power steering fluid DODGE DURANGO 2006 2.G Owners Manual

If for some reason, the power assist is interrupted, it will
still be possible to steer your vehicle. Under these condi-
tions you will observe a substantial increase in steering
effort, especially at very low vehicle speeds and during
parking maneuvers.
NOTE:Increased noise levels at the end of the steering
wheel travel are considered normal and does not indicate
that there is a problem with the power steering system.
Upon initial start-up in cold weather, the power steering
pump may make noise for a short period of time. This is
due to the cold, thick fluid in the steering system. This
noise should be considered normal, and does not in any
way damage the steering system.WARNING!
Continued operation with reduced power steering
assist could pose a safety risk to yourself and others.
Service should be obtained as soon as possible.
CAUTION!
Prolong operation of the steering system at the end
of the steering wheel travel will increase the steering
fluid temperature and should be avoided when
possible. Damage to the power steering pump may
occur.
STARTING AND OPERATING 263
5

▫Catalytic Converter....................347
▫Maintenance-Free Battery................348
▫Air Conditioner Maintenance.............349
▫Power Steering — Fluid Check............350
▫Front Suspension Ball Joints..............351
▫Drive Shaft Constant Velocity Joints........351
▫Body Lubrication.....................351
▫Windshield Wiper Blades................352
▫Windshield Washers...................352
▫Exhaust System......................353
▫Cooling System.......................354
▫Emission Related Components............359
▫Brake System........................360▫Automatic Transmission................362
▫Transfer Case........................364
▫Axles..............................365
▫Selection Of Lubricating Grease...........365
▫Appearance Care And Protection From
Corrosion...........................366
Power Distribution Center (Fuse/Relay).......370
Fuse Block............................371
▫Interior Fuses........................371
▫Underhood Fuses
(Power Distribution Center)..............373
▫Underhood Fuses
(Integrated Power Module)..............375
Replacement Light Bulbs.................376
332 MAINTAINING YOUR VEHICLE

WARNING!
•Use only refrigerants and compressor lubricants
approved by the manufacturer for your air condi-
tioning system. Some unapproved refrigerants are
flammable and can explode, injuring you. Other
unapproved refrigerants or lubricants can cause
the system to fail, requiring costly repairs. Refer
to Section 3 of the Warranty Information book for
further warranty information.
•The air conditioning system contains refrigerant
under high pressure. To avoid risk of personal
injury or damage to the system, adding refrigerant
or any repair requiring lines to be disconnected
should be done by an experienced repairman.
Refrigerant Recovery and Recycling
R-134a Air Conditioning Refrigerant is a hydrofluorocar-
bon (HFC) that is endorsed by the Environmental Pro-
tection Agency and is an ozone-saving product. How-
ever, the manufacturer recommends that air conditioning
service be performed by dealers or other service facilities
using recovery and recycling equipment.
Power Steering — Fluid Check
Checking the power steering fluid level at a defined
service interval is not required. The fluid should only be
checked if a leak is suspected, abnormal noises are
apparent, and/or the system is not functioning as antici-
pated. Coordinate inspection efforts through a certified
DaimlerChrysler Dealership.
350 MAINTAINING YOUR VEHICLE

WARNING!
Fluid level should be checked on a level surface and
with the engine off to prevent injury from moving
parts and to insure accurate fluid level reading. Do
not overfill. Use only manufacturers recommended
power steering fluid.
If necessary, add fluid to restore to the proper indicated
level. With a clean cloth, wipe any spilled fluid from all
surfaces. Refer to Fluids, Lubricants, and Genuine Parts
for correct fluid type.
Front Suspension Ball Joints
The ball joints and seals should be inspected whenever
the vehicle is serviced for other reasons. Damaged seals
should be replaced to prevent leakage or contamination
of the grease.
Drive Shaft Constant Velocity Joints
All four wheel drive models are equipped with four
constant velocity joints. Periodic lubrication of these
joints is not required. However, the joint boot should be
inspected for external leakage or damage periodically. If
external leakage or damage is evident, the joint boot and
grease should be replaced immediately. Continued op-
eration could result in failure of the joint due to water
and dirt contamination of the grease. This would require
complete replacement of the joint assembly. Refer to the
Service Manual for the detailed replacement procedure.
Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, doors,liftgate and hood hinges, should be
lubricated periodically to assure quiet, easy operation
and to protect against rust and wear. Prior to the appli-
cation of any lubricant, the parts concerned should be
wiped clean to remove dust and grit; after lubricating
excess oil and grease should be removed. Particular
MAINTAINING YOUR VEHICLE 351
7

