center console DODGE DURANGO 2007 2.G Owners Manual

The following requirements must be strictly adhered to:
•Do not modify the front seat center console or center
position seat in any way.
•Do not use prior or future model year seat covers not
designated for the specific model being repaired. Al-
ways use the correct seat cover specified for the
vehicle.
•Do not replace the seat cover with an aftermarket seat
cover.
•Do not add a secondary seat cover other than those
approved by DaimlerChrysler/Mopar.
•At no time should any supplemental restraint system
(SRS) component or SRS related component or fas-
tener be modified or replaced with any part except
those which are approved by DaimlerChrysler/
Mopar.
If A Deployment Occurs
The airbag system is designed to deploy the airbags
when the impact sensors detect a moderate-to-severe
frontal collision, to help restrain the driver and front
passenger, and then immediately deflate.
NOTE:A frontal collision that is not severe enough to
need airbag protection will not activate the system. This
does not mean something is wrong with the airbag
system.
If you do have a collision which deploys the airbags, any
or all of the following may occur:
•The nylon airbag material may sometimes cause abra-
sions and/or skin reddening to the driver and front
passenger as the airbags deploy and unfold. The
abrasions are similar to friction rope burns or those
you might get sliding along a carpet or gymnasium
floor. They are not caused by contact with chemicals.
They are not permanent and normally heal quickly.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57
2

Overhead Console With Electronic Vehicle
Information Center (EVIC) — If Equipped.....151
▫Dome/Reading Lights..................151
▫Electronic Vehicle Information Center (EVIC) — If
Equipped...........................152
▫Compass/Temperature Button............158

Garage Door Opener — If Equipped.........160
▫Programming HomeLink................162
▫Canadian Programming/Gate Programming . . 164
▫Using HomeLink.....................165
▫Erasing HomeLink Buttons..............165
▫Reprogramming a Single HomeLink Button . . . 165
▫Security............................166

Power Sunroof — If Equipped.............167▫Express Open Feature..................167
▫Wind Buffeting.......................168
▫Sunroof Maintenance...................169

Electrical Power Outlets..................169
▫115V Inverter Outlet – If Equipped.........170
▫Electrical Outlet Use With Engine Off (Battery
Fed Configuration)....................171

Floor Console.........................172
▫Floor Console Features.................172
▫Rear Floor Console Features – If Equipped . . . 174

Factory Installed Roof Luggage Rack.........175

Cargo Management System—If Equipped......177
78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The front heated seat system allows the driver and front
passenger to select from two different levels of supple-
mental electrical seat heating, or no seat heating to suit
their individual comfort requirements.
With the ignition switch in the RUN position, depressing
the heated seat switch rocker to its momentary high or
low position provides power to the heated seat element
and maintains the requested temperature setting. If the
heated seat switch is depressed to a different position
(low or high) than the currently selected state, the re-
quested temperature setting will change to a new selec-
tion. If the heated seat switch is depressed a second time
to the same position as the currently selected state, the
seat heater will turn off.
The controls for the second row heated seats are located
on the center console between the second row seats.Each heated seat switch has two settings (HI and LOW).
Press the switch once to obtain high heat level, then press
the switch again to obtain low heat level. Pressing the
switch a third time will turn the heated seats off. If you
do not purposefully turn the switch off, the seat heating
level will automatically change to the next lower level, or
Rear Heated Seats Switches
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113
3

“Overhead Console with Electronic Vehicle Information
Center (EVIC)” in Section 3 of this manual.
TO OPEN AND CLOSE THE HOOD
To open the hood, two latches must be released. First pull
the hood release lever located under the left side of the
instrument panel.Then push the safety latch lever to the left. It is located
between the grille and hood opening right of the center.
To prevent possible damage, do not slam the hood to
close it. Use a firm downward push at the center front
edge of the hood to ensure that both latches engage.
Never drive your vehicle unless the hood is fully closed,
with both latches engaged.
Hood Release Lever
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129
3

