Page 39 of 174
rear screendemisting ......................................................... (current page)
Jaune NoirNoir texte
1.37
ENG_UD25096_5
Poste de conduite direction à gauche (B90 - L90 Ph2 - F90 Ph2 - R90 \
Ph2 - Dacia)
ENG_NU_817-10_B90_Dacia_1
DRIVER’S POSITION, LEFT-HAND DRIVE (2/2)
The presence of the equipment DEPENDS ON THE VEHICLE VERSION AND COUNTRY.
1 Side air ven t.
2
Demister ou
tlet.
3
Stalk for:
–
direction indicator lights,
–
exterior lights,
–
front fog lights,
–
rear fog lights,
–
horn.
4
Instrument panel.
5
Location for
driver’s air bag.
6
S
teering column stalk for wind-
screen and rear screen wash/wipe.
On-board computer information re-
adout control.
7
Centre air vents.
8
L
ocation for passenger air bag or
storage compartment.
9
Demister ou
tlet. 10 Side air ven t.
1
1
Passenger
air bag activation/deac-
tivation switch.
12
Glove box.
13
Location
for radio or storage com-
partment.
14
Electric wind
ow control.
15
Central doo
r locking switch.
16
Hazard war
ning lights switch.
17
Heating and
ventilation controls.
18
Cigar lighter
.
19
Handbrake.
20
R
ear window electric locking con-
trol. 21 Electric doo r mirror control.
22
Location for
ashtray or cup holder.
23
Gear lever
.
24
Heated rear
screen control.
25
Electric wind
ow control.
26
Ignition swit
ch.
27
Headlight
beam height adjustment
control.
28
Bonnet rele
ase.
29
Fuse flap.
Page 41 of 174
JauneNoirNoir texte
1.39
ENG_UD18230_3
Poste de conduite direction à droite (B90 - Dacia)
ENG_NU_817-10_B90_Dacia_1
1 Side air ven t.
2
Demister ou
tlet.
3
S
torage compartment or location
for passenger air bag.
4
Centre air vents.
5
Stalk for:
–
direction indicator lights,
–
exterior lights,
–
front fog lights,
–
rear fog lights.
6
Instrument panel.
7
L
ocation for driver’s air bag (de-
pending on vehicle).
8
Windscreen
wiper/washer stalk.
On-board computer information re-
adout control.
9
Demister ou
tlet. 22 R ear window electric locking con-
trol
23
Electric doo
r mirror control.
24
Location for
ashtray or cup holder.
25
Gear lever
.
26
Heated rear
screen control.
27
Electric wind
ow control.
28
Glove box.
29
Passenger
air bag activation/deac-
tivation switch.
DRIVER’S POSITION, RIGHT- HAND DRIVE (2/2)
The presence of the equipment DEPENDS ON THE VEHICLE VERSION AND COUNTRY.
10
Side air ven
t.
1
1
Fuse box.
12
Bonnet rele
ase.
13
Headlight
beam height adjustment
control.
14
Ignition swit
ch.
15
Location
for radio or storage com-
partment.
16
Electric wind
ow control.
17
Central lock
ing switch.
18
Hazard war
ning lights switch.
19
Heating and
ventilation controls.
20
Cigar lighter
.
21
Handbrake.
Page 128 of 174
bulbschanging ......................................... (up to the end of the DU)
changing a bulb .................................... (up to the end of the DU)
indicators ............................................................... (current page)
practical advice ..................................... (up to the end of the DU)
lighting: exterior ............................................ (up to the end of the DU)
lights: dipped beam headlights .................. (up to the end of the DU)
lights: direction indicators .......................... (up to the end of the DU)
lights: side lights ........................................ (up to the end of the DU)
lights: main beam headlights ..................... (up to the end of the DU)
bulbs changing ......................................... (up to the end of the DU)
5.14
ENG_UD25198_4
Feux avant : remplacement des lampes (B90 - Dacia)
ENG_NU_817-10_B90_Dacia_5
Front side light
Remove bulb holder 4 to access the
bulb.
Bulb type: W5W.
Changing bulbs Front lights
The following bulbs can be replaced.
However, we would advise you to have
them replaced by an approved dealer if
it proves difficult.
Main beam headlights,
dipped beam headlights
Remove cover A .
The engine may be hot
during operations in close
proximity. In addition, the
engine cooling fan may
come on at any moment.
Risk of injury.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
FRONT LIGHTS: changing bulbs
To comply with local legislation, or
as a precaution, you can obtain an
emergency kit containing a set of
spare bulbs and fuses from an ap-
proved dealer.
A
3
4
Remove bulb connector 1 . Release
spring 2 and take out the bulb.
Bulb type: H4 anti UV bulb (see box).
Do not touch the bulb glass. Hold it
by its base.
Direction indicator lights
Turn bulb holder 3 a quarter of a turn
and take out the bulb.
Bulb type: PY21W.
When the bulb has been changed,
make sure you refit the cover correctly.
21
Page 138 of 174
5.24
ENG_UD22587_8
Fusibles (B90 - Dacia)
ENG_NU_817-10_B90_Dacia_5
FUSES (3/3)
Allocation of fuses
(the presence of certain fuses DEPENDS ON THE VEHICLE EQUIPMENT LEVEL)\
Symbol Allocation
QLeft-hand main beam
headlight
LLeft-hand dipped beam
headlight
TRight-hand dipped
beam headlight
VRight-hand side light
YLeft-hand side light
FRear fog light
ḼElectric rear windows
Symbol Allocation
qEngine immobiliser
ËReversing light
uPower-assisted steering
iAutomatic gearbox
GAS fuel
