Turn Signals
Move the multifunction lever up or down and the arrows
on each side of the instrument cluster flash to show
proper operation of the front and rear turn signal lights.
NOTE:
•If either light remains on and does not flash, or there is
a very fast flash rate, check for a defective outside light
bulb. If an indicator fails to light when the lever is
moved, it would suggest that the indicator bulb is
defective.
• A “Turn Signal On” message will appear in the EVIC
(if equipped) and a continuous chime will sound if the
vehicle is driven more than 1 mile (1.6 km) with either
turn signal on.
Lane Change Assist
Tap the lever up or down once, without moving beyond
the detent, and the turn signal (right or left) will flash
three times then automatically turn off.
High/Low Beam Switch
Push the multifunction lever away from you to switch
the headlights to high beam. Pull the multifunction lever
toward you to switch the headlights back to low beam.
Flash-To-Pass
You can signal another vehicle with your headlights by
lightly pulling the multifunction lever toward you. This
will turn on the high beams headlights until the lever is
released.
NOTE: If the flash to pass is held for 20 seconds the
feature will deactivate.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 241

6. Front Fog Light Indicator — If EquippedThis indicator will illuminate when the front
fog lights are on.
7. Engine Temperature Warning Light This light warns of an overheated engine condi-
tion. If the engine coolant temperature is too high,
this indicator will illuminate and a single chime will
sound.
If the light turns on while driving, safely pull over and
stop the vehicle. If the A/C system is on, turn it off. Also,
shift the transmission into NEUTRAL and idle the ve-
hicle. If the temperature reading does not return to
normal, turn the engine off immediately and call for
service. Refer to “If Your Engine Overheats” in “What To
Do In Emergencies” for further information.
For vehicles equipped with a premium cluster this indi-
cator will display in the Electronic Vehicle Information Center (EVIC). Refer to ”Electronic Vehicle Information
Center (EVIC) — If Equipped” for further information.
8. High Beam Indicator
This indicator shows that the high beam head-
lights are on. Push the multifunction lever for-
ward to switch the headlights to high beam, and pull
toward yourself (normal position) to return to low beam.
9. Seat Belt Reminder Light
When the ignition switch is placed in the ON/
RUN position, this light will turn on for four to
eight seconds as a bulb check. During the bulb
check, if the driver’s seat belt is unbuckled, a chime will
sound. After the bulb check or when driving, if the
driver’s seat belt remains unbuckled, the Seat Belt Re-
minder Light will illuminate and the chime will sound.
Refer to “Occupant Restraints” in “Things To Know
Before Starting Your Vehicle” for further information.
312 UNDERSTANDING YOUR INSTRUMENT PANEL

Alarm...............................316
Anti-Lock ............................ .318
Automatic Headlights ....................236
Brake Warning ........................ .313
Bulb Replacement .......................604
Cruise ...............................320
Daytime Running .......................239
Dimmer Switch, Headlight .................240
Electronic Stability Program (ESP) Indicator .....457
Exterior ..............................111
Fog ................................ .239
Hazard Warning Flasher ..................519
Headlights ............................235
Headlights On Reminder ..................239
Headlights On With Wipers ................236
Headlight Switch .......................235
High Beam ............................241
High Beam Indicator .....................312
High Beam/Low Beam Select ...............241Illuminated Entry
........................23
Instrument Cluster ..................... .235
Intensity Control ........................243
Interior ............................. .242
License ............................. .607
Lights On Reminder .....................239
Low Fuel ............................ .316
Malfunction Indicator (Check Engine) .........318
Oil Pressure .......................... .318
Parade Mode (Daytime Brightness) ...........244
Passing ............................. .241
Reading ............................. .242
Seat Belt Reminder ..................... .312
Security Alarm ........................ .316
Service ...............................604
Service Engine Soon (Malfunction Indicator) . . . .318
Tire Pressure Monitoring (TPMS) ............308
T raction

Control ........................457
Turn Signal ............................111
642 INDEX
