Page 61 of 360
ENGINE BREAK-IN RECOMMENDATIONS
A long break-in period is not required for the engine in
your new vehicle.
Drive moderately during the first 300 miles (500 km).
After the initial 60 miles (100 km), speeds up to 50 or 55
mph (80 or 90 km/h) are desirable.
While cruising, brief full-throttle acceleration, within the
limits of local traffic laws, contributes to a good break-in.
Wide open throttle acceleration in low gear can be
detrimental and should be avoided.
The engine oil installed in the engine at the factory is a
high quality energy conserving type lubricant. Oil
changes should be consistent with anticipated climate
conditions under which vehicle operations will occur.
The recommended viscosity and quality grades are
shown in Section 7 of this manual. NON-DETERGENT
OR STRAIGHT MINERAL OILS MUST NEVER BE
USED.A new engine may consume some oil during its first few
thousand miles (kilometers) of operation. This should be
considered as a normal part of the break-in and not
interpreted as an indication of difficulty.
SAFETY TIPS
Exhaust Gas
WARNING!
Exhaust gases can injure or kill. They contain carbon
monoxide (CO) which is colorless and odorless.
Breathing it can make you unconscious and can
eventually poison you. To avoid breathing (CO)
follow the safety tips below.
Do not run the engine in a closed garage or in confined
areas any longer than needed to move your vehicle in or
out of the area.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61
2
Page 62 of 360
If it is necessary to sit in a parked vehicle with the engine
running, adjust your heating or cooling controls to force
outside air into the vehicle. Set the blower at high speed.
WARNING!
If you are required to drive with the deck lid /
liftgate open, make sure that all windows are closed,
and the climate control blower switch is set at high
speed. DO NOT use the recirculation mode.
Safety Checks You Should Make Inside The
Vehicle
Seat Belts
Inspect the belt system periodically, checking for cuts,
frays and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.
Front seat belt assemblies must be replaced after a
collision. Rear seat belt assemblies must be replaced after
a collision if they have been damaged (bent retractor, torn
webbing, etc. If there is any question regarding belt or
retractor condition, replace the belt.
Airbag Light
The light should come on and remain on for 6 to 8
seconds as a bulb check when the ignition switch is first
turned ON. If the LED is not lit during starting, have it
checked. If the light stays on or comes on while driving,
have the system checked by an authorized dealer.
Defroster
Check operation by selecting the defrost mode and place
the blower control on high speed. You should be able to
feel the air directed against the windshield.
Periodic Safety Checks You Should Make Outside
The Vehicle
Tires
Examine tires for excessive tread wear or uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect tread and sidewall for cuts or
cracks. Check wheel nuts for tightness, and tires (includ-
ing spare) for proper pressure.
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 63 of 360
Lights
Have someone observe the operation of exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
engine coolant, oil or other fluid leaks. Also, if gasoline
fumes are detected or fuel, power steering fluid, trans-
mission fluid or brake fluid leaks are suspected, the cause
should be located and corrected immediately.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63
2
Page 64 of 360
Page 65 of 360
UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS
Mirrors..............................69
▫Inside Day/Night Mirror — If Equipped......69
▫Outside Mirror—Driver’s Side.............69
▫Outside Mirror—Passenger’s Side...........69
▫Electric Remote-Control Mirrors............70
▫Vanity Mirrors — If Equipped.............71
▫Sun Visor Sliding Feature................71
Hands–Free Communication (UConnect™) —
If Equipped
...........................72
▫Operations...........................73
▫Phone Call Features....................79
▫UConnect™ System Features..............81▫Advanced Phone Connectivity.............84
▫Things You Should Know About
Your UConnect™ System.................86
▫General Information....................93
Seats................................94
▫Front Seat Adjustment...................94
▫Manual Seat Height Adjustment —
If Equipped..........................95
▫Manual Lumbar— If Equipped.............95
▫Driver’s Seat Back Recline................96
▫Adjustable Head Restraints...............96
▫Heated Seats — If Equipped..............97
3
Page 66 of 360
▫Fold Flat Front Passenger Seat.............98
▫Folding Rear Seat......................99
▫Reclining Rear Seat — If Equipped.........100
