The power liftgate may also be opened by pressing the
button located on the overhead console.
When the remote keyless entry transmitter button is
pressed and the“Lamp Flash”feature is enabled, the tail
lights will flash to signal that the liftgate is opening or
closing.WARNING!
During power operation, personal injury or cargo
damage may occur. Ensure the liftgate travel path is
clear. Make sure the liftgate is closed and latched
before driving away.
NOTE:
•If anything obstructs the power liftgate while it is
closing or opening, the liftgate will automatically
reverse to the closed or open position, provided it
meets sufficient resistance.
•There are also pinch sensors attached to the side of the
liftgate opening. Light pressure anywhere along these
strips will cause the liftgate to return to the open
position.
Power Liftgate Switch
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

However, if you haven’t healed significantly within a
few days, or if you have any blistering, see your doctor
immediately.
•As the airbags deflate you may see some smoke-like
particles. The particles are a normal by-product of the
process that generates the nontoxic gas used for airbag
inflation. These airborne particles may irritate the skin,
eyes, nose, or throat. If you have skin or eye irritation,
rinse the area with cool water. For nose or throat
irritation, move to fresh air. If the irritation continues,
see your doctor. If these particles settle on your
clothing, follow the garment manufacturer’s instruc-
tions for cleaning.
•It is not advisable to drive your vehicle after the
airbags have deployed. If you are involved in another
collision, the airbags will not be in place to protect you.
WARNING!
Deployed airbags, front seat belt buckle pretension-
ers and driver inflatable knee blocker cannot protect
you in another collision. Have the airbags, front seat
belt buckle pretensioners and driver inflatable knee
blocker replaced by an authorized dealer as soon as
possible. Also, have the Occupant Classification
System serviced as well.
Enhanced Accident Response
If the airbags and seat belt pertensioners deploy after an
impact and the electrical system remains functional,
vehicles equipped with power door locks will unlock
automatically. In addition, approximately 10 seconds
after the vehicle has stopped moving, the interior lights
will illuminate until the ignition switch is turned off.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67
2

Next, push to the left the safety catch located under the
front edge of the hood, near the center.
Use the hood prop rod to secure the hood in the open
position.
To prevent possible damage, do not slam the hood to
close it. Lower the hood until it is open approximately 30cm (12 inches) and then drop it. This should secure both
latches. Never drive your vehicle unless the hood is fully
closed, with both latches engaged.
WARNING!
If the hood is not fully latched, it could fly up when
the vehicle is moving and block your forward vision.
You could have a collision. Be sure all hood latches
are fully latched before driving.
LIGHTS
All of the lights, except the hazard warning lights, are
controlled by switches to the left of the steering column
on the instrument panel.
Hood Safety Catch
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

MULTIFUNCTION LEVER
Turn Signals
Move the Multifunction Lever up or down and the
arrows on each side of the base instrument cluster or
Information Center flash to indicate proper operation of
the front and rear turn signal lights. You can signal a lane
change by moving the lever partially up or down.
If either indicator flashes at a rapid rate, check for a
defective outside turn signal light bulb. If one of the
indicators fails to light when the lever is moved, it would
suggest that the indicator light is defective.
Turn Signal Warning
If the vehicle electronics sense that the vehicle has
traveled at over 18 mph (29 km/h) for about one mile
with the turn signals on, a chime will sound to alert the
driver.
Turn Signal Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147
3

WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, see Section 7 of this manual. Follow
the warnings under the Cooling System Pressure
Cap paragraph.
17. Washer Fluid Light
This light turns on when the washer fluid level
falls below approximately 1/4 filled. The light will
remain on until fluid is added.
18. Transmission Range Indicator
This display indicator shows the automatic transaxle gear
selection.NOTE:You must apply the brakes before shifting from
Park.
19. Oil Pressure Warning Light
This light shows low engine oil pressure. The light
should turn on momentarily when the engine is
started. If the light turns on while driving, stop the
vehicle and shut off the engine as soon as possible. A
chime will sound for 4 minutes when this light turns on.
Do not operate the vehicle until the cause is corrected.
This light does not show how much oil is in the engine.
The engine oil level must be checked under the hood.
20. High Beam Light
This light shows that the headlights are on high
beam. Pull the turn signal lever towards the
steering wheel to switch the headlights from high or low
beam.
UNDERSTANDING YOUR INSTRUMENT PANEL 209
4

WARNING!
Do not connect trailer brakes to your vehicle’s hy-
draulic brake lines. It can overload your brake sys-
tem and cause it to fail. You might not have brakes
when you need them and could have an accident.
Towing any trailer will increase your stopping dis-
tance. When towing you should allow for additional
space between your vehicle and the vehicle in front
of you. Failure to do so could result in an accident.
Towing Requirements—Trailer Lights & Wiring
Whenever you pull a trailer, regardless of the trailer size,
stop lights and turn signals on the trailer are required for
motoring safety.
The Trailer Tow Package may includea4and7pin
wiring harness. Use a factory approved trailer harness
and connector.NOTE:Do not cut or splice wiring into the vehicles
wiring harness.
The electrical connections are all complete to the vehicle
but you must mate the harness to a trailer connector.
Refer to the following illustrations.
4 - Pin Connector
STARTING AND OPERATING 361
5

