisted steering............................................ 1.57, 4.10
power-assisted steering pump........................................... 4.10
practical advice .....................1.72, 3.26, 5.2 – 5.4, 5.9 → 5.37,
5.39 → 5.43, 5.45 → 5.49
puncture.................................................. 5.3 – 5.4, 5.10 – 5.11
R
radio................................................................................... 3.29
fitting a radio ................................................................ 5.43
radio frequency remote control/key
use ................................................................................. 1.2
rear bench seat......................................................3.20 → 3.22
rear parcel shelf ................................................................. 3.27
rear screen de-icing/demisting ..................................3.4 → 3.6
rear seats
functions ..........................................................3.20 → 3.22
rear view camera .................................................... 2.51 – 2.52
rear view mirrors ................................................................ 1.37