To Open And Close The Hood............101
Lights..............................102
▫Map/Reading Lights...................102
▫Multi-Function Control Lever.............103
▫Headlights, Parking Lights,
Instrument Panel Lights.................103
▫Lights-On Reminder...................104
▫Fog Lights — If Equipped...............104
▫Turn Signals.........................105
▫Highbeam/Lowbeam Select Switch.........105
▫Passing Light........................106
Daytime Running Lights (DRL) —
If Equipped
..........................106▫Functionality........................106
Windshield Wipers And Washers..........106
▫Windshield Washers...................106
▫Mist Feature.........................107
▫Windshield Wiper Operation.............108
▫Intermittent Wiper System...............108
▫Adding Washer Fluid..................108
Tilt Steering Column....................108
Electronic Speed Control — If Equipped.....109
▫ToActivate ..........................110
▫To Set At A Desired Speed...............110
▫To Deactivate........................110
▫To Resume Speed.....................110
▫To Vary The Speed Setting...............110
▫Manual Transaxle.....................111
▫To Accelerate For Passing...............111
66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 67 of 360
Garage Door Opener — If Equipped........112
▫Programming The Universal Transceiver.....113
▫“Rolling Code” Programming............114
▫Canadian Programming/
Gate Programming....................116
▫Operation...........................116
▫Reprogramming A Single Button..........116
▫Security............................116
Anti-Lock Brake System (ABS) –
If Equipped
..........................117
Electronic Brake Control System -
ABS/TCS/BAS/ESP — If Equipped
........118
▫Traction Control System (TCS) —
If Equipped.........................118
▫Brake Assist System (BAS) — If Equipped....118
▫ESP (Electronic Stability Program) —
If Equipped.........................119
Power Sunroof — If Equipped............122
▫Opening Sunroof – Manual..............123
▫Opening Sunroof – Express Mode..........123
▫Closing Sunroof – Manual...............123
▫Closing Sunroof – Express Mode..........123
▫Pinch Protect Feature...................123
▫Pinch Protect Override.................123
▫Venting Sunroof – Express...............124
▫Sunshade Operation...................124
▫Wind Buffeting.......................124
▫Sunroof Maintenance...................124
▫Ignition Off Operation..................124
Electrical Power Outlets.................124
▫Electrical Outlet Use With Engine Off.......126
Console Features......................127
Cargo Area Features....................128
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 67
3
Page 68 of 360
▫Cargo Light/Removable Self- Recharging
Flashlight – If Equipped................128
▫Tonneau Cover — If Equipped............130
▫Removable Load Floor..................130
▫Cargo Tie-Down Loops.................130
▫Fold Down Speakers – If Equipped.........132Rear Window Features..................132
▫Rear Window Wiper/Washer.............132
▫Rear Window Defroster.................134
Roof Luggage Rack — If Equipped.........134
Cooled Beverage Storage Bin/Glove
Compartment — If Equipped
.............134
68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 69 of 360
MIRRORS
Inside Day/Night Mirror — If Equipped
Adjust the mirror to center on the view through the rear
window. A two point pivot system allows for horizontal
and vertical mirror adjustment.
Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position
(toward rear of vehicle). The mirror should be adjusted
while set in the day position (toward windshield).
Outside Mirror—Driver’s Side
Adjust the Flat (Drivers Side) Outside Mirror so you can
just see the side of your vehicle in the part of the mirror
closest to vehicle with your head close to the door glass.
Outside Mirror—Passenger’s Side
Adjust the convex outside mirror so you can just see the
side of your vehicle in the part of the mirror closest to the
vehicle.
WARNING!
Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side mirror could cause you to collide
with another vehicle or other object. Use your inside
mirror when judging the size or distance of a vehicle
seen in this convex mirror.
Adjusting Rear View Mirror
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 69
3
Page 70 of 360
Electric Remote-Control Mirrors
The controls for the power mirrors are located on the
driver’s door trim panel.
To adjust a mirror, turn the control wand toward the left
or right mirror positions indicated. Tilt the control wand
in the direction you want the mirror to move. When
finished adjusting the mirror, turn the control to the
center position to prevent accidentally moving a mirror.
Remote Control Mirrors Switch
Mirror Directions
