50/50 Fold & Tumble Rear Seat Removal
1. Lower the head restraint and pull up on release lever
“1” to fold the seatback down. 2. Pull up on release lever “2” and tumble the seat fully
forward.
50/50 Seat Release Lever 1 Location
50/50 Seat Release Lever 2 Location
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141
3

3. Pull the release strap “3” located at the bottom of the
seat to disengage the front attachments.
4. The seat assembly can now be removed from the
vehicle and moved on its Easy Out Rollers. To reinstall the 50/50 rear seat, lower the head restraint to
the full down position, tilt the seat forward and engage
the front floor attachments, then tilt the seat rearward to
engage the rear attachments. Pull the seatback release
lever to return the seatback to its full upright position.
Ensure that the seatback is fully latched in the upright
position.
WARNING!
In a collision, you or others in your vehicle could be
injured if seats are not properly latched to their floor
attachments. Always be sure the seats are fully
latched.
50/50 Seat Release Strap 3 Location
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2 – Passenger and 3 – Passenger Bench Seats
Release levers are located on the rear leg assemblies, near
the floor. To remove the seat, squeeze each release handle
and rotate downwards to deploy the wheels. A lock
indicator button pops up when the seat is unlocked. The
seat assembly can now be removed from the vehicle and
moved on its Easy Out  Rollers.
To reinstall the seat, align the seat into the detent posi-
tions on the floor. Squeeze the release handle and rotate
upward until the lock indicator button returns into the
handle.
Bench Seat Release Levers
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143
3

WARNING!
If not properly latched, the bench seats could be-
come loose. Personal injuries could result. After
reinstalling these seats, be sure the red indicator
button on the release handles return into the
handles.
Plastic Grocery Bag Retainer
Retainer hooks which will hold plastic grocery bag
handles are built into the seatbacks of all rear seats and
some front seats. The floor supports the partial weight of
the bagged goods.
Rear-Most Bench Seat
The seat position can be adjusted fore and aft to any of
three positions - normal (rearward), intermediate, and
full forward. In this way varying needs for legroom and
cargo space behind the seat can be accommodated.
Grocery Bag Holders
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The release lever is below the seat and is accessible from
the front and back of the seat.
Rear Seat Descriptions
7 Passenger Model — 2– passenger bench or bucket seats
in the second position and 3– passenger bench seat or
50/50 bench seat in the third position. All rear seats are
removable.
Rear Bench Seating Flexibility
The 3– passenger bench seat may be adjusted to any of 3
positions on its tracks while installed in the vehicle. The
bench seat may also be moved to the second seating
position or removed from the vehicle.
Release Lever Location
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145
3

1. Normal Seating—
The 2nd and 3rd row seats are installed. The 3rd row
bench seat is in the full rear position on the tracks.
2. Increased Storage—
Increased storage area is provided by adjusting 3rd row
bench seat to the intermediate track position. Rear seat-
ing for 3 passengers (children) is still provided. 3. Additional Storage—
The 2nd and 3rd row seats installed. The 3rd row bench
seat is in the full forward position on the tracks and one
or both of the rear seatbacks are folded down.
4. Auxiliary Seating—
The middle quad seats are removed from the vehicle. The
3– passenger bench seat can be installed in either the
second or third row.
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Rear Quad and 50/50 Seating Flexibility
The seats may be used with either or both seatbacks
folded forward for additional storage space, or with
either or both seats removed from the vehicle. Both 50/50
seats may also be moved to the 2nd row seating position
when the middle quad seats are removed.
1. Normal Seating—
The 2nd and 3rd row seats are installed. Both seatbacks
are in the upright position. 2. Increased Storage—
Increased storage area is provided by folding either or
both seatbacks. With one seatback folded forward, rear
seating for another occupant is still provided. Either or
both seats may Fold and Tumble forward for more
storage space. For maximum storage, remove the head
restraint and place on the seat cushion, then fold the
seatback over the head restraint by lifting lever “1” and
tumble the seat forward by lifting lever “2”.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147
3

NOTE:
Driving with the 2nd-row seats in the tumbled position is
not recommended when passengers occupy the 3rd row
seats. This position is intended only to increase available
cargo area without requiring removal of the seats.
Do not leave the head restraint stored between the
cushions for extended periods of time or inadvertent
damage to the seat cover or head restraint may occur.
3. Additional Storage—
The 2nd row seats are installed in the middle seating
position. Either or both of the rear seats are removed
from the vehicle. 4. Auxiliary Seating—
The 2nd row seats are removed from the vehicle. Then
the third row seats can be installed in either the rear or
middle seat position.
If the seat is not occupied, the seatback can be folded
forward to obtain additional cargo space. To fold the
seatback forward, pull the handle labeled “1” located
behind the seat on the passenger side.
The seatback will latch in the folded position. To assure
the seatback is latched in the folded position, additional
downward pressure on the seatback may be required
when folding.
The same lever is used to return the seatback to the
upright position.
NOTE:
The head restraints are removable, if needed. To
remove them, press the release tab on the right side of the
base of the head restraint.
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
•Not all head restraints in this vehicle are the
same. Head restraints from one seating position
should not be removed and installed in any other
seating position. In a collision, serious injury or
death may result if the proper head restraint is
not installed on each seat.
•The cargo area in the rear of the vehicle should
not be used as a play area by children. They could
be seriously injured in a collision. Children
should be seated and using the proper restraint
system.
•It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision,
people riding in these areas are more likely to be
seriously injured or killed.
•Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
•Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
TO OPEN AND CLOSE THE HOOD
To open the hood, two latches must be released. First pull
the hood release lever located under the left side of the
instrument panel.
Hood Release Lever
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149
3

Next, push to the left the safety catch located under the
front edge of the hood, near the center.
Use the hood prop rod to secure the hood in the open
position.
To prevent possible damage, do not slam the hood to
close it. Lower the hood until it is open approximately 30 cm (12 inches) and then drop it. This should secure both
latches. Never drive your vehicle unless the hood is fully
closed, with both latches engaged.
WARNING!
If the hood is not fully latched, it could fly up when
the vehicle is moving and block your forward vision.
You could have a collision. Be sure all hood latches
are fully latched before driving.
LIGHTS
All of the lights, except the hazard warning lights, are
controlled by switches to the left of the steering column
on the instrument panel.
Hood Safety Catch
