Page 405 of 517
CAUTION!
Do not attempt to raise the vehicle by jacking on
locations other than those indicated in the Jacking
Instructions for this vehicle.
NOTE: Refer to the “Spare Tire” section of “Tires —
General Information” in “Starting And Operating” for
information about the spare tire, its use, and operation.
1.
Remove the scissors jack and lug wrench from the spare
wheel as an assembly. Turn the jack screw to the left to
loosen the lug wrench, and remove the wrench from the
jack assembly.
NOTE: The jack handle attaches to the side of the jack
with two attachment points. When the jack is partially
expanded, the tension between the two attachment
points holds the jack handle in place.
Jack Warning Label
Removing Jack Handle From Jack
6
WHAT TO DO IN EMERGENCIES 403
