radio antenna DODGE CALIBER 2007 1.G Owners Manual

▫TapeEject...........................184
▫Scan Button.........................185
▫Changing Tape Direction................185
▫Metal Tape Selection...................185
▫Pinch Roller Release...................185
▫Noise Reduction......................185
▫Operation Instructions -
(CD Mode For CD Audio Play)...........185
▫Load/Eject Button
(CD Mode For CD Audio Play)...........186
▫Notes On Playing MP3 Files.............188
▫Operation Instructions - (CD Mode For MP3
And WMA Audio Play).................190
▫Load/Eject Button (CD Mode For MP3
AndWMAPlay) ......................190

Sales Code REC — AM/FM/CD
(6–Disc) Radio With Navigation System
.....192▫Operating Instructions — Satellite Radio
(If Equipped)........................192
▫Clock Setting Procedure.................192

Satellite Radio — If Equipped.............193
▫System Activation.....................193
▫Electronic Serial Number/Sirius
Identification Number (ESN/SID)..........193
▫Selecting Satellite Mode In REF,
And RAQ, Radios.....................194
▫Selecting a Channel....................194
▫Storing And Selecting Pre-Set Channels......195
▫Using The PTY (Program Type) Button
(If Equipped)........................195
▫PTY ButtonScan.....................195
▫PTY ButtonSeek.....................195
▫Satellite Antenna......................195
▫Reception Quality.....................195
UNDERSTANDING YOUR INSTRUMENT PANEL 139
4

Storing and Selecting Pre-Set Channels
In addition to the 12 AM and 12 FM pre-set stations, you
may also commit 12 satellite stations to push button
memory. These satellite channel pre-set stations will not
erase any AM or FM pre-set memory stations. Follow the
memory pre-set procedures that apply to your radio.
Using the PTY (Program Type) Button (if
equipped)
Follow the PTY button instructions that apply to your
radio.
PTY ButtonSCAN
When the desired program type is obtained, press the
SCANbutton within five seconds. The radio will play 7
seconds of the selected channel before moving to the next
channel of the selected program type. Press theSCAN
button a second time to stop the search.
NOTE:Pressing theSEEKorSCANbutton while
performing a music type scan will change the channel by
one and stop the search. Pressing a pre-set memory
button during a music type scan, will call up the memory
channel and stop the search.
PTY ButtonSEEK
When the desired program is obtained, press theSEEK
button within five seconds. The channel will change to
the next channel that matches the program type selected.
Satellite Antenna
To ensure optimum reception, do not place items on the
roof around the rooftop antenna location. Metal objects
placed within the line of sight of the antenna will cause
decreased performance. Larger luggage items should be
placed as far forward as possible. Do not place items
directly on or above the antenna. The luggage rack (if
equipped), should also not be positioned directly above
the antenna.
Reception Quality
Satellite reception may be interrupted due to one of the
following reasons.
•The vehicle is parked in an underground parking
structure or under a physical obstacle.
•Dense tree coverage may interrupt reception in the
form of short audio mutes.
UNDERSTANDING YOUR INSTRUMENT PANEL 195
4

•Driving under wide bridges or along tall buildings can
cause intermittent reception.
•Placing objects over or too close to the antenna can
cause signal blockage.
REMOTE SOUND SYSTEM CONTROLS — IF
EQUIPPED
The remote sound system controls are located on the rear
surface of the steering wheel. Reach behind the wheel to
access the switches.The right hand control is a rocker type switch with a push
button in the center. Pressing the top of the switch will
increase the volume and pressing the bottom of the
switch will decrease the volume.
The button located in the center of the right hand control
will switch modes to Radio or CD.
The left hand control is a rocker type switch with a push
button in the center. The function of the left hand control
is different depending on which mode you are in.
The following describes the left hand control operation in
each mode.
Radio Operation
Pressing the top of the switch will SEEK up for the next
listenable station and pressing the bottom of the switch
will SEEK down for the next listenable station.
The button located in the center of the left hand control
will tune to the next pre-set station that you have
programmed in the radio pre-set push-buttons.
196 UNDERSTANDING YOUR INSTRUMENT PANEL

RADIO OPERATION AND CELLULAR PHONES
Under certain conditions, the cellular phone being ON in
your vehicle can cause erratic or noisy performance from
your radio. This condition may be lessened or eliminated
by relocating the cellular phone antenna. This condition
is not harmful to the radio. If your radio performance
does not satisfactorily “clear” by the repositioning of the
antenna, it is recommended that the radio volume be
turned down or off during cellular phone operation.
CLIMATE CONTROLS
Climate Controls
The Climate Control System allows you to balance the
temperature, amount, and direction of air circulating
throughout the vehicle. The controls are located on the
instrument panel, below the radio.The air conditioning system of your vehicle contains
R-134a, a refrigerant that does not deplete the ozone layer
in the upper atmosphere.Climate Control Location
198 UNDERSTANDING YOUR INSTRUMENT PANEL

