hood release DODGE CHARGER SRT 2007 6.G Owners Manual

TO OPEN AND CLOSE THE HOOD
Two latches must be released to open the hood. First, pull
the hood release lever located under the left side of the
instrument panel.
Next, move to the outside of the vehicle and push the
safety catch to the left. The safety catch is located under
the center front edge of the hood.Use the hood prop rod (if equipped) to secure the hood in
the open position.
To prevent possible damage, do not slam the hood to
close it. Lower the hood until it is open approximately 6
inches (15 cm), and then drop it. This should secure both
latches. Never drive your vehicle unless the hood is fully
closed, with both latches engaged.
Hood Release Lever
Hood Safety Catch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89
3

INSTRUMENT PANEL AND CONTROLS
1 Ð Air Outlet 6 Ð Radio 11 Ð Ignition Switch
2 Ð Instrument Cluster 7 Ð Climate Control 12 Ð Hood Release
3 Ð Hazard Switch 8 Ð Heated Seat Switch* 13 Ð Trunk Release Switch
4 Ð Electronic Stability Program Off Button*
/ Traction Control System Off Button*9 Ð Power Outlet 14 Ð Headlight Switch
5 Ð Glove Box 10 Ð Ash Tray* * If Equipped 122 UNDERSTANDING YOUR INSTRUMENT PANEL

seconds with the accelerator pedal pushed all the way to
the floor. Release the accelerator pedal and the key once
the engine is running smoothly. Do not overspeed the
engine.
If the engine shows no sign of starting after two 15-
second periods of cranking with the accelerator pedal
held to the floor, the ªNORMAL STARTINGº procedure
should be repeated.
After Starting
The idle speed is controlled automatically and it will
decrease as the engine warms up.
ENGINE BLOCK HEATER Ð IF EQUIPPED
The engine block heater warms engine coolant and
permits quicker starts in cold weather. Connect the cord
to a standard 110-115 volt AC electrical outlet with a
grounded, three-wire extension cord.
The engine block heater cord is routed under the hood on
the driver side of the vehicle. It has a removable cap that
is located on the driver side of the Integrated Power
Module.
WARNING!
Remember to disconnect the cord before driving.
Damage to the 110-115 volt electrical cord could
cause electrocution.
192 STARTING AND OPERATING

Refer to the ªMaintenance Scheduleº in this manual for
the recommended air conditioning filter replacement
intervals.
Power Steering Ð Fluid Check
Checking the power steering fluid level at a defined
service interval is not required. The fluid should only be
checked if a leak is suspected, abnormal noises are
apparent, and/or the system is not functioning as antici-
pated. Coordinate inspection efforts through a certified
DaimlerChrysler Dealership.
WARNING!
Fluid level should be checked on a level surface and
with the engine off to prevent injury from moving
parts and to insure accurate fluid level reading. Do
not overfill. Use only manufacturer's recommended
power steering fluid.
If necessary, add fluid to restore to the proper indicated
level. With a clean cloth, wipe any spilled fluid from allsurfaces. Refer to ªFluids, Lubricants, and Genuine
Partsº in this section for the correct fluid type.
Front & Rear Suspension Ball Joints
The suspension ball joints should be inspected for exter-
nal leakage or damage when other maintenance is per-
formed.
Steering Linkage
The tie rod end ball joints should be inspected for
external leakage or damage when other maintenance is
performed.
Body Lubrication
Locks and all body pivot points, including seat tracks,
door hinges, trunk hinges, and hood hinges, should be
lubricated periodically to assure quiet, easy operation
and to protect against rust and wear. Prior to the appli-
cation of any lubricant, the parts concerned should be
wiped clean to remove dust and grit; after lubricating
excess oil and grease should be removed. Particular
attention should also be given to hood latching compo-
nents to insure proper function. When performing other
underhood services, the hood latch, release mechanism,
and safety catch should be cleaned and lubricated.
276 MAINTAINING YOUR VEHICLE

Gas Cap (Fuel Filler Cap)..............240,264
Gasoline, Clean Air..................... 238
Gasoline (Fuel)........................ 237
Gasoline, Reformulated.................. 238
Gauges
Coolant Temperature.................. 125
Fuel............................... 124
Speedometer......................... 124
Tachometer.......................... 124
General Information.................14,20,237
Glass Cleaning......................... 290
Gross Axle Weight Rating................. 244
Gross Vehicle Weight Rating............... 244
GVWR............................... 244
Hands-Free Phone (UConnectŸ)............ 65
Hazard Warning Flasher.................. 248
Head Restraints......................... 86
Headlights
Cleaning............................ 290
High Beam........................... 93
High Beam/Low Beam Select Switch....... 93
Lights On Reminder.................... 92On With Wipers.....................91,97
Passing............................. 93
Switch.............................. 90
Time Delay........................... 91
Heated Seats........................... 86
Heater............................... 175
Heater, Engine Block.................... 192
High Beam/Low Beam Select (Dimmer) Switch . 93
Holder, Cup........................... 114
HomeLinkt(Garage Door Opener) Transmitter . 104
Hood Release.......................... 89
Hoses............................... 283
Ignition............................... 11
Key ................................ 11
Ignition Key Removal.................... 11
Illuminated Entry....................... 16
Immobilizer (Sentry Key).................. 12
Infant Restraint.......................46,47
Inflation Pressure Tires................... 129
Information Center, Vehicle............... 132
Inside Rearview Mirror................... 62
Instrument Cluster...................123,124
INDEX 341
