Page 248 of 360
Follow the recommended tire rotation frequency for your
type of driving found in the “Maintenance Schedules”
Section of this manual. More frequent rotation is permis-
sible if desired. The reasons for any rapid or unusual
wear should be corrected before rotating. The suggested
rotation method is the “forward-cross” shown in the
diagram.FUEL REQUIREMENTS
GASOLINE ENGINES
Your vehicle is designed to meet all emis-
sion regulations and provide excellent fuel
economy when using high quality regular
unleaded gasoline with an octane rating of
87. The use of premium gasoline is not
recommended. The use of premium gaso-
line will provide no benefit over high quality regular
gasolines, and in some circumstances, may result in
poorer performance.
Light spark knock at low engine speeds is not harmful to
your engine. However, continued heavy spark knock at
high speeds can cause damage and immediate service is
required.
Poor quality gasoline can cause problems such as hard
starting, stalling and hesitations. If you experience these
symptoms, try another brand of gasoline (with the ap-
propriate octane rating for your engine) before consider-
ing service for the vehicle.
248 STARTING AND OPERATING
Page 249 of 360
Reformulated Gasoline
Many areas of the country require the use of cleaner
burning gasoline referred to as “Reformulated Gasoline”.
Reformulated gasolines contain oxygenates, and are spe-
cifically blended to reduce vehicle emissions and im-
prove air quality.
The manufacturer supports the use of reformulated gaso-
lines. Properly blended reformulated gasolines will pro-
vide excellent performance and durability of engine and
fuel system components.
Gasoline/Oxygenate Blends
Some fuel suppliers blend unleaded gasoline with oxy-
genates such as 10% ethanol, MTBE, and ETBE. Oxygen-
ates are required in some areas of the country during the
winter months to reduce carbon monoxide emissions.
Fuels blended with these oxygenates may be used in
your vehicle.
CAUTION!
DO NOT use gasolines containing Methanol or E85
Ethanol. Use of these blends may result in starting
and driveability problems and may damage critical
fuel system components.
Problems that result from using methanol/gasoline
blends are not the responsibility of the manufacturer.
While MTBE is an oxygenate made from Methanol, it
does not have the negative effects of Methanol.
MMT In Gasoline
MMT is a manganese containing metallic additive that is
blended into some gasoline to increase the octane num-
ber. Gasolines blended with MMT offer no performance
advantage beyond gasolines of the same octane number
without MMT. Gasolines blended with MMT have shown
to reduce spark plug life and reduce emission system
performance in some vehicles. The manufacturer recom-
mends using gasolines without MMT. Since the MMT
STARTING AND OPERATING 249
5
Page 251 of 360
•The use of fuel additives which are now being sold as
octane enhancers is not recommended. Most of these
products contain high concentrations of methanol.
Fuel system damage or vehicle performance problems
resulting from the use of such fuels or additives is not
the responsibility of the manufacturer.
NOTE:Intentional tampering with emissions control
systems can result in civil penalties being assessed
against you.
Carbon Monoxide Warnings
WARNING!
Carbon monoxide (CO) in exhaust gases is deadly.
Follow the precautions below to prevent carbon
monoxide poisoning:
•Do not inhale exhaust gases. They contain carbon
monoxide, a colorless and odorless gas which can kill.
Never run the engine in a closed area, such as a
garage, and never sit in a parked vehicle with the
engine running for an extended period. If the vehicle is
stopped in an open area with the engine running for
more than a short period, adjust the ventilation system
to force fresh, outside air into the vehicle.
•Guard against carbon monoxide with proper mainte-
nance. Have the exhaust system inspected every time
the vehicle is raised. Have any abnormal conditions
repaired promptly. Until repaired, drive with all side
windows fully open.
•Keep the liftgate closed when driving your vehicle to
prevent carbon monoxide and other poisonous ex-
haust gases from entering the vehicle.
STARTING AND OPERATING 251
5
Page 317 of 360
FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) or equivalent.
Engine Oil Use API Certified SAE 5W-20 Engine Oil. Refer to your engine oil filler cap
for correct SAE grade meeting DaimlerChrysler Material Standard MS-6395.
Engine Oil Filter Mopar04884900AB or equivalent.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection 87 Octane (R + M)/2
MAINTAINING YOUR VEHICLE 317
7
Page 350 of 360
Fabric Care........................... 305
Filler Location Fuel..................... 144
Filters
Air Cleaner.......................... 288
Engine Fuel......................... 288
Engine Oil.......................286,317
Flashers.............................. 266
Hazard Warning...................... 266
Turn Signal.......................... 312
Flat Tire Stowage....................... 271
Flooded Engine Starting.................. 209
Fluid, Brake........................... 318
Fluid Capacities........................ 316
Fluid Leaks............................ 63
Fluid Level Checks
Automatic Transaxle................... 301
Fluids ............................... 317
Fluids, Lubricants and Genuine Parts........ 317
FogLights ......................104,149,311
Fog Lights, Rear........................ 152
Folding Rear Seat....................... 99
Folding Rear Seat (Sedan)................. 99
FreeingAStuckVehicle .................. 274Fuel..............................248,317
Adding............................. 252
Additives ........................... 250
Capacity............................ 316
CleanAir ........................... 249
Filler Cap (Gas Cap)................144,252
Filler Door (Gas Cap).................. 144
Filter.............................. 288
Gasoline............................ 248
Gauge............................. 144
Hoses.............................. 298
Light .............................. 145
OctaneRating ........................ 248
Requirements........................ 248
System Hoses........................ 298
Tank Capacity........................ 316
Fuel System Caution.................... 254
Fueling .............................. 252
Fuses................................ 307
Garage Door Opener (HomeLink) .......... 112
Gas Cap (Fuel Filler Cap)...........252,253,280
Gasoline, Clean Air..................... 249
350 INDEX
Page 354 of 360
Navigation Radio....................... 192
Navigation System...................... 192
New Vehicle Break-In Period............... 61
Occupant Classification System (OCS)........ 44
Occupant Restraints (Sedan)................ 28
Octane Rating, Gasoline (Fuel)............. 248
Odometer............................ 147
Trip ............................147,148
Oil, Engine.........................283,316
Capacity............................ 316
Change Interval...................... 284
Checking........................... 283
Disposal............................ 286
Filter.............................. 286
Identification Logo.................... 285
Materials Added to.................... 286
Recommendation..................285,316
Synthetic........................... 285
Viscosity............................ 285
Oil Pressure Light...................... 145
Onboard Diagnostic System............280,281
Opener, Garage Door (HomeLink) ......... 112Operator Manual (Owner’s Manual).......... 4
OutsideAirIntake ...................... 204
Overdrive............................ 213
Overheating, Engine..................... 266
Owner’s Manual (Operator Manual)....... 4,341
PaintCare ............................ 303
Panic Alarm........................... 21
Parking Brake......................... 218
Passing Light.......................... 106
Performance........................... 213
Personal Settings....................... 155
Pets .................................. 60
Phone, Cellular......................... 72
Phone, Hands-Free (UConnect™)............ 72
Placard, Tire and Loading Information....... 229
Power
Distribution Center (Fuses).............. 307
Door Locks.......................... 15
Mirrors ............................. 70
Outlet (Auxiliary Electrical Outlet)........ 124
Steering .........................223,291
Steering, Checking.................... 291
354 INDEX
