DODGE DAKOTA 2008 3.G Owners Manual

CavityCartridge
FuseMini
FuseDescription
39 30 Amp
PinkStarter Solenoid
40 Spare
41 30 Amp
PinkWiper Motor
42 25 Amp
NaturalFront Control Module
(FCM) 5 (T-Case)
43 10 Amp
RedLt Park Lamps
44 10 Amp
RedRt Park Lamps
45 20 Amp
YellowTrailer Tow Park
Lamps
46 10 Amp
RedAirbag System # 2CavityCartridge
FuseMini
FuseDescription
47 40 Amp
GreenIgnition Run/
Accessory (Acc)
48 20 Amp
BlueSunroof/Sound Box
49 30 Amp
PinkTrailer Tow B+
50 40 Amp
GreenAnti-Lock Brake Sys-
tem (ABS) Module
(Pump)
51 40 Amp
GreenPark Lamps
52 Spare
53 40 Amp
GreenRear Defogger
54 Spare
MAINTAINING YOUR VEHICLE 371
7

CavityCartridge
FuseMini
FuseDescription
55 10 Amp
RedCabin Compartment
Node (CCN) Acces-
sory (ACC) Feed
56 10 Amp
RedHeated Seats
57 20 Amp
YellowAirbag System # 2
58 20 Amp
YellowHeated Seats
59 10 Amp
RedHVAC Module
60 10 Amp
RedABS Module
61 20 Amp
YellowFront Control Module
(FCM) 3 (Reverse
Lamps)CAUTION!
When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a
properly rated fuse continues to blow, it suggests a
problem in the circuit that must be corrected.
NOTE:If you are leaving your vehicle dormant for
longer than 21 days you may want to take steps to protect
your battery. You may do this by disconnecting the
battery or by disconnecting the two ignition-off draw
(I.O.D.) fuses located in the Auxiliary Power Distribution
Center (PDC) located in the engine compartment. The
I.O.D. cavities include a snap-in retainer that allows the
372 MAINTAINING YOUR VEHICLE

fuse to be disconnected, without removing it from the
fuse block. Pressing the I.O.D. fuse back into the cavity
reconnects it.
VEHICLE STORAGE
If you are storing your vehicle for more than 21 days, we
recommend that you take the following steps to mini-
mize the drain on your vehicle's battery:
²Disconnect the Ignition-Off Draw fuse (I.O.D.) fuse
located in the Power Distribution Center (PDC). The
I.O.D. cavity includes a snap-in retainer that allows the
fuse to be disconnected, without removing it from the
fuse block.
²The transfer case should be placed in the 4HI mode
and kept in this position to minimize the battery drain.
²As an alternative to the above steps you may discon-
nect the negative cable from the battery.
REPLACEMENT LIGHT BULBS
LIGHT BULBS Ð Interior Bulb No.
Dome Light........................WL212±2
Cargo Light............................ 921
Overhead Console Lights................... 192
Reading Light.......................WL212±2
LIGHT BULBS Ð Outside Bulb No.
Headlight............................. H13
Front Park/Turn/Sidemarker.............3157NA
Back-Up..............................3157
Center High Mounted Stoplight.............. 921
Fog Lamp.............................9145
License Plate Light....................... 168
Rear Tail, Stop, Turn Signal.................3057
MAINTAINING YOUR VEHICLE 373
7

BULB REPLACEMENT
Headlight (Halogen)/Front Park and Turn Lights
CAUTION!
This is a halogen bulb. Avoid touching the glass with
your fingers. Reduced bulb life will result.
1. Open the hood
2. Remove the three (3) bolts from the front of the
headlight housing.
3. Grasp the headlight and pull firmly to disengage the
headlight housing from the fender panel.
374 MAINTAINING YOUR VEHICLE

4. While firmly holding the headlight housing in your
hands unlock and disconnect headlight bulb connector.
5. Twist 1/4 turn and remove headlight bulb from hous-
ing and replace.NOTE:It is not necessary to disconnect the connector to
replace the park/turn signal bulb. If the bulb socket
needs replacement disconnect the connector.
NOTE:The headlight bulb is a Halogen bulb. Take care
not to touch the bulb with your fingers. Body oils from
your fingers could cause excessive heat buildup which
reduces bulb life.
To remove the park/turn signal bulb, rotate bulb socket
1/4 turn and remove socket from housing. Pull bulb
straight from socket.
Unlocking Headlight Connector
MAINTAINING YOUR VEHICLE 375
7

Removing Park/Turn Signal BulbDisconnecting Park/Turn Signal Connector
376 MAINTAINING YOUR VEHICLE

Rear Side Marker, Taillamps/Stoplamp, and Turn
Signal Bulbs Ð Replacement
1. Remove the two (2) screws that pass through the bed
sheetmetal.
2. Pull the taillamp housing straight out from the body.
Removing the Two (2) Screws
Pulling Housing From Body
MAINTAINING YOUR VEHICLE 377
7

3. Rotate the bulb socket counterclockwise to from the
housing.4. Pull bulb straight out of socket.
Rotating Bulb Socket From Housing
Pulling Bulb From Socket
378 MAINTAINING YOUR VEHICLE

5. Reverse Procedure to install bulb and housing. Place
the two raised blocks passed the body.Center High-Mounted Stoplamp And Cargo Lamp
1. Remove the two (2) screws holding the housing/lens
to the body as shown.
Sliding Raised Blocks Past Body
Removing Screws
MAINTAINING YOUR VEHICLE 379
7

2. Remove housing from Cab 3. Remove connector from housing tab for more clear-
ance.
Removing Housing from Cab
Removing Connector from Tab
