INSTRUMENT PANEL AND CONTROLS
CONTENTS

Instruments And Controls.................134

Instrument Cluster......................135

Instrument Cluster Description.............136

Electronic Digital Clock..................143
▫Clock Setting Procedure.................144

Radio General Information................144
▫Radio Broadcast Signals.................144
▫Two Types Of Signals..................144
▫Electrical Disturbances..................145▫AM Reception.......................145
▫FM Reception........................145

Sales Code REF — AM/FM/CD (Single Disc)
Radio With Optional Satellite Radio And Hands
Free Phone Capability...................146
▫Operating Instructions - Radio Mode.......146
▫Operation Instructions - CD Mode.........150
▫Operation Instructions - Auxiliary Mode.....152
▫Operating Instructions - Hands Free Phone —
If Equipped.........................1534

▫Operating Instructions - Satellite Radio — If
Equipped...........................153

Sales Code RAQ – AM/FM/CD (6-Disc) Radio
With Optional Satellite Radio, Hands Free Phone,
And Vehicle Entertainment Systems (VES)
Capabilities...........................154
▫Operating Instructions - Radio Mode.......154
▫Operation Instructions - (CD Mode For CD
Audio Play).........................159
▫Load/Eject Button (CD Mode For CD
Audio Play).........................161
▫Notes On Playing MP3 Files.............163
▫Operation Instructions - (CD Mode For MP3
Audio Play).........................165
▫Load/Eject Button (CD Mode For MP3 Play) . . 165
Satellite Radio — If Equipped..............167
▫System Activation.....................168
▫Electronic Serial Number/Sirius Identification
Number (ESN/SID)....................168
▫Selecting Satellite Mode In REF, RAQ, And RAK
Radios.............................169
▫Selecting a Channel....................170
▫Storing And Selecting Pre-Set Channels......170
▫Using The PTY (Program Type) Button (If
Equipped)..........................170
▫PTY ButtonScan.....................170
▫PTY ButtonSeek.....................171
▫Satellite Antenna......................171
▫Reception Quality.....................171
132 INSTRUMENT PANEL AND CONTROLS

Remote Sound System Controls — If Equipped . . 172
▫Radio Operation......................172
▫CD Player..........................173

Compact Disc Maintenance................173

Sound Box Operation....................174
Radio Operation And Cellular Phones........175

Climate Controls.......................175
▫Air Conditioning And Heater.............175
▫Operating Tips.......................178
▫Operation Tips Chart...................181
INSTRUMENT PANEL AND CONTROLS 133
4

INSTRUMENTS AND CONTROLS
134 INSTRUMENT PANEL AND CONTROLS

INSTRUMENT CLUSTER
INSTRUMENT PANEL AND CONTROLS 135
4

INSTRUMENT CLUSTER DESCRIPTION
1. Fuel Gauge
The fuel gauge shows level of fuel in tank when
ignition switch is in the ON position.
2. Temperature Gauge
The temperature gauge indicates engine coolant
temperature. Any reading within the normal
range indicates that the cooling system is operat-
ing satisfactorily. The gauge needle will likely indicate a
higher temperature when driving in hot weather, up
mountain grades, in heavy traffic, or when towing a
trailer. If the needle rises to the “H” mark, stop the
vehicle, shift into N (Neutral), and increase engine speed
for 2-3 minutes. If the temperature reading does not
return to normal, seek authorized service immediately.
CAUTION!
Do not leave your vehicle unattended with the
engine running as you would not be able to react to
the temperature indicator if the engine overheats.
The gauge pointer will remain near its last reading when
the engine is turned off. It will return to a true reading
when the engine is restarted.
3. Turn Signal Indicators
When a turn signal is activated, a right-pointing or
left-pointing arrow lights up and flashes to indicate the
direction of the turn. These indicators also indicate
proper operation of the front and rear turn signal lights.
If either indicator flashes at a faster rate than normal,
check for a defective bulb. If either indicator fails to light
up when the lever is moved, check for a defective fuse or
turn signal LED. A single chime is activated when the
136 INSTRUMENT PANEL AND CONTROLS