Adding Fuel........................... 346
Adding Washer Fluid..................299,414
Additives, Fuel......................... 344
Adjustable Pedals....................... 153
Air Conditioner Maintenance............... 410
Air Conditioning.....................274,279
Air Conditioning Controls................. 274
Air Conditioning Filter.................296,411
Air Conditioning, Operating Tips............ 296
Air Conditioning, Rear Zone.............282,291
Air Conditioning Refrigerant............... 410
Air Conditioning System..........274,279,284,410
Air Conditioning System, Zone Control........ 275
Air Pressure, Tires....................... 329
Airbag................................ 54
Airbag Deployment....................... 66
Airbag Light...................59,60,68,84,206
Airbag Maintenance....................... 68
Airbag, Window (Side Curtain)............... 55Alarm Light........................... 208
Alarm System (Security Alarm)............... 26
Alignment and Balance................... 336
Alterations/Modifications, Vehicle............. 7
Antenna, Satellite Radio................... 269
Antifreeze (Engine Coolant)...........417,418,443
Disposal............................ 419
Anti-Lock Brake System (ABS).............. 315
Anti-Lock Warning Light.................. 207
Anti-Theft Security Alarm (Theft Alarm)........ 26
Appearance Care........................ 428
Arming Theft System (Security Alarm)......... 27
Ashtray............................... 178
Auto Down Power Windows................ 41
Automatic Dimming Mirror................. 90
Automatic Door Locks...................19,20
Automatic Headlights.................... 145
Automatic Temperature Control (ATC)......... 284
Automatic Transaxle...................... 309
482 INDEX

Temperature Gauge..................... 208
Exhaust Gas Caution..............37,83,345,415
Exhaust System......................... 415
Extender, Seat Belt........................ 53
Exterior Folding Mirrors................... 91
Filters
Air Cleaner.......................... 406
Air Conditioning....................296,411
Automatic Transaxle.................... 427
Engine Oil........................405,444
Engine Oil Disposal.................... 405
Flashers
Hazard Warning....................... 366
Turn Signal.....................205,439,441
Flat Tire Stowage........................ 377
Fluid Capacities......................... 443
Fluid Leaks............................. 84Fluid Level Checks
Automatic Transmission................. 426
Brake............................... 423
Power Steering........................ 412
Fluids................................ 444
Fluids, Lubricants and Genuine Parts.......... 444
Fog Light Service........................ 440
Fog Lights..........................146,440
Fold in Floor (Stown Go) Seating........... 123
Freeing A Stuck Vehicle................... 390
Fuel................................. 342
Adding............................. 346
Additives............................ 344
Clean Air............................ 342
Filler Cap (Gas Cap).................... 346
Gasoline............................ 342
Gauge.............................. 204
Hoses.............................. 424
Light............................... 204
INDEX 487
10

Octane Rating......................342,444
Requirements......................342,443
Tank Capacity........................ 443
Fuel System Caution..................... 344
Fueling............................... 346
Fuses................................ 434
Garage Door Opener (HomeLink) ........... 167
Gas Cap (Fuel Filler Cap).................. 346
Gasoline, Clean Air...................... 342
Gasoline (Fuel)......................... 342
Gasoline, Reformulated................... 343
Gauges
Coolant Temperature.................... 208
Fuel................................ 204
Speedometer......................... 205
Tachometer.......................... 207
Gearshift.............................. 311
General Information..................16,25,339Glass Cleaning.......................... 431
Grocery Bag Retainer..................... 136
Gross Axle Weight Rating...............348,351
Gross Vehicle Weight Rating.............348,351
Hands-Free Phone (UConnect™) .............. 94
Hazard Warning Flasher................... 366
Head Phones........................... 264
Head Restraints......................... 119
Headlights............................ 143
Bulb Replacement...................... 438
High Beam/Low Beam Select Switch........ 148
Lights On Reminder.................... 145
Replacing............................ 438
Time Delay.......................... 146
Heated Seats........................... 119
Heater............................... 274
Heater, Engine Block..................... 309
488 INDEX

Lap/Shoulder Belts....................... 43
LATCH (Lower Anchors and Tether for CHildren) . 74
Latches
Hood............................... 141
Lead Free Gasoline...................... 342
Life of Tires............................ 335
Liftgate................................ 34
Lights..............................84,142
Airbag........................59,68,84,206
Alarm.............................. 208
Anti-Lock........................... 207
Automatic Headlights................... 145
Back-Up............................. 441
Battery Saver......................... 145
Brake Warning........................ 205
Bulb Replacement...................437,438
Center Mounted Stop................... 442
Cruise.............................. 211
Dimmer Switch, Headlight............... 144Door Ajar........................... 205
Engine Temperature Warning.............. 208
Fog .............................146,440
Hazard Warning Flasher................. 366
Headlight Switch...................... 143
Headlights........................... 438
Headlights On Reminder................. 145
High Beam Indicator.................... 209
High Beam/Low Beam Select............. 148
Illuminated Entry....................... 16
Interior..........................143,144
License............................. 442
Liftgate Ajar.......................... 205
Lights On Reminder.................... 145
Low Fuel............................ 204
Malfunction Indicator (Check Engine)........ 210
Oil Pressure.......................... 209
Park.............................143,439
Passing............................. 148
490 INDEX
