fuel filter DODGE DART 2014 PF / 1.G Owners Manual

E-85 Usage In Non-Flex Fuel Vehicles
Non-Flex Fuel (FFV) vehicles are compatible with gaso-
line containing 10% ethanol (E10). Gasoline with higher
ethanol content may void the vehicle’s warranty.
If a Non-FFV vehicle is inadvertently fueled with E-85
fuel, the engine will have some or all of these symptoms:
•Operate in a lean mode
• OBD II “Malfunction Indicator Light” on
• Poor engine performance
• Poor cold start and cold driveability
• Increased risk for fuel system component corrosion To fix a Non-FFV vehicle inadvertently fueled once with
E-85 perform the following:
•
Change the engine oil and oil filter
• Disconnect and reconnect the battery
• Drain the fuel tank (see your authorized dealer)
More extensive repairs will be required for prolonged
exposure to E-85 fuel.
MMT In Gasoline
Methylcyclopentadienyl Manganese Tricarbonyl (MMT)
is a manganese-containing metallic additive that is
blended into some gasoline to increase octane. Gasoline
blended with MMT provides no performance advantage
beyond gasoline of the same octane number without
MMT. Gasoline blended with MMT reduces spark plug
life and reduces emissions system performance in some
494 STARTING AND OPERATING

MAINTAINING YOUR VEHICLE
CONTENTS
ENGINE COMPARTMENT — 1.4L TURBO . . . .557
 ENGINE COMPARTMENT — 2.0L ..........558
 ENGINE COMPARTMENT — 2.4L ..........559
 ONBOARD DIAGNOSTIC SYSTEM — OBD II . .560
▫ Loose Fuel Filler Cap Message ............560
 EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS ..........................561
 REPLACEMENT PARTS ..................562
 DEALER SERVICE ..................... .563
 MAINTENANCE PROCEDURES ...........563▫
Engine Oil ..........................564
▫ Engine Oil Filter ..................... .567
▫ Engine Air Cleaner Filter ................567
▫ Tires ..............................568
▫ Maintenance-Free Battery ...............568
▫ Air Conditioner Maintenance .............569
▫ A/C Air Filter .......................571
▫ Body Lubrication .....................574
▫ Windshield Wiper Blades ...............574
▫ Adding Washer Fluid ..................575
7

FLUID CAPACITIES
U.S.Metric
Fuel (Approximate)
Fuel (1.4L Engines) 13.2 Gallons50 Liters
Fuel (2.0L/2.4L Engines) 14.2 Gallons54 Liters
Fuel (2.4L GT models only) 15.8 Gallons60 Liters
Engine Oil With Filter
1.4L Turbo Engine (SAE 5W-40 Synthetic, API Certified) 4 Quarts3.8 Liters
2.0L Engine (SAE 0W-20, API Certified) 5 Quarts4.7 Liters
2.4L Engine (SAE 0W-20, API Certified) 5.5 Quarts5.2 Liters
Cooling System*
1.4L Turbo Engine (MOPAR® OAT Antifreeze/Engine
Coolant 10 Year/150,000 Mile Formula or equivalent) 7.2 Quarts
6.8 Liters
2.0L and 2.4L Engine (MOPAR® OAT Antifreeze/Engine
Coolant 10 Year/150,000 Mile Formula or equivalent) 7.2 Quarts
6.8 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
608 MAINTAINING YOUR VEHICLE

ComponentFluid, Lubricant, or Genuine Part
Engine Oil Filter We recommend you use MOPAR® Engine Oil Filter or equivalent.
Spark Plugs – 1.4L Turbo Engine We recommend you use MOPAR® Spark Plugs (Gap 0.026 in [0.65 mm]).
Spark Plugs – 2.0L Engine We recommend you use MOPAR® Spark Plugs (Gap 0.043 in [1.1 mm]).
Spark Plugs – 2.4L Engine We recommend you use MOPAR® Spark Plugs (Gap 0.047 in [1.2 mm]).
Fuel Selection – 1.4L Turbo Engine 91 Octane Recommended – 87 Octane Acceptable.
Fuel Selection – 2.0L and
2.4L Engine 87 Octane.
610 MAINTAINING YOUR VEHICLE

