snow chains DODGE DART 2015 PF / 1.G Owners Manual

WARNING!
•When in%Partial Off%mode, the TCS functionality
of ESC, (except for the limited slip feature de-
scribed in the TCS section), has been disabled and
the%ESC Off Indicator Light%will be illuminated.
When in%Partial Off%mode, the engine power
reduction feature of TCS is disabled, and the
enhanced vehicle stability offered by the ESC sys-
tem is reduced.
•Trailer Sway Control (TSC) is disabled when the
ESC system is in the%Partial Off%mode.
NOTE:When driving with snow chains, or when starting
off in deep snow, sand, or gravel, it may be desirable to
allow more wheel spin when starting off in snow, mud,
sand, gravel, or when using tire chains. This can be
accomplished by momentarily pressing the “ESC off”
button to enter partial mode “Partial Off” mode. Once the
situation requiring “Partial Off” mode is overcome, turn
ESC back on by momentarily pressing the “ESC Off”
button. This may be done while the vehicle is in motion
ESC Activation/Malfunction Indicator Light
The “ESC Activation/Malfunction Indicator
Light” in the instrument cluster will come on
when the ignition switch is turned to the ON
position. It should go out with the engine
running. The “ESC Activation/Malfunction Indicator
Light” will flash to indicate the system is actively cor-
recting an undesirable vehicle condition. This includes
5
STARTING AND OPERATING 463

graphic display to the vehicle’s recommended cold plac-
ard pressure value. The system will automatically up-
date, the “Inflate Tire to XX” message will no longer be
displayed, the graphic display of the pressure value(s)
will return to their normal color, and the Tire Pressure
Monitoring Light will extinguish once the updated tire
pressure(s) have been received. The vehicle may need to
be driven for up to 20 minutes above 15 mph (24 km/h)
to receive this information.
Service TPMS Message
The Tire Pressure Monitoring Telltale Light will flash on
and off for 75 seconds, and then remain on solid when a
system fault is detected. The system fault will also sound
a chime. The EVIC/DID will display a “SERVICE TPM
SYSTEM” message for a minimum of five seconds. This
text message is then followed by a graphic display, with
“- -“ in place of the pressure value(s) indicating which
Tire Pressure Monitoring Sensor(s) is not being received.
If the ignition key is cycled, this sequence will repeat,
providing the system fault still exists. If the system fault
no longer exists, the Tire Pressure Monitoring Telltale
Light will no longer flash, the#SERVICE TPM SYSTEM#
message will not be present, and a pressure value will be
displayed instead of dashes. A system fault can occur
with any of the following scenarios:
1. Jamming due to electronic devices or driving next to
facilities emitting the same radio frequencies as the
TPM sensors.
2. Installing some form of aftermarket window tinting
that affects radio wave signals.
3. Snow or ice around the wheels or wheel housings.
4. Using tire chains on the vehicle.
5. Using wheels/tires not equipped with TPM sensors.
498 STARTING AND OPERATING

Security Alarm
Arm The System........................20
Rearming The System.....................20
Security Alarm..........................20
Tamper Alert...........................22
Selection of Oil...........................573
SENTRY KEY®
FCC General Information..................19
Sentry Key (Immobilizer)....................17
Sentry Key Programming....................19
Sentry Key Replacement.....................18
Service Assistance.........................631
Service Contract..........................633
Service Engine Soon Light (Malfunction Indicator) . .318
Service Manuals..........................636
Setting the Clock..........................367
Shifting
Manual Transmission....................417
Shift Lever Override.......................556
Short Message Service (SMS).................164
Shoulder Belts............................52
Side View Mirror Adjustment.................122
Signals, Turn.............................114
Snow Chains (Tire Chains)...................488
Snow Tires..............................481
Spare Tire...............................483
Spark Plugs.............................616
Specifications
Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..573
Speed Control (Cruise Control)................253
Speedometer.............................314
Starting.................................30
Automatic Transmission..................412
Engine Fails to Start.....................415
Manual Transmission.....................411
Remote...............................30
Starting Procedures........................411
656 INDEX