left/right turn signal is left on with the engine RPM
vehicle speed greater than 15 mph (24 km/h) for more
than one mile.
4. Low Fuel Warning Light
This indicator lights when the fuel gauge reads 1/8
of a tank or less. There is a pointer on the side of
this symbol that indicates the side that your fuel
filler door is located.
5. High Beam Indicator
Indicates that headlights are on high beam.
6. Seat Belt Reminder Light
This light comes on for several seconds after the
ignition is turned ON as a reminder to “buckle
up.” This light will remain on as long as the seat
belt remains unbuckled. If this light flashes, it indicates a
fault in the airbag system. Have the system checked by
an authorized dealer.7. Fog Light Indicator — If Equipped
This light shows when the fog lights are ON.
8. Coolant Temperature Light
This light warns of an overheated engine condi-
tion. For a bulb check, this light will come on
momentarily when the ignition is turned On. If the
light turns on while driving, stop the vehicle, shift into N
(Neutral) and increase the engine speed for 2 to 3
minutes. If the temperature reading does not return to
normal, seek authorized service immediately.
INSTRUMENT PANEL AND CONTROLS 137
4

CAUTION!
Driving with a hot engine cooling system could
damage your vehicle. If the temperature light is on,
safely pull over and stop the vehicle. Idle the vehicle
in neutral with the air conditioner turned off until
the light turns off. If the if the light remains on, turn
the engine off immediately, and call for service.
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, see Section 7 of this manual. Follow
the warnings under the Cooling System Pressure
Cap paragraph.
9. Speedometer
Shows the vehicles speed.
10. Voltage Light
This light monitors the electrical system voltage.
The light should turn on momentarily as the
engine is started. If the light stays on or turns on while
driving, it indicates a problem with the charging system.
Immediate service should be obtained.
138 INSTRUMENT PANEL AND CONTROLS

11. Security Light
This light will flash rapidly for approximately 15 seconds
when the vehicle theft alarm is arming. The light will
flash at a slower speed continuously after the alarm is set.
The security light will also come on for about three
seconds when the ignition is first turned on.
12. ABS Warning Light
This light monitors the Anti-Lock Brake System
which is described elsewhere in this manual.
This light will come on when the ignition key is
turned to the ON position and may stay on for
approximately 3 seconds. If this light remains on or
comes on during driving, it indicates that the Anti-Lock
portion of the brake system is not functioning and that
service is required. See your authorized dealer immedi-
ately.13. Engine Oil Pressure Indicator Light
This light indicates that the engine oil pressure has
become too low. For a bulb check, this light will
come on momentarily when the ignition is turned On. If
the light turns on while driving, stop the vehicle and shut
off the engine as soon as possible. Immediate service
should be obtained.
14. Tachometer
This gauge measures engine revolutions-per-minute
(rpm x 1000).
15. Gear Selector
The electronic gear selector display is self-contained
within the instrument cluster. It displays the position of
the automatic transmission shift lever, and the relation of
each position to all other positions. For a good signal the
display will place a box around the selected transmission
INSTRUMENT PANEL AND CONTROLS 139
4

range (PRND21). If the PRNDL displays only the char-
acters PRND21 (no boxes), have the system checked by
an authorized dealer.
16. Trip Odometer
The trip odometer shows individual trip mileage. To
toggle between the odometer and the trip odometer,
press the Odometer/Trip Odometer Button. To reset the
Trip Odometer, press and hold the button while in trip
mode, until the Trip Odometer resets.
Also the cluster will display, replacing the odometer,
vehicle warning messages such as: door ajar, low wash,
No-fuse, and the outside temperature on vehicles that are
not equipped with the Overhead Console with
Compass/Temperature Mini-Trip Computer. For addi-
tional information, refer to “Compass/Temperature
Mini-Trip Computer” in section 3.
If the vehicle diagnostic system determines that the fuel
filler cap is loose, improperly installed, or damaged,GASCAP will be displayed in the instrument cluster.
Tighten the fuel filler cap properly and press the odom-
eter reset button to turn the GASCAP message off. If the
problem continues, the message will appear the next time
the vehicle is started.
17. Odometer
The odometer shows the total distance the vehicle has
been driven.
U.S. federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser the
correct mileage that the vehicle has been driven. There-
fore, if the odometer reading is changed during repair or
replacement, be sure to keep a record of the reading
before and after the service so that the correct mileage can
be determined.