D. Maintain coolant concentration at 50% HOAT ethyl-
ene glycol engine coolant (minimum) and distilled water
for proper corrosion protection of your engine.
E. Make sure that the radiator and coolant bottle over-
flow hoses are not kinked or obstructed.
F. Keep the front of the radiator clean. If your vehicle is
equipped with air conditioning, keep the front of the
condenser clean also.
G. The thermostat should not be changed for summer or
winter operation. If replacement is ever necessary, install
ONLY the correct type thermostat. Other designs may
result in unsatisfactory cooling performance.
Emission Related Components
Fuel System Hoses And Vapor/Vacuum Harnesses
When the vehicle is serviced for scheduled maintenance,
inspect surface of hoses and nylon tubing for evidence of
heat and mechanical damage. Hard and brittle rubber,cracking, checking, tears, cuts, abrasions, and excessive
swelling suggest deterioration of the rubber. Particular
attention should be given to examining hose surfaces
nearest to high heat sources, such as the exhaust mani-
fold.
Insure nylon tubing in these areas has not melted or
collapsed.
Inspect all hose clamps and couplings to make sure they
are secure and no leaks are present.
NOTE:Fluids such as oil, power steering fluid, and
brake fluid are used during assembly plant operations to
ease the assembly of hoses to couplings. Therefore, oil
wetness at the hose-coupling area is not necessarily an
indication of leakage. Actual dripping of hot fluid when
systems are under pressure (during vehicle operation),
should be noted before hose is replaced based on leakage.
MAINTAINING YOUR VEHICLE 359
7

Chassis
Component Fluids, Lubricants and Genuine Parts.
Automatic Transmission MoparATF+4, Automatic Transmission Fluid.
Transfer Case MoparATF+4, Automatic Transmission Fluid.
Front Axle SAE 75W-90 Multipurpose Type, GL-5 Gear Lubricant or equivalent.
Rear Axle SAE 75W-140 Synthetic Gear Lubricant or equivalent.
Brake Master Cylinder MoparDOT 3 and SAE J1703 should be used or equivalent. If DOT 3
brake fluid is not available, then DOT 4 is acceptable. Use only recom-
mended brake fluids.
Power Steering Reservoir MoparATF+4, Automatic Transmission Fluid.
MAINTAINING YOUR VEHICLE 387
7

Ball Joints............................. 351
Battery............................... 348
Charging............................ 325
Emergency Starting..................... 325
Gas Caution.......................... 325
Keyless Transmitter Replacement (RKE)....... 26
Saving Feature (Protection)............... 132
Belts, Drive............................ 345
Belts, Seat.............................. 37
Body Mechanism Lubrication............... 351
B-Pillar Location........................ 269
Brake Assist System...................139,147
Brake Control System, Electronic............. 146
Brake Fluid............................ 387
Brake System........................260,360
Anti-Lock (ABS)....................146,260
Disc Brakes.......................... 360
Fluid Check.......................... 360
Hoses.............................. 361Master Cylinder....................... 360
Parking............................. 258
Warning Light.....................186,189
Brakes............................... 260
Brake/Transmission Interlock............... 245
Break-In Recommendations, New Vehicle........ 74
Bulb Replacement....................... 377
Bulbs, Light............................ 376
Calibration, Compass..................... 159
Capacities, Fluid........................ 385
Caps, Filler
Fuel.............................287,288
Oil (Engine).......................... 343
Power Steering........................ 350
Radiator (Coolant Pressure)............... 354
Car Washes............................ 367
Carbon Monoxide Warning............75,163,290
Cargo Management System................. 176
INDEX 421
10

