Page 41 of 520
If the liftgate is locked and is not equipped with a
powered liftgate, pressing the button on the remote
keyless entry transmitter will result in the liftgate becom-
ing unlocked for 30 seconds allowing you to manually
access the liftgate area. NOTE:
On vehicles without power locks, the liftgate can
only be opened using the vehicle keys. The key must be
held in the unlocked position for the liftgate to open.
Power Liftgate — If Equipped
The power liftgate may be opened manually or by using
the button on the remote keyless entry transmitter. Press
the button on the remote keyless entry transmitter twice
within five seconds, to open the power liftgate. Once the
liftgate is fully open, pressing the button twice within
five seconds a second time will close the liftgate.
Liftgate Handle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41
2
Page 42 of 520
The power liftgate may also be opened by pressing the
button located on the overhead console.
When the remote keyless entry transmitter button is
pressed and the “Lamp Flash” feature is enabled, the tail
lights will flash to signal that the liftgate is opening or
closing.WARNING!
During power operation, personal injury or cargo
damage may occur. Ensure the liftgate travel path is
clear. Make sure the liftgate is closed and latched
before driving away.
NOTE:
•If anything obstructs the power liftgate while it is
closing or opening, the liftgate will automatically
reverse to the closed or open position, provided it
meets sufficient resistance.
•There are also pinch sensors attached to the side of the
liftgate opening. Light pressure anywhere along these
strips will cause the liftgate to return to the open
position.
Power Liftgate Button
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 43 of 520
•The power liftgate must be in the full open or close
positions for any of the buttons to operate. If the
liftgate is not in the full open or close positions it must
be opened or closed manually.
•If the liftgate release button is activated while the
power liftgate is closing, the liftgate will reverse to the
full open position.
•The power liftgate buttons will not operate if the
vehicle is in gear or the vehicle speed is above 0 mph
(0 km/h).
•The power liftgate will not operate in temperatures
below 12°F( 24° C) or temperatures above 143° F
(62° C). Be sure to remove any build-up of snow or ice
from the liftgate before pressing any of the power
liftgate buttons.
•If the power liftgate encounters multiple obstructions
within the same cycle, the system will automatically
stop and must be opened or closed manually.
WARNING!
•Driving with the liftgate open can allow poison-
ous exhaust gases into your vehicle. You and your
passengers could be injured by these fumes. Keep
the liftgate closed when you are operating the
vehicle.
•If you are required to drive with the liftgate open,
make sure that all windows are closed, and the
climate control blower switch is set at high speed.
DO NOT use the recirculation mode.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43
2
Page 44 of 520
Gas props support the liftgate in the open position.
However, because the gas pressure drops with tempera-
ture, it may be necessary to assist the props when
opening the liftgate in cold weather.
SEAT STORAGE BIN SAFETY WARNING
WARNING!
Always close the storage bin covers when your
vehicle is unattended. Do not allow children to have
access to the 2nd row seat storage bins. Once in the
storage bin, young children may not be able to
escape. If trapped in the storage bin, children can die
from suffocation or heat stroke.
CAUTION!
The storage bin cover must lay flat and latched to
avoid being gouged by the front seat track which has
minimal clearance.
Storage Bin Cover Emergency Release
As a security measure, a Storage Bin Cover Emergency
Release strap is built into the storage bin cover latching
mechanism.
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 45 of 520
NOTE:In the event of an individual being locked inside
the storage bin, the storage bin cover can be opened from
inside of the bin by pulling on the glow-in-the-dark strap
attached to the storage bin cover latching mechanism.
Reinstalling Storage Bin Cover Emergency
Release
If the storage bin cover strap disengages from the latch, it
can be reinstalled by inserting the loose end of the strap
into the latch mechanism.
Storage Bin Cover Emergency Release Strap
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45
2
Page 46 of 520
Push the strap into the latch mechanism until it engages
around the latch post.
