Page 293 of 529
AUTOSTICK® ........................ .318
▫ Steering Wheel Mounted Paddle Shifters Or
Console Mounted Shifter ................318
SPORT MODE ........................ .321
LAUNCH MODE — IF EQUIPPED ..........322
DRIVING ON SLIPPERY SURFACES .........327
▫ Acceleration ........................ .327
▫ Traction ........................... .327
DRIVING THROUGH WATER .............328
▫ Flowing/Rising Water ..................328
POWER STEERING .....................330
▫ Power Steering Fluid Check ..............331
FUEL SAVER TECHNOLOGY —
IF EQUIPPED ......................... .332
PARKING BRAKE ..................... .332
▫ Manual Transmission — If Equipped ........333
▫ Automatic Transmission — If Equipped ......334
BRAKE SYSTEM ...................... .336
▫ Anti-Lock Brake System (ABS) ............336
ELECTRONIC BRAKE CONTROL SYSTEM . . . .339
▫ Anti-Lock Brake System (ABS) ............339
▫ Traction Control System (TCS) ............340
▫ Brake Assist System (BAS) ...............340
▫ Hill Start Assist (HSA) .................341
▫ Electronic Stability Control (ESC) ..........343
▫ ESC Activation/Malfunction Indicator Light And
ESC OFF Indicator Light ................346
292 STARTING AND OPERATING
Page 333 of 529
WARNING!
Fluid level should be checked on a level surface and
with the engine off to prevent injury from moving
parts and to ensure accurate fluid level reading. Do
not overfill. Use only manufacturer’s recommended
power steering fluid.
If necessary, add fluid to restore to the proper indicated
level. With a clean cloth, wipe any spilled fluid from all
surfaces. Refer to “Fluids, Lubricants, and Genuine
Parts” in “Maintaining Your Vehicle” for further informa-
tion.
FUEL SAVER TECHNOLOGY — IF EQUIPPED
This feature offers improved fuel economy by shutting
off four of the engine’s eight cylinders during light load
and cruise conditions. The system is automatic with no
driver inputs or additional driving skills required. NOTE:
This system may take some time to return to full
functionality after a battery disconnect.
PARKING BRAKE
Before leaving the vehicle, make sure that the parking
brake is fully applied and place the shift lever in the
PARK or REVERSE (manual transmission only) position.
When the parking brake is applied and the ignition
switch is in the ON position (RUN position with Keyless
Enter-N-Go™), the “Brake Warning Light” in the instru-
ment cluster will illuminate.
NOTE:
• When the parking brake is applied and the transmis-
sion is placed in gear, the “Brake Warning Light” will
flash. If vehicle speed is detected, a chime will sound
to alert the driver. Fully release the parking brake
before attempting to move the vehicle.
332 STARTING AND OPERATING
Page 419 of 529
▫Manual Transmission — If Equipped .......446
▫ Automatic Transmission — If Equipped .....446
▫ Rear Axle .......................... .448
▫ Appearance Care And Protection From
Corrosion .......................... .449
FUSES ............................. .455
▫ Integrated Power Module ...............455
▫ Rear Power Distribution Center ...........459
VEHICLE STORAGE ....................464
REPLACEMENT BULBS .................464
BULB REPLACEMENT ..................465
▫ Low Beam Headlamp, High Beam Headlamp,
Park/Turn Lamp — Models with Halogen
Headlamps — If Equipped ...............465 ▫
Low Beam Headlamp, High Beam Headlamp, and
Park/Turn Lamp — Models with High Intensity
Discharge (HID) Headlamps — If Equipped . . .465
▫ Front/Rear Side Marker Lamp ............466
▫ Tail/Turn And Stop Lamp ...............467
▫ Center Tail/Backup Lamp ...............469
▫ Center High-Mounted Stop Lamp (CHMSL) . .469
▫ License Lamp ....................... .469
FLUID CAPACITIES ....................471
FLUIDS, LUBRICANTS AND GENUINE
PARTS ............................. .472
▫ Engine ............................ .472
▫ Chassis ........................... .473
418 MAINTAINING YOUR VEHICLE
Page 447 of 529
Manual Transmission — If Equipped
Fluid Level Check
Check the fluid level by removing the fill plug on the left
side of the transmission. The fluid level should be 1/4
inch (6.4mm) below the bottom of the fill hole. Add fluid,
if necessary, to maintain the proper level. Refer to “Flu-
ids, Lubricants, and Genuine Parts” in “Maintaining Your
Vehicle” for further information.