Engine Oil Disposal.................... 344
Flashers
Hazard Warning....................... 316
Turn Signal.....................136,183,378
Flat Tire Stowage.....................319,325
Flooded Engine Starting................... 243
Floor Console.......................... 172
Fluid, Brake.........................360,387
Fluid Capacities......................... 385
Fluid Level Checks
Automatic Transmission................. 362
Brake............................... 360
Cooling System....................... 354
Engine Oil........................... 340
Power Steering........................ 350
Transfer Case......................... 364
Fluids, Lubricants and Genuine Parts.......... 386
Fog Lights..........................135,384
Folding Rear Seat..................... 117,120Four Wheel Drive....................... 250
Operation........................... 250
Four-Way Hazard Flasher.................. 316
Freeing A Stuck Vehicle................... 264
Front Axle (Differential)................... 365
Fuel................................. 285
Adding............................. 287
Filter............................... 346
Gauge.............................. 183
Octane Rating......................285,386
Requirements......................285,385
Tank Capacity........................ 385
Fueling............................... 287
Fuses...........................172,370,371
Garage Door Opener (HomeLink) ........... 162
Gas Cap (Fuel Filler Cap)...............288,337
Gas Gauge (Fuel Gauge)................... 183
Gasoline (Fuel)......................... 285
INDEX 425
10

Bulb Replacement...................376,377
Center Mounted Stop................... 383
Courtesy/Reading..................... 155
Cruise.............................. 191
Daytime Running...................... 134
Door Ajar........................... 188
Electronic Stability Program (ESP)
Indicator...........................151,189
Fog ..........................135,184,384
Hazard Warning Flasher................. 316
Headlights........................... 134
High Beam........................... 137
High Beam/Low Beam Select............. 137
Instrument Cluster..................134,183
Interior..........................132,155
License............................. 382
Lights On Reminder.................... 135
Low Fuel.........................183,184
Malfunction Indicator (Check Engine)........ 190Park............................... 134
Passing............................. 136
Seat Belt Reminder..................... 184
Service.............................. 376
Traction Control....................... 151
Turn Signal........................136,378
Warning (Instrument Cluster Description)..... 183
Washer Fluid......................... 189
Loading Vehicle......................... 292
Tires ............................... 269
Locks................................. 15
Automatic Door........................ 17
Child Protection........................ 19
Door................................ 15
Ignition.............................. 13
Keys................................ 10
Power Door........................... 16
Steering Wheel......................... 13
428 INDEX

Sunroof............................. 168
Windows............................. 34
Power Steering Fluid..................... 387
Pregnant Women and Seat Belts.............. 47
Preparation for Jacking.................... 321
Pretensioners
Seat Belts............................. 45
Programmable Electronic Features.........163,167
Programming Transmitters
(Remote Keyless Entry)...............24,163,167
Radial Ply Tires......................... 276
Radiator Cap (Coolant Pressure Cap).......... 357
Radio Broadcast Signals................... 191
Radio Operation...................193,200,222
Radio Reception........................ 191
Radio, Satellite.......................... 215
Radio (Sound Systems).................193,200
Rear Axle (Differential).................... 365Rear Liftgate............................ 29
Rear Window Defroster................... 238
Rear Window Features.................... 237
Rear Wiper/Washer...................... 237
Rearview Mirrors........................ 84
Reception, Radio........................ 191
Reclining Front Seats..................... 112
Recorder, Event Data...................... 62
Recreational Towing...................... 308
Shifting into Transfer Case Neutral (N)....... 309
Shifting out of Transfer Case Neutral (N)..... 311
Reformulated Gasoline.................... 286
Refrigerant............................ 350
Release, Hood.......................... 129
Reminder, Seat Belt....................... 46
Remote Keyless Entry (RKE)................. 20
Remote Sound System (Radio) Controls........ 220
Remote Starting System.................... 28
Replacement Keys........................ 11
INDEX 431
10