NOTE: Do not use the storage bin emergency release to
lift the storage bin cover. The strap is intended for
emergency release only.OCCUPANT RESTRAINTS
Some of the most important safety features in your
vehicle are the restraint systems. These include the front
and rear seat belts for the driver and all passengers, front
airbags for both the driver and front passenger, driver
inflatable knee blocker and if equipped, window bags for
the driver and passengers seated next to a window. If you
will be carrying children too small for adult-size seat
belts, your seat belts or the LATCH feature (Lower
Anchors and Tether for CHildren) also, can be used to
hold infant and child restraint systems.
NOTE: The front airbags have a multi stage inflator
design. This allows the airbag to have different rates of
inflation that are based on collision severity.
Please pay close attention to the information in this
section. It tells you how to use your restraint system
properly to keep you and your passengers as safe as
possible.
Reinstall Cover Strap
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 47 of 520
WARNING!
In a collision, you and your passengers can suffer
much greater injuries if you are not properly buck-
led up. You can strike the interior of your vehicle or
other passengers, or you can be thrown out of the
vehicle. Always be sure you and others in your
vehicle are buckled up properly.
Buckle up even though you are an excellent driver, even
on short trips. Someone on the road may be a poor driver
and cause a collision that includes you. This can happen
far away from home or on your own street.
Research has shown that seat belts save lives, and they
can reduce the seriousness of injuries in a collision. Some of the worst injuries happen when people are thrown
from the vehicle. Seat belts reduce the possibility of
ejection and the risk of injury caused by striking the
inside of the vehicle.
Everyonein a motor vehicle should
be belted at all times.
Lap/Shoulder Belts
All the outboard seats in your vehicle are equipped with
Lap/Shoulder Belts.
The belt webbing retractor is designed to lock during
very sudden stops or collisions. This feature allows the
shoulder part of the belt to move freely with you under
normal conditions. But in a collision, the belt will lock
and reduce the risk of your striking the inside of the
vehicle or being thrown out.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47
2
Page 48 of 520
WARNING!
•It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision,
people riding in these areas are more likely to be
seriously injured or killed.
•Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
belts.
•Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
WARNING!
•Wearing a seat belt incorrectly is dangerous. Seat
belts are designed to go around the large bones of
your body. These are the strongest parts of your
body and can take the forces of a collision the
best.
•Wearing your belt in the wrong place could make
your injuries in a collision much worse. You
might suffer internal injuries, or you could even
slide out of part of the belt. Follow these instruc-
tions to wear your seat belt safely and to keep
your passengers safe, too.
•Two people should never be belted into a single
seat belt. People belted together can crash into one
another in a collision, hurting one another badly.
Never use a lap/shoulder belt or lap belt for more
than one person, no matter what their size.
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 49 of 520
Lap/Shoulder Belt Operating Instructions
1. Enter the vehicle and close the door. Sit back and
adjust the seat.
2. The seat belt latch plate is near the seatback of the
front seats and next to your arm in the rear seats. Grasp
the latch plate and pull out the belt. Slide the latch plate
up the webbing as far as necessary to allow the belt to go
around your lap.
Latch Plate
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49
2
Page 50 of 520
3. When the belt is long enough to fit, insert the latch
plate into the buckle until you hear a “click”.WARNING!
•A belt that is buckled into the wrong buckle will not
protect you properly. The lap portion could ride too
high on your body, possibly causing internal injuries.
Always buckle your belt into the buckle nearest you.
•A belt that is too loose will not protect you as well.
In a sudden stop you could move too far forward,
increasing the possibility of injury. Wear your seat belt
snugly.
•A belt that is worn under your arm is very danger-
ous. Your body could strike the inside surfaces of the
vehicle in a collision, increasing head and neck injury.
A belt worn under the arm can cause internal injuries.
Ribs aren’t as strong as shoulder bones. Wear the belt
over your shoulder so that your strongest bones will
take the force in a collision.
•A shoulder belt placed behind you will not protect
you from injury during a collision. You are more likely
to hit your head in a collision if you do not wear your
shoulder belt. The lap and shoulder belt are meant to
be used together.Latch Plate To Buckle
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