Change Transmission Fluid
If contaminated with water, change the fluid immedi-
ately. See your authorized dealer for service.
Refer to the “Maintenance Schedule” for the proper
maintenance intervals.
Automatic Transmission — If Equipped
Selection Of Lubricant
It is important to use the proper transmission fluid to
ensure optimum transmission performance and life. Use
only the manufacturer ’s specified transmission fluid.
Refer to “Fluids, Lubricants, and Genuine Parts” in this
section for fluid specifications. It is important to maintain
the transmission fluid at the correct level using the
recommended fluid. No chemical flushes should be used
in any transmission; only the approved lubricant should
be used.
CAUTION!
Using a transmission fluid other than the manufac-
turer ’s recommended fluid may cause deterioration
in transmission shift quality and/or torque converter
(Continued)
446 MAINTAINING YOUR VEHICLE
Page 448 of 529
CAUTION!(Continued)
shudder, and will require more frequent fluid and
filter changes. Refer to “Fluids, Lubricants, and
Genuine Parts” in this section for fluid specifica-
tions.
Special Additives
The manufacturer strongly recommends against using
any special additives in the transmission.
Automatic Transmission Fluid (ATF) is an engineered
product and its performance may be impaired by supple-
mental additives. Therefore, do not add any fluid addi-
tives to the transmission. The only exception to this
policy is the use of special dyes for diagnosing fluid
leaks. Avoid using transmission sealers as they may
adversely affect seals.
CAUTION!
Do not use chemical flushes in your transmission as
the chemicals can damage your transmission compo-
nents. Such damage is not covered by the New
Vehicle Limited Warranty.
Fluid Level Check
The fluid level is preset at the factory and does not
require adjustment under normal operating conditions.
Routine fluid level checks are not required, therefore the
transmission has no dipstick. Your authorized dealer can
check your transmission fluid level using special service
tools.
If you notice fluid leakage or transmission malfunction,
visit your authorized dealer immediately to have the
transmission fluid level checked. Operating the vehicle
with an improper fluid level can cause severe transmis-
sion damage.
7
MAINTAINING YOUR VEHICLE 447
Page 474 of 529
Chassis
ComponentFluid, Lubricant, or Genuine Part
Manual Transmission – If
Equipped We recommend you use MOPAR® ATF+4® Automatic Transmission
Fluid.
Automatic Transmission – If
Equipped Use only ATF+4® Automatic Transmission Fluid.
Failure to use ATF+4® fluid may affect the function or performance of
your transmission. We recommend MOPAR® ATF+4® fluid.
Brake Master Cylinder We recommend you use MOPAR® DOT 3, SAE J1703 should be used. If
DOT 3, SAE J1703 brake fluid is not available, then DOT 4 is acceptable.
Power Steering Reservoir We recommend you use MOPAR® Power Steering Fluid + 4, MOPAR®
ATF+4® Automatic Transmission Fluid.
Rear Axle We recommend you use MOPAR® Synthetic Gear Lubricant SAE 75W90
(API GL-5) or with MOPAR® Friction Modifier — Hypoid Gear Additive.
7
MAINTAINING YOUR VEHICLE 473
Page 484 of 529
54,000 Miles (90,000 km) or
54 Months Maintenance
Service Schedule
❏Change the engine oil and engine oil
filter.
❏ Rotate tires.
❏ Inspect the rear axle fluid.
❏ Inspect the manual transmission
fluid (if equipped), add as necessary.
