Page 512 of 671
1. Place the vehicle in PARK (P) position and switch theignition LOCK/OFF.
2. Push the center-rear edge of the fuel filler door and release to open. 3. Remove the fuel filler cap and hang cap by tether on
fill door to prevent damage to body side.
Fuel Filler Cap (Gas Cap)
Fuel Filler Door And Fuel Filler Cap Tether Hook
1 — Fuel Filler Door Actuator
2 — Fuel Filler Cap Tether Hook
510 STARTING AND OPERATING
Page 513 of 671
NOTE:In certain cold conditions, ice may prevent the
fuel door from opening. If this occurs, lightly push on the
fuel door around the entire perimeter to break the ice
buildup and re-open the door.
4. When the fuel nozzle “clicks” or shuts off, the fuel tank is full.
5. After you have stopped pumping fuel, remove the fuel filler nozzle and replace the fuel filler cap.
6. Tighten the gas cap about one-quarter turn until you hear one click. This is an indication that the cap is
properly tightened.
7. To close the fuel filler door, push the center-rear edge of the fuel filler door and then release. The fuel door
will close.WARNING!
•Never have any smoking materials lit in or near the
vehicle when the gas cap is removed or the tank is
being filled.
• Never add fuel when the engine is running. This is
in violation of most state and federal fire regula-
tions and may cause the malfunction indicator light
to turn on.
• A fire may result if gasoline is pumped into a
portable container that is inside of a vehicle. You
could be burned. Always place gas containers on
the ground while filling.
CAUTION!
• Damage to the fuel system or emission control
system could result from using an improper fuel
(Continued)
5
STARTING AND OPERATING 511
Page 653 of 671
DrivingThrough Flowing, Rising, Or Shallow Standing
Water ............................... .449
Electrical Power Outlets .....................282
Electric Rear Window Defrost .................294
Electric Remote Mirrors .....................123
Electronic Brake Control System ...............456
Anti-Lock Brake System ..................456
Traction Control System ...................462
Electronic Speed Control (Cruise Control) ........250
Electronic Stability Control (ESC) ..............463
Electronic Throttle Control Warning Light ........314
Electronic Vehicle Information Center (EVIC) . .266, 329
Emergency Brake ........................ .451
Emergency Deck Lid Release ..................48
Emergency, In Case Of Freeing Vehicle When Stuck ................559
Hazard Warning Flasher ..................531 Jacking
.............................. .544
Jump Starting ......................... .555
Overheating .......................... .531
Towing ............................. .563
Emergency Trunk Release ....................48
Emission Control System Maintenance ..........575
Engine ............................. .572, 573
Air Cleaner .......................... .582
Block Heater ......................... .420
Break-In Recommendations ................107
Checking Oil Level ..................... .578
Compartment ......................... .571
Cooling ............................. .591
Exhaust Gas Caution .................109, 509
Fuel Requirements ..................... .504
Jump Starting ......................... .555
Oil .......................... .578, 622, 623
Oil Filler Cap ................572, 573, 580, 581
Oil Filter ............................ .581
10
INDEX 651
