height adjustment DODGE DART 2016 PF / 1.G Owners Manual

▫Advanced Phone Connectivity ............153
▫ Things You Should Know About Your Uconnect
Phone ............................. .154
▫ General Information ...................165
 UCONNECT PHONE (8.4/8.4N) ............165
▫ Uconnect 8.4/8.4Nav ...................165
▫ Operation ......................... .168
▫ Phone Call Features ...................180
▫ Uconnect Phone Features ................185
▫ Advanced Phone Connectivity ............189
▫ Things You Should Know About Your Uconnect
Phone ............................ .190
▫ General Information ...................201
 VOICE COMMAND (Uconnect 200) .........201▫
Voice Command System Operation .........201
▫ Commands ........................ .203
▫ Voice Training ....................... .207
 VOICE COMMAND ....................207
▫ Uconnect 8.4/8.4 Nav ..................207
▫ Uconnect Voice Commands ..............209
 SEATS ............................. .219
▫ Power Seats — If Equipped ..............219
▫ Manual Front Seat Forward/Rearward
Adjustment ......................... .222
▫ Manual Front Seat Recline Adjustment ......223
▫ Manual Seat Height Adjustment — If
Equipped .......................... .224
▫ Front Heated Seats — If Equipped .........224
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Manual Seat Height Adjustment — If Equipped
The driver ’s seat height can be raised or lowered by
using a lever, located on the outboard side of the seat.
Pull upward on the lever to raise the seat height or push
downward on the lever to lower the seat height.
Front Heated Seats — If Equipped
The front heated seats control buttons are located within
the Uconnect system. You can gain access to the control
buttons through the climate screen or the controls screen.
•Press the heated seat button
once to turn the HI
setting ON.
• Press the heated seat buttona second time to turn
the LO setting ON.
• Press the heated seat buttona third time to turn
the heating elements OFF.
If the HI-level setting is selected, the system will auto-
matically switch to LO-level after approximately 60 min-
utes of continuous operation. At that time, the display
will change from HI to LO, indicating the change. The
LO-level setting will turn OFF automatically after ap-
proximately 45 minutes.
Seat Height Adjustment
224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
The head restraints for all occupants must be prop-
erly installed and adjusted prior to operating the
vehicle or occupying a seat. Head restraints should
never be adjusted while the vehicle is in motion.
Driving a vehicle with the head restraints improperly
adjusted or removed could cause serious injury or
death in the event of a collision.
Reactive Head Restraints — Front Seats
The front driver and passenger seats are equipped with
Reactive Head Restraints (RHR). In the event of a rear
impact the RHRs will automatically extend forward
minimizing the gap between the back of the occupant’s
head and the RHR.The RHRs will automatically return to their normal
position following a rear impact. If the RHRs do not
return to their normal position see your authorized
dealer immediately.
To raise the head restraint, pull upward on the head
restraint. To lower the head restraint, push the adjust-
ment button, located at the base of the head restraint, and
push downward on the head restraint.
NOTE:
To remove the head restraint, raise it as far as it
can go then push the release button and the adjustment
button at the base of each post while pulling the head
restraint up. Seatback angle may need to be adjusted to
fully remove the head restraint. To reinstall the head
restraint, put the head restraint posts into the holes and
push downward. Then adjust the head restraint to the
appropriate height.
226 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Rear Head Restraints
The rear outboard head restraints have three positions
UP, MID and DOWN. The center head restraint has only
two positions, UP and DOWN. When the center seat is
being occupied the head restraint should be in the raised
position. When there are no occupants in the center seat
the head restraint can be lowered for maximum visibility
for the driver.
To raise the head restraint, pull upward on the head
restraint. To lower the head restraint, push the adjust-
ment button, located at the base of the head restraint, and
push downward on the head restraint.NOTE:
To remove the head restraint, raise it as far as it
can go then push the release button and the adjustment
button at the base of each post while pulling the head
restraint up. Seatback needs to be folded forward to fully
remove the head restraint. To reinstall the head restraint,
put the head restraint posts into the holes and push
downward. Then adjust the head restraint to the appro-
priate height.
228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