Odometer Reading Date
Repair Order #Dealer Code
Signature, Authorized Service Center
60,000 Miles (100,000 km) or 60 Months Maintenance Service
Schedule
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Replace the engine air cleaner filter.
❏ Replace the air conditioning filter.
❏ Inspect the brake linings, and replace if necessary.
❏ Adjust parking brake on vehicles equipped with four-wheel disc brakes.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Change the automatic transmission fluid and filter if using your vehicle for any of
the following: police, taxi, fleet, or other severe usage.
❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all
parts for damage, wear, improper looseness or end play; replace if necessary.
Odometer Reading Date
Repair Order #Dealer Code
Signature, Authorized Service Center
8
MAINTENANCE SCHEDULES 483
Page 490 of 529
120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Replace the engine air cleaner filter.
❏ Flush and replace the engine coolant at 120 months or 150,000 miles (240 000 km) whichever comes first.
❏ Inspect the brake linings, and replace if necessary.
❏ Adjust parking brake on vehicles equipped with four-wheel disc brakes.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness
or end play; replace if necessary.
❏ Change the automatic transmission fluid and filter.
❏ Replace the air conditioning filter.
Odometer Reading Date
Repair Order #Dealer Code
Signature, Authorized Service Center
8
MAINTENANCE SCHEDULES 489
Page 508 of 529
Automatic Temperature Control (ATC)..........281
Automatic Transmission ....................310
Adding Fluid ......................... .448
Fluid and Filter Changes ..................448
Fluid Change ......................... .448
Fluid Level Check ...................... .447
Fluid Type ........................... .473
Special Additives ...................... .447
Autostick .............................. .318
Auto Unlock, Doors ........................36
Axle Fluid ............................. .473
Axle Lubrication (Axle Fluid) .................473
Battery ................................ .427
Keyless Transmitter Replacement (RKE) ........28
Location ............................. .427
Belts, Seat ...............................49
Body Mechanism Lubrication .................433
B-Pillar Location ......................... .355Brake Assist System
...................... .340
Brake Control System, Electronic ..............339
Brake Fluid ............................ .473
Brake, Parking .......................... .332
Brakes ................................ .336
Brake System ........................... .336
Anti-Lock (ABS) ....................... .336
Fluid Check .......................... .444
Master Cylinder ....................... .444
Parking ............................. .332
Warning Light ........................ .218
Brake/Transmission Interlock .................310
Break-In Recommendations, New Vehicle .........96
Brightness, Interior Lights ...................167
Bulb Replacement ........................ .464
Bulbs, Light ............................ .101
Calibration, Compass ..................... .238
Capacities, Fluid ......................... .471
10
INDEX 507
Page 512 of 529
Fuel Requirements..................... .379
Jump Starting ......................... .405
Oil................................. .424
Oil Change Interval ..................... .425
Oil Filler Cap ......................... .425
Oil Selection .......................... .425
Oil Synthetic ......................... .426
Overheating .......................... .392
Starting ............................. .295
Temperature Gauge ..................... .213
Engine Oil Viscosity ...................... .425
Enhanced Accident Response Feature ............69
Entry System, Illuminated ....................22
Ethanol ............................... .380
Event Data Recorder ........................73
Exhaust Gas Caution ........................98
Exhaust System ...........................98
Exterior Folding Mirrors ....................109
Exterior Lighting ......................... .161Exterior Lights
.......................... .101
Filler Location Fuel ....................... .383
Filters Air Cleaner .......................... .426
Air Conditioning ...................... .288
Engine Oil ........................... .426
Engine Oil Disposal .....................426
Flashers Hazard Warning ....................... .392
Turn Signal .......................... .101
Flash-To-Pass ........................... .166
Flooded Engine Starting ....................301
Fluid, Brake ............................ .473
Fluid Capacities ......................... .471
Fluid Leaks ............................ .101
Fluid Level Checks Automatic Transmission ..................447
Brake ............................... .444
10
INDEX 511
