BODY WIRING SYSTEM 9A – 15
DAEWOO V–121 BL4
FRONT HARNESS ROUTING
J4B39A12

9A – 16IBODY WIRING SYSTEM
DAEWOO V–121 BL4
REAR HARNESS ROUTING
J3B19A13

BODY WIRING SYSTEM 9A – 17
DAEWOO V–121 BL4
HATCHBACK REAR HARNESS ROUTING

9A – 18IBODY WIRING SYSTEM
DAEWOO V–121 BL4
FLOOR HARNESS ROUTING
J3B19A14

BODY WIRING SYSTEM 9A – 19
DAEWOO V–121 BL4
INSTRUMENT HARNESS ROUTING
J4B39A15

9A – 20IBODY WIRING SYSTEM
DAEWOO V–121 BL4
DOOR HARNESS ROUTING
J3B19A16

SECTION : 9B
LIGHTING SYSTEMS
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS9B–2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Usage Chart 9B–2. . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 9B–2. . . . . . . . . . .
SCHEMATIC AND ROUTING DIAGRAMS9B–3 . . . . .
Backup Lamps Circuit 9B–3. . . . . . . . . . . . . . . . . . . . . .
Instruments Circuit (W/O Dimmer Control :
General Only) 9B–4. . . . . . . . . . . . . . . . . . . . . . . . . . .
Instruments Circuit (W/ Dimmer Control) 9B–5. . . . . .
Front And Rear Fog Lamps Circuit 9B–6. . . . . . . . . . .
Headlamps–On Reminder Chime Circuit 9B–7. . . . . .
Headlamps and Headlamp Leveling Circuit 9B–8. . . .
Daytime Running Lamps Circuit 9B–9. . . . . . . . . . . . .
Parking, Tail and License Lamps Circuit 9B–10. . . . . .
Stoplamps Circuit 9B–11. . . . . . . . . . . . . . . . . . . . . . . . .
Turn and Hazard Lamps Circuit 9B–12. . . . . . . . . . . . .
Interior Courtesy and Luggage Compartment Lamp
Circuit 9B–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DIAGNOSIS9B–14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps–On Reminder Chime 9B–14. . . . . . . . . . .
Headlamps 9B–16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamp Leveling 9B–20. . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps 9B–22. . . . . . . . . . . . . . . . . . .
Parking Lamps and Taillamps 9B–23. . . . . . . . . . . . . .
Interior Courtesy and Luggage Compartment
Lamps 9B–31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog Lamps 9B–34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND REPAIR9B–36 . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9B–36. . . . . . . . . . . . . . . . . . . . Headlamps/Front Turn Signal Lamps 9B–36. . . . . . . .
Daytime Running Lamp Module 9B–37. . . . . . . . . . . . .
Parking Lamps 9B–37. . . . . . . . . . . . . . . . . . . . . . . . . . .
Side Turn Signal Lamps 9B–38. . . . . . . . . . . . . . . . . . .
Front Fog Lamps 9B–38. . . . . . . . . . . . . . . . . . . . . . . . .
Notchback Rear Combination Lamps 9B–39. . . . . . . .
Hatchback Rear Combination Lamps 9B–40. . . . . . . .
Hatchback Extension Lamps 9B–40. . . . . . . . . . . . . . .
Notchback Center High–Mounted Stoplamp 9B–41. .
Hatchback Center High–Mounted Stoplamp 9B–41. .
License Plate Lamps 9B–42. . . . . . . . . . . . . . . . . . . . . .
Door Jamb Switch 9B–42. . . . . . . . . . . . . . . . . . . . . . . .
Center Room Lamp 9B–43. . . . . . . . . . . . . . . . . . . . . . .
Map Lamp 9B–43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage Compartment Lamp 9B–44. . . . . . . . . . . . . . .
Ashtray and Cigar Lighter Lamp 9B–44. . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION9B–46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps–On Reminder Chime 9B–46. . . . . . . . . . .
Headlamps 9B–46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps 9B–46. . . . . . . . . . . . . . . . . . .
Parking and Turn Signal Lamps 9B–46. . . . . . . . . . . . .
Fog Lamps 9B–46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Combination Lamps 9B–46. . . . . . . . . . . . . . . . . .
License Plate Lamp 9B–46. . . . . . . . . . . . . . . . . . . . . . .
Interior Courtesy Lamp 9B–46. . . . . . . . . . . . . . . . . . . .
Luggage Compartment Lamp 9B–46. . . . . . . . . . . . . . .
Backup Lamps 9B–47. . . . . . . . . . . . . . . . . . . . . . . . . . .

9B – 2ILIGHTING SYSTEMS
DAEWOO V–121 BL4
SPECIFICATIONS
BULB USAGE CHART
BulbReplacement Bulb Number
Backup Lamp21W
Center High–Mounted Stoplamp5W
Front Fog Lamp27W
Headlamp55W
Interior Courtesy Lamp10W
License Plate Lamp5W
Luggage Compartment Lamp10W
Park and Front Turn Signal LampDouble 21/5W
Rear Fog Lamp21W
Rear Turn Signal Lamp21W
Side Turn Signal Lamp5W
Taillamp and StoplampDouble 21/5W
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNSmLb–FtLb–In
CHMSL Mounting Nuts4–35
Door Jamb Switch Screw4–35
Front Fog Lamp Nuts4–35
Headlamp Assembly Bolts and Nuts4–35
License Plate Lamp Screws4–35
Map Lamp Screws1.5–13
Rear Combination Lamp Assembly Screws4–35
Hatchback Extension Lamp3–27

LIGHTING SYSTEMS 9B – 3
DAEWOO V–121 BL4
SCHEMATIC AND ROUTING DIAGRAMS
BACKUP LAMPS CIRCUIT

9B – 4ILIGHTING SYSTEMS
DAEWOO V–121 BL4
INSTRUMENTS CIRCUIT
(W/O DIMMER CONTROL : GENERAL ONLY)