NOTE:
•Ensure that the rear bumper is free of dirt and debris
to keep the system operating properly.
•Jackhammers, large trucks, and other vibrations could
affect the performance of the system.
If “Service Park Assist System” appears in the Electronic
Vehicle Information Center (EVIC) after making sure the
rear bumper is clean please see your authorized dealer.
To turn on/off the rear park assist system, refer to the
Personal Settings (Customer Programmable Features) in
Section 3 of this Owner Manual.
OVERHEAD CONSOLE
The overhead console has the following features:
•Courtesy Lights
•Garage Door Opener — If Equipped
•Electronic Vehicle Information Center (EVIC) — If
Equipped
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Courtesy/Reading Lights
Near the front of the console are two courtesy/reading
lights.
Both lights illuminate as courtesy lights when a door is
opened, when the dimmer control is rotated to the
courtesy light position (fully upward position), or when
the UNLOCK button is pressed on the Remote Keyless
Entry transmitter, if so equipped. These lights are also
operated individually as reading lights by pressing the
recessed area of the corresponding lens.
NOTE:The courtesy/reading lights will remain on until
the switch is pressed a second time, so be sure they have
been turned off before leaving the vehicle. If the interior
lights are left on after the vehicle is turned OFF, they will
extinguish after 15 minutes.
OVERHEAD CONSOLE WITH ELECTRONIC
VEHICLE INFORMATION CENTER (EVIC) — IF
EQUIPPED
The overhead console contains dome/reading lights, and
an Electronic Vehicle Information Center (EVIC).
Dome/Reading Lights
Located in the overhead console are two dome/reading
lights.
The dome/reading lights illuminate when a door is
opened or when the interior lights are turned on by
rotating the dimmer control located on the Headlight
Switch.
The reading lights are activated by pressing on the
recessed area of the corresponding lens.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151
3

Programming HomeLink
The Electronic Vehicle Information Center (EVIC) fea-
tures a driver–interactive display which includes
HomeLink system messages. The EVIC display is located
in the overhead console.
NOTE:When programming a garage door opener, it is
advised to park outside the garage. It is also recom-
mended that a new battery be placed in the hand-held
transmitter of the device being programmed to
HomeLink for quicker training and accurate transmis-
sion of the radio-frequency signal.
1. Press and hold the two outer HomeLink buttons, and
the EVIC will display “CLEARING CHANNELS”, do not
release the buttons until “CHANNELS CLEARED” is
displayed on the EVIC (after approximately 20 seconds).
Do nothold the buttons for longer than 30 seconds anddo notrepeat step one to program a second and/or third
hand-held transmitter to the remaining two HomeLink
buttons.
2. Position the end of your hand-held transmitter 1-3
inches (3-8 cm) away from the HomeLink buttons while
keeping the EVIC display in view.
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

the rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof opening to
minimize the buffeting or open any window.
Sunroof Maintenance
Use only a nonabrasive cleaner and a soft cloth to clean
the glass panel.
ELECTRICAL POWER OUTLETS
This vehicle has three auxiliary power outlets that can
provide up to 20 Amps of current for accessories de-
signed for use with the standard power outlet adapters.
The outlet located in the lower portion of the instrument
panel has a snap on plastic cap so that it can be covered
when not in use. As a safety precaution, the outlet in the
instrument panel only operates with the ignition switch
ON. When the optional Cigar Lighter heating element isused, it heats when pushed in and pops out automati-
cally when ready for use.To preserve the heating
element, do not hold the lighter in the heating position.
There are two additional 12 V/(20 total Amps for both
outlets) power outlets, one located in the storage bin of
the center console and another located in the right rear
cargo area. These outlets can be reconfigured by the
customer to operate only when the ignition is ON
(switched battery fed) or with the ignition ON or OFF
(battery fed) to allow for cellular telephone charging and
or operation while the ignition is off.
NOTE:All accessories connected to these outlets should
be removed or turned OFF when the vehicle is not in use
to protect the battery against discharge (unless the cus-
tomer has reconfigured the fuse block to switched battery
feed).
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169
3

115V Inverter Outlet – If Equipped
This vehicle may also be equipped with a 115 Volt (150
Watts Maximum) outlet on the rear of the front center
console. These outlets can power cell phones, electronics
and other low power devices. This plug is controlled by
a switch located in left lower instrument panel.NOTE:Due to build in overload protection the inverter
will shut down if the power rating is exceeded.
WARNING!
To Avoid Serious Injury or Death:
•Donotusea3—Prong Adaptor.
•Do not insert any objects into the receptacles.
•Do not touch with wet hands.
•Close the lid when not in use.
•If this outlet is mishandled it may cause an
electric shock and failure.
115 V Inverter Switch
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

•Portable phone storage bin
•Portable phone cord routing between lid and base on
forward edge
•12 Volt reconfigurable power outlet inside storage
compartment
•Side open armrest lid
•Tissue holder & pen holder
•Coin slots
•Removable CD bin
The coin slots are located under the instrument panel
center stack.
Cup Holders
Your vehicle has 8 cupholders. Four are located in the
center console, two are located in the second row armrest,
and two are located in the left hand quarter panel for
third row occupants. The four cupholders located in the
center console may be removed for cleaning.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173
3
