DODGE CHARGER SRT 2016 7.G Owners Manual

Engine/
Transmis- sion Red Key/
700+ HP Black Key/
500 HP Transmis-
sion Paddle
Shifters Suspen-
sion Steering Traction
6.2L XXXXXN /AX
6.4L N/A N/A XXXX X
The SRT Drive Modes main screen displays the current
drive mode and real-time status of the vehicle’s perfor-
mance configuration. The selectable Drive Modes buttons
are Track, Sport, Custom, or Default and will be high-
lighted when displaying the current configuration. Infor-
mation shown below each drive mode button will indi-
cate the actual status of each system, along with a graphic
that displays the status of the vehicle’s components. The
color red indicates “Track,” orange “Sport,” and yellow
“Street.” If the system status shown does not match the current drive mode set up, a message will be displayed
indicating which values are not matching the current
mode and why.
NOTE:
ESC Full-Off can be activated across all of the
Drive Mode features by pushing and holding the ESC Off
button on the instrument panel switch bank for five
seconds.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 339

Listed below are the available Drive Modes:
Track Mode
Pressing the “Track” button on the touchscreen will
activate the configuration for typical track driving. TheTransmission, Traction, Steering, and Suspension systems
are all set to their “Track” settings highlighted in red. The
Paddle Shifters are enabled.
Drive Modes (Track)
340 UNDERSTANDING YOUR INSTRUMENT PANEL

Sport Mode
Pressing the “Sport” button on the touchscreen will
activate the configuration for typical enthusiast driving.The Traction, Transmission, Steering, and Suspension
systems are all set to their “Sport” settings highlighted in
orange. The Paddle Shifters are enabled.
Drive Modes (Sport)
4
UNDERSTANDING YOUR INSTRUMENT PANEL 341

Default Mode
The vehicle will start in Default Mode unless Valet or
ECO mode (if equipped) is active. This mode is for
typical driving conditions where the Traction and Trans-
mission will be operating in their Street settings, whichcannot be changed while in this mode. The Steering and
Suspension can be configured in either the “Street,”
“Sport,” or “Track” modes and the Paddle Shifters may
be enabled or disabled while in this mode.
Drive Modes (Default)
342 UNDERSTANDING YOUR INSTRUMENT PANEL

Custom Mode
The Custom Mode may be selected quickly by pushing
the SRT button on the instrument panel switch bank two
times, or pressing the “Custom” button on the touch-
screen. Custom Mode allows the you to create a customconfiguration that is saved for quick selection of your
favorite settings. While in Custom Mode, the Power,
Traction, Transmission, Steering, Suspension, and Paddle
Shifter settings are shown in their current configuration.
While in the Custom Drive Mode screen, press the
“Custom Set-Up” button on the touchscreen to access the
Custom Mode
Custom Mode Set-Up — 6.2L Example
4
UNDERSTANDING YOUR INSTRUMENT PANEL 343

selectable options. In the Custom Mode Set-Up screen the
individual current configuration will be displayed. Select
which mode suits your driving needs for a custom
driving experience.
Custom Mode Set-Up Info
Within the Custom Mode Set-Up screen, press the “info”
button on the touchscreen then use the left / right arrows
to scroll through all the available Drive Mode systems
giving you a description of their operation and current
configuration.Power — If Equipped With 6.2L Supercharged Engine
•
700+
Press the “700+” button on the touchscreen to modify the
output power of the engine to 700+.
Power — 6.2L Supercharged Engine Only
344 UNDERSTANDING YOUR INSTRUMENT PANEL

NOTE:This selection is only available with the RED RKE
Key Fob.
• 500
Press the “500” button on the touchscreen to modify the
output power of the engine to 500.
NOTE: This selection is available with the RED or
BLACK RKE Key Fob and will limit the transmission to
the “Street” setting but Eco and Valet modes are still
available.Transmission — If Equipped With 8 Speed Transmission
• Track
Press the “Track” button on the touchscreen to provide
the fastest shift speeds and will have the highest comfort
trade-off.
Transmission
4
UNDERSTANDING YOUR INSTRUMENT PANEL 345

•Sport
Press the “Sport” button on the touchscreen to provide
faster shift speeds and will have a moderate comfort
trade-off.
• Street
Press the “Street” button on the touchscreen to provide a
balance of shift speed and comfort for typical daily
driving. Paddle Shifters
•
ON
Press the “ON” button on the touchscreen to enable
steering wheel paddle shifters.
Paddle Shifters
346 UNDERSTANDING YOUR INSTRUMENT PANEL

•OFF
Press the “OFF” button on the touchscreen to disable
steering wheel paddle shifters. Traction
•
Track
Press the “Track” button on the touchscreen to modify
traction control to optimize track performance with the
least stability control.
Traction
4
UNDERSTANDING YOUR INSTRUMENT PANEL 347

•Sport
Press the “Sport” button on the touchscreen to turn off
traction control and reduce stability control.
• Street
Press the “Street” button on the touchscreen to provide
full traction control and full stability control. Suspension
•
Track
Press the “Track” button on the touchscreen to provide
the firmest possible suspension stiffness with the highest
amount of comfort trade-off.
Suspension
348 UNDERSTANDING YOUR INSTRUMENT PANEL