Mopar Total Clean is specifically recommended for
leather upholstery.
Your leather upholstery can be best preserved by regular
cleaning with a damp soft cloth. Small particles of dirt
can act as an abrasive and damage the leather upholstery
and should be removed promptly with a damp cloth.
Stubborn soils can be removed easily with a soft cloth
and Mopar Total Clean. Care should be taken to avoid
soaking your leather upholstery with any liquid. Please
do not use polishes, oils, cleaning fluids, solvents, deter-
gents, or ammonia based cleaners to clean your leather
upholstery. Application of a leather conditioner is not
required to maintain the original condition.
WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
Cleaning Headlights
Your vehicle has plastic headlights that are lighter and
less susceptible to stone breakage than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with Mopar Glass Cleaner or any commercial household-
type glass cleaner. Never use an abrasive type cleaner.
Use caution when cleaning the inside rear window
equipped with electric defrosters or the right rear quarter
window equipped with the radio antenna. Do not use
scrapers or other sharp instruments which may scratch
306 MAINTAINING YOUR VEHICLE

ABS (Anti-Lock Brake System)............. 220
Accelerator Pedal....................... 213
Adding Engine Coolant (Antifreeze)......... 295
Adding Fuel.......................... 252
Adding Washer Fluid.................108,133
Additives, Fuel........................ 250
Air Cleaner, Engine
(Engine Air Cleaner Filter)................ 288
Air Conditioner Maintenance.............. 290
Air Conditioning Controls................ 198
Air Conditioning, Operating Tips........... 203
Air Conditioning Refrigerant...........290,291
Air Conditioning System..............198,290
Air Pressure, Tires...................... 234
Airbag................................ 39
Airbag Deployment...................... 49
Airbag Light...................... 52,62,145
Airbag Maintenance...................... 51
Airbag, Side........................... 47
Alarm System (Security Alarm).......... 24,145
Alignment and Balance.................. 240
All Wheel Drive (AWD).................. 217
Alterations/Modifications, Vehicle............ 6Antenna, Satellite Radio.................. 195
Antifreeze (Engine Coolant).........294,316,317
Capacities........................... 316
Disposal............................ 296
Anti-Lock Brake System (ABS).......... 117,220
Anti-Theft Security Alarm (Theft Alarm)...... 24
Appearance Care....................... 303
Automatic Door Locks.................. 16,17
Automatic Transaxle........... 9,208,210,267,301
Fluid Level Check..................... 301
Interlock System.................... 14,212
Overheating......................... 267
Selection Of Lubricant................. 301
Shifting............................ 212
Special Additives..................... 301
Autostick ............................. 214
BallJoints ............................ 291
Battery ............................... 289
Keyless Transmitter Replacement (RKE)..... 23
Belts,Drive ........................... 286
Beverage Cooler........................ 134
Body Mechanism Lubrication.............. 292
346 INDEX

Safety Checks Inside Vehicle............... 62
Safety Checks Outside Vehicle.............. 62
Safety Defects, Reporting................. 341
Safety Information, Tire.................. 225
SafetyTips ............................. 61
Satellite Radio......................192,193
Satellite Radio Antenna.................. 195
Schedule, Maintenance................... 320
Seat Belt Maintenance................... 307
Seat Belt Reminder...................... 37
Seat Belts
Adjustable Shoulder Belt................ 33
Adjustable Upper Shoulder Anchorage...... 33
And Pregnant Women.................. 39
Child Restraint........................ 54
Front Seat............................ 29
Pretensioners......................... 37
Rear Seat............................ 29
Reminder........................... 145
Seat Belts (Sedan)....................... 28
Seats................................. 94
Adjustment.......................... 94
Cleaning............................ 305Head Restraints....................... 96
Heated.............................. 97
Lumbar Support....................... 95
Rear Folding......................... 99
Rear Folding (Sedan)................... 99
Seatback Release....................... 96
Tilting.............................. 96
Security Alarm (Theft Alarm)............... 24
SelectionofOil ........................ 285
Sentry Key (Immobilizer)................ 11,25
Sentry Key Programming.................. 12
Service and Maintenance................. 320
Service Assistance...................... 338
ServiceContract ........................ 340
Service Manuals........................ 341
Setting the Clock...........162,164,170,181,192
Settings, Personal....................... 155
Shift Speeds, Manual Transaxle............ 216
Shoulder Belts.......................... 29
Side Airbag............................ 47
Side Window Demisters (Defrosters)......... 204
Signals, Turn.......................... 312
Slippery Surfaces, Driving On............. 224
356 INDEX