Uconnect® Settings........................25
ABS (Anti-Lock Brake System) ................446
Adding Engine Coolant (Antifreeze) ............580
Adding Fuel ............................ .497
Adding Washer Fluid ..................... .575
Additives, Fuel .......................... .495
Airbag ..................................61
Airbag Deployment ........................80
Airbag Light .............................68
Airbag Maintenance ........................82
Airbag, Side ..............................65
Airbag, Window (Side Curtain) ................65
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . .567
Air Conditioner Maintenance .................569
Air Conditioning ..........................390
Air Conditioning Controls ...................390
Air Conditioning Filter .....................404
Air Conditioning Refrigerant .................569
Air Conditioning System ....................390 Air Pressure, Tires
........................ .470
Alarm Arm The System ........................20
Disarm The System .......................21
Rearming The System .....................20
Tamper Alert ...........................22
Vehicle Security Alarm ....................20
Alarm Light ............................ .316
Alarm, Panic .............................23
Alarm (Security Alarm) ......................20
Alarm System (Security Alarm) ................20
Alterations/Modifications, Vehicle ...............7
Antifreeze (Engine Coolant) ..................579
Capacities ............................608
Disposal ............................. .582
Anti-Lock Brake System (ABS) ................446
Anti-Lock Warning Light ....................318
Appearance Care ........................ .589
Assistance Towing ........................ .147
632 INDEX

Hazard Warning Flasher..................519
Jacking ...............................532
Jump Starting ..........................543
Overheating .......................... .519
Towing ............................. .551
Emergency Trunk Release ....................47
Emission Control System Maintenance ..........561
Engine .................................558
Air Cleaner .......................... .567
Block Heater ..........................414
Break-In Recommendations ................106
Checking Oil Level ..................... .564
Compartment ..........................557
Cooling ............................. .578
Exhaust Gas Caution .....................108
Fuel Requirements ..................... .492
Jump Starting ..........................543
Oil..................................564
Oil Filler Cap ..........................558 Oil Selection
.......................... .565
Overheating .......................... .519
Temperature Gauge ..................... .310
Enhanced Accident Response Feature ............80
Entry System, Illuminated ....................23
Ethanol ............................... .493
Event Data Recorder ........................83
Exhaust Gas Caution .......................108
Exhaust System .......................... .108
Exterior Folding Mirrors ....................121
Exterior Lighting ..........................235
Exterior Lights ...........................111
Filler Location Fuel ........................316
Filters Air Cleaner .......................... .567
Air Conditioning .......................404
Automatic Transmission ..................588
Engine Oil ............................567
10
INDEX 637

Monitor, Tire Pressure System................483
Mopar Parts ............................ .562
MTBE/ETBE ............................493
Multi-Function Control Lever .................240
New Vehicle Break-In Period .................106
Occupant Restraints ........................47
Occupant Restraints (Sedan) ..................65
Octane Rating, Gasoline (Fuel) ................492
Odometer ...............................316
Oil Change Indicator .......................317
Oil Change Indicator, Reset ..................317
Oil, Engine ............................. .564
Capacity ............................ .608
Change Interval ........................565
Checking ............................ .564
Disposal ............................. .567
Filter ............................... .567Filter Disposal
........................ .567
Materials Added to ..................... .566
Recommendation .......................565
Viscosity ............................ .566
Oil Filter, Selection ........................567
Onboard Diagnostic System ..................560
Opener, Garage Door (HomeLink®) ............274
Operating Precautions ..................... .560
Operator Manual (Owner’s Manual) .............4
Outside Rearview Mirrors ...................120
Overhead Console ........................ .272
Overheating, Engine .......................310
Owner’s Manual (Operator Manual) .............4
Paint Care ............................. .589
Panic Alarm ..............................23
Parking Brake ............................442
Parking On Hill ..........................442
ParkSense® System, Rear ....................257
644 INDEX
